Sony STR-DG710 - Electrical Parts List: Video, XM Board Components; Video Board Resistors; XM Board Capacitors and Connectors

83
STR-DG710
R201 1-247-804-11 CARBON 75 5% 1/4W
R218 1-247-804-11 CARBON 75 5% 1/4W
R219 1-247-804-11 CARBON 75 5% 1/4W
R220 1-247-804-11 CARBON 75 5% 1/4W
R221 1-247-804-11 CARBON 75 5% 1/4W
R301 1-247-804-11 CARBON 75 5% 1/4W
R302 1-247-804-11 CARBON 75 5% 1/4W
R303 1-247-804-11 CARBON 75 5% 1/4W
R304 1-247-804-11 CARBON 75 5% 1/4W
R305 1-247-804-11 CARBON 75 5% 1/4W
R306 1-247-804-11 CARBON 75 5% 1/4W
R307 1-247-804-11 CARBON 75 5% 1/4W
R308 1-247-804-11 CARBON 75 5% 1/4W
R309 1-247-804-11 CARBON 75 5% 1/4W
R310 1-247-804-11 CARBON 75 5% 1/4W
R311 1-247-804-11 CARBON 75 5% 1/4W
R312 1-247-804-11 CARBON 75 5% 1/4W
*************************************************************
VIDEO 3 BOARD
*************
< CAPACITOR >
C293 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C294 1-100-566-11 CERAMIC CHIP 0.1uF 10% 25V
C298 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C299 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
< CONNECTOR >
CN201 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
* CN202 1-690-880-31 LEAD (WITH CONNECTOR)
< JACK >
J298 1-819-187-11 JACK, PIN 3P (VIDEO 3/PORTABLE AV IN
VIDEO,AUDIO)
< RESISTOR >
R298 1-216-821-11 METAL CHIP 1K 5% 1/10W
R299 1-216-821-11 METAL CHIP 1K 5% 1/10W
*************************************************************
A-1267-502-A XM BOARD, COMPLETE (US,CND)
*******************
< CAPACITOR >
C101 1-137-649-31 ELECT 220uF 20% 10V
C102 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C103 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C104 1-112-100-11 ELECT 10uF 20% 50V
C105 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C106 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C107 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C108 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C109 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C110 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C111 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C112 1-216-864-11 SHORT CHIP 0
C113 1-126-964-11 ELECT 10uF 20% 50V
C114 1-216-864-11 SHORT CHIP 0
C115 1-216-864-11 SHORT CHIP 0
C116 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C117 1-216-864-11 SHORT CHIP 0
C118 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C119 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C120 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C121 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C122 1-112-100-11 ELECT 10uF 20% 50V
C123 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C124 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C125 1-112-100-11 ELECT 10uF 20% 50V
C126 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C127 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C128 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C129 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C130 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C131 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C132 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C133 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C134 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C135 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C136 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C137 1-126-964-11 ELECT 10uF 20% 50V
C138 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C139 1-126-964-11 ELECT 10uF 20% 50V
C140 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C142 1-126-964-11 ELECT 10uF 20% 50V
C143 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C144 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C145 1-126-933-11 ELECT 100uF 20% 16V
C153 1-126-933-11 ELECT 100uF 20% 16V
C157 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C159 1-137-649-31 ELECT 220uF 20% 10V
C161 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C163 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C164 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C165 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C166 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C167 1-216-864-11 SHORT CHIP 0
C168 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C169 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN101 1-568-828-11 CONNECTOR, FFC 9P
CN102 1-784-766-11 CONNECTOR, FFC 5P
CNP103 1-779-978-11 PIN, CONNECTOR 3P
< DIODE >
D101 6-500-462-01 DIODE NSAD500F-T1B
D103 8-719-083-02 DIODE KDS160-RTK
< FERRITE BEAD >
FB101 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB104 1-469-152-11 FERRITE, EMI (SMD) (2012)
< IC >
IC101 6-705-468-01 IC BA33BC0FP-E2
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
XMVIDEO VIDEO 3
