Sony STR-DG710 - Electrical Parts List: HDMI RE Board Components; HDMI RE ICs and Transistors; HDMI RE Board Connectors and Diodes

75
STR-DG710
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C3591 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3593 1-128-994-21 ELECT CHIP 47uF 20% 10V
C3594 1-128-994-21 ELECT CHIP 47uF 20% 10V
C3596 1-128-994-21 ELECT CHIP 47uF 20% 10V
C3597 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3615 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3616 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3617 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3618 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3619 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3620 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3621 1-112-791-11 ELECT CHIP 100uF 20% 16V
C3625 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C3627 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C3630 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3631 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3632 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3633 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3634 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3635 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C3643 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C3644 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
< CONNECTOR >
CN3501 1-820-735-11 CONNECTOR, HDMI 19P (HDMI DVD IN)
CN3502 1-820-735-11 CONNECTOR, HDMI 19P (HDMI VIDEO 2/BD IN)
CN3504 1-820-735-11 CONNECTOR, HDMI 19P (HDMI OUT)
CN3509 1-779-993-11 PIN, CONNECTOR (PWB) 5P
CN3510 1-784-859-51 CONNECTOR, FFC (LIF(NON-ZIF)) 7P
CN3512 1-785-466-41 CONNECTOR, FFC/FPC 7P
< DIODE >
D3501 8-719-988-61 DIODE 1SS355TE-17
D3502 8-719-988-61 DIODE 1SS355TE-17
D3511 8-719-988-61 DIODE 1SS355TE-17
D3512 8-719-988-61 DIODE 1SS355TE-17
< TERMINAL >
ET3503 1-780-318-11 TERMINAL
< FERRITE BEAD >
FB3501 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3502 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3503 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3504 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3505 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3506 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3508 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3509 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3510 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3511 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3512 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3513 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3514 1-414-234-22 INDUCTOR, FERRITE BEAD
< IC >
IC3501 8-759-389-26 IC 74LCX08MTCX
IC3503 6-710-819-01 IC TMDS341APFCR
IC3504 8-759-596-39 IC SN74LV4052APWR
IC3507 6-708-758-01 IC PCA9517DP.118
IC3509 6-704-001-01 IC BR24L02F-WE2
IC3511 (Not supplied) IC SII9011CLU
IC3513 (Not supplied) IC SII9030CTU-7
IC3516 6-705-337-01 IC TK11150CSCL-G
IC3519 6-807-228-01 IC M30620FCPGP-RPT02
IC3521 8-759-596-39 IC SN74LV4052APWR
IC3526 6-707-744-01 IC SI-3033KM-TL
IC3527 6-707-744-01 IC SI-3033KM-TL
IC3528 8-759-832-05 IC BA18BC0FP-E2
< TRANSISTOR >
Q3504 6-550-014-01 FET SSM6N15FU(TE85R)
Q3505 8-729-600-22 TRANSISTOR 2SA1235-F
Q3506 8-729-600-22 TRANSISTOR 2SA1235-F
< RESISTOR >
R3500 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3502 1-216-864-11 SHORT CHIP 0
R3504 1-216-864-11 SHORT CHIP 0
R3509 1-216-805-11 METAL CHIP 47 5% 1/10W
R3511 1-216-841-11 METAL CHIP 47K 5% 1/10W
R3512 1-216-805-11 METAL CHIP 47 5% 1/10W
R3513 1-216-841-11 METAL CHIP 47K 5% 1/10W
R3519 1-216-864-11 SHORT CHIP 0
R3521 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3524 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3525 1-218-844-11 METAL CHIP 750 0.5% 1/10W
R3526 1-218-861-11 METAL CHIP 3.9K 0.5% 1/10W
R3527 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3528 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3532 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3533 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3534 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3535 1-216-864-11 SHORT CHIP 0
R3536 1-216-864-11 SHORT CHIP 0
R3541 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3542 1-216-864-11 SHORT CHIP 0
R3544 1-216-805-11 METAL CHIP 47 5% 1/10W
R3545 1-216-805-11 METAL CHIP 47 5% 1/10W
R3546 1-216-857-11 METAL CHIP 1M 5% 1/10W
R3548 1-216-803-11 METAL CHIP 33 5% 1/10W
R3549 1-216-809-11 METAL CHIP 100 5% 1/10W
R3550 1-216-809-11 METAL CHIP 100 5% 1/10W
R3551 1-216-809-11 METAL CHIP 100 5% 1/10W
R3552 1-216-809-11 METAL CHIP 100 5% 1/10W
R3554 1-216-809-11 METAL CHIP 100 5% 1/10W
R3556 1-216-809-11 METAL CHIP 100 5% 1/10W
R3557 1-216-805-11 METAL CHIP 47 5% 1/10W
R3558 1-216-864-11 SHORT CHIP 0
R3562 1-216-864-11 SHORT CHIP 0
R3563 1-216-809-11 METAL CHIP 100 5% 1/10W
R3564 1-218-285-11 METAL CHIP 75 5% 1/10W
R3565 1-216-805-11 METAL CHIP 47 5% 1/10W
R3566 1-218-285-11 METAL CHIP 75 5% 1/10W
R3567 1-218-285-11 METAL CHIP 75 5% 1/10W
HDMI RE
Note: When IC3511 and IC3513 on the HDMI RE board are damaged, exchange
the new HDMI RE board for the HDMI RE board which IC damaged.
