Sony STR-DG710 - Electrical Parts List: Main Board Transistors and Resistors; Main Board Transistors and Resistors

79
STR-DG710
IC801 8-759-071-48 IC TA7807S
IC802 8-759-071-47 IC TA79007S
IC3002 8-759-710-97 IC NJM4565M-D
< JACK >
J309 1-770-377-21 JACK, PIN 1P (SUB WOOFER AUDIO OUT)
J402 1-770-614-11 JACK, PIN 4P (VIDEO 1 AUDIO IN/AUDIO OUT)
J406 1-774-411-11 JACK, PIN 6P (SA-CD/CD/CD-R IN,
TV AUDIO IN,SAT AUDIO IN)
< COIL >
L501 1-420-872-52 COIL, AIR-CORE
L551 1-420-872-52 COIL, AIR-CORE
L601 1-420-872-52 COIL, AIR-CORE
L651 1-420-872-52 COIL, AIR-CORE
L701 1-420-872-52 COIL, AIR-CORE
L751 1-420-872-52 COIL, AIR-CORE
< TRANSISTOR >
Q501 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q502 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q505 8-729-216-31 TRANSISTOR 2SA1163-G
Q506 8-729-216-31 TRANSISTOR 2SA1163-G
Q535 8-729-216-31 TRANSISTOR 2SA1163-G
Q536 8-729-216-31 TRANSISTOR 2SA1163-G
Q540 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q560 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q571 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q572 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q580 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q601 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q602 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q605 8-729-216-31 TRANSISTOR 2SA1163-G
Q606 8-729-216-31 TRANSISTOR 2SA1163-G
Q610 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q611 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q612 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q640 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q651 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q652 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q655 8-729-216-31 TRANSISTOR 2SA1163-G
Q656 8-729-216-31 TRANSISTOR 2SA1163-G
Q680 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q691 8-729-281-53 TRANSISTOR 2SC1815-GR
Q692 8-729-029-40 TRANSISTOR DTA124ESA
Q701 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q702 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q705 8-729-216-31 TRANSISTOR 2SA1163-G
Q706 8-729-216-31 TRANSISTOR 2SA1163-G
Q710 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q722 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q723 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q725 8-729-216-31 TRANSISTOR 2SA1163-G
Q740 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q750 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q751 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q752 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q755 8-729-216-31 TRANSISTOR 2SA1163-G
Q756 8-729-216-31 TRANSISTOR 2SA1163-G
Q790 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q793 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q795 8-729-216-31 TRANSISTOR 2SA1163-G
Q801 8-729-140-97 TRANSISTOR 2SB734-34
< RESISTOR >
R402 1-216-821-11 METAL CHIP 1K 5% 1/10W
R404 1-216-821-11 METAL CHIP 1K 5% 1/10W
R405 1-216-821-11 METAL CHIP 1K 5% 1/10W
R406 1-216-821-11 METAL CHIP 1K 5% 1/10W
R408 1-216-821-11 METAL CHIP 1K 5% 1/10W
R423 1-216-864-11 SHORT CHIP 0
R427 1-216-864-11 SHORT CHIP 0
R428 1-216-821-11 METAL CHIP 1K 5% 1/10W
R429 1-216-821-11 METAL CHIP 1K 5% 1/10W
R447 1-216-864-11 SHORT CHIP 0
R452 1-216-821-11 METAL CHIP 1K 5% 1/10W
R454 1-216-821-11 METAL CHIP 1K 5% 1/10W
R455 1-216-821-11 METAL CHIP 1K 5% 1/10W
R456 1-216-821-11 METAL CHIP 1K 5% 1/10W
R458 1-216-821-11 METAL CHIP 1K 5% 1/10W
R468 1-216-845-11 METAL CHIP 100K 5% 1/10W
R469 1-216-821-11 METAL CHIP 1K 5% 1/10W
R470 1-216-841-11 METAL CHIP 47K 5% 1/10W
R471 1-216-841-11 METAL CHIP 47K 5% 1/10W
R472 1-216-841-11 METAL CHIP 47K 5% 1/10W
R473 1-216-841-11 METAL CHIP 47K 5% 1/10W
R474 1-216-841-11 METAL CHIP 47K 5% 1/10W
R475 1-216-833-11 METAL CHIP 10K 5% 1/10W
R476 1-216-833-11 METAL CHIP 10K 5% 1/10W
R480 1-216-864-11 SHORT CHIP 0 (EXCEPT US,CND)
R481 1-216-864-11 SHORT CHIP 0 (EXCEPT US,CND)
R501 1-216-821-11 METAL CHIP 1K 5% 1/10W
R502 1-216-843-11 METAL CHIP 68K 5% 1/10W
R503 1-208-445-41 RES-CHIP 2.2K 2% 1/10W
R505 1-208-826-11 METAL CHIP 68K 0.5% 1/10W
R510 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R511 1-216-844-11 METAL CHIP 82K 5% 1/10W
R513 1-216-818-11 METAL CHIP 560 5% 1/10W
R514 1-249-399-11 CARBON 33 5% 1/4W F
R515 1-249-399-11 CARBON 33 5% 1/4W F
R516 1-234-182-11 ENCAPSULATED COMPONENT 0.22X2 5W
R517 1-249-393-11 CARBON 10 5% 1/4W F
R518 1-249-389-11 CARBON 4.7 5% 1/4W F
R520 1-216-214-00 RES-CHIP 4.7K 2% 1/8W
R521 1-240-855-11 CARBON 6.2K 5% 1/4W F
R522 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R523 1-216-841-11 METAL CHIP 47K 5% 1/10W
R524 1-216-835-11 METAL CHIP 15K 5% 1/10W
R525 1-216-843-11 METAL CHIP 68K 5% 1/10W
R526 1-234-182-11 ENCAPSULATED COMPONENT 0.22X2 5W
R530 1-216-214-00 RES-CHIP 4.7K 2% 1/8W
R531 1-240-855-11 CARBON 6.2K 5% 1/4W F
R532 1-216-833-11 METAL CHIP 10K 5% 1/10W
R533 1-216-841-11 METAL CHIP 47K 5% 1/10W
R534 1-216-835-11 METAL CHIP 15K 5% 1/10W
R535 1-216-843-11 METAL CHIP 68K 5% 1/10W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
