Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DN1010
100
< CONNECTOR >
CN6202 1-770-408-11 CONNECTOR, BOARD TO BOARD 14P
< DIODE >
D6101 6-501-817-01 DIODE MA2J1110GLS0
D6102 6-501-817-01 DIODE MA2J1110GLS0
D6503 6-502-218-01 DI RB060M-30TR
D6504 6-502-961-01 DI DA2J10100L
D6505 6-502-961-01 DI DA2J10100L
< FERRITE BEAD >
FB6001 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB6002 1-469-152-11 FERRITE, EMI (SMD) (2012)
< IC >
IC6001 6-706-767-01 IC NJM2586AM
IC6101 8-759-822-05 IC LA7213
IC6102 8-759-822-05 IC LA7213
IC6205 6-713-031-01 IC KIA7805API-U/PF
IC6206 6-711-998-01 IC KIA7905PI
IC6302 6-704-199-01 IC NJM2595M-TE2
< JACK >
J6001 1-816-592-11 JACK, PIN 9P
(COMPONENT VIDEO ASSIGNABLE
(INPUT ONLY) IN 1/IN 2/MONITOR OUT)
J6002 1-821-278-12 JACK 3P (COMPONENT VIDEO ASSIGNABLE
(INPUT ONLY) IN 3)
J6004 1-815-043-11 JACK, PIN 2P
(VIDEO 1 VIDEO IN, MONITOR VIDEO OUT)
J6005 1-794-978-11 JACK, PIN 3P
(SAT/CATV VIDEO IN, BD VIDEO IN,
VIDEO 1 VIDEO OUT)
< JUMPER RESISTOR >
JR6000 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q6105 6-551-469-01 TRANSISTOR RT3N33M-T111-1
Q6106 6-551-272-01 TRANSISTOR RT3CLLM
< RESISTOR >
R6001 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6002 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6003 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6004 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6005 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6006 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6007 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6008 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6009 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6013 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6014 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6015 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6016 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6017 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6018 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6101 1-216-815-11 METAL CHIP 330 5% 1/10W
R6102 1-216-815-11 METAL CHIP 330 5% 1/10W
R6103 1-216-847-11 METAL CHIP 150K 5% 1/10W
R6104 1-216-847-11 METAL CHIP 150K 5% 1/10W
R6105 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R6106 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R6107 1-216-813-11 METAL CHIP 220 5% 1/10W
R6111 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R6112 1-216-821-11 METAL CHIP 1K 5% 1/10W
R6113 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R6114 1-216-821-11 METAL CHIP 1K 5% 1/10W
R6124 1-216-815-11 METAL CHIP 330 5% 1/10W
R6125 1-216-815-11 METAL CHIP 330 5% 1/10W
R6301 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6302 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6304 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6306 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6307 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R6311 1-216-864-11 SHORT CHIP 0
*************************************************************
MISCELLANEOUS
**************
55 1-828-384-11 WIRE (FLAT TYPE) (23 CORE)
56 1-828-312-51 WIRE (FLAT TYPE) (9 CORE)
0 103 1-777-071-83 CORD, POWER (UK, ECE)
0 103 1-834-270-11 CORD, POWER (US, CND)
0 103 1-833-566-21 POWER SUPPLY CORD (AUS)
155 1-828-954-11 WIRE (FLAT TYPE) (9 CORE) (US, CND)
155 1-828-964-11 WIRE (FLAT TYPE) (11 CORE) (UK, AUS, ECE)
156 1-828-660-11 WIRE (FLAT TYPE) (27 CORE)
0 F900 1-532-465-33 FUSE, T3.15AL 250V (UK, AUS, ECE)
0 F900 1-533-311-12 FUSE, GLASS (DIA.5) 8A 125V (US, CND)
IC604 6-702-390-01 TRANSISTOR MN2488-OPY-MK
IC605 6-702-391-01 TRANSISTOR MP1620-OPY-MK
IC606 6-702-390-01 TRANSISTOR MN2488-OPY-MK
IC607 6-702-391-01 TRANSISTOR MP1620-OPY-MK
IC608 6-702-390-01 TRANSISTOR MN2488-OPY-MK
IC609 6-702-391-01 TRANSISTOR MP1620-OPY-MK
IC610 6-702-390-01 TRANSISTOR MN2488-OPY-MK
IC611 6-702-391-01 TRANSISTOR MP1620-OPY-MK
IC612 6-702-390-01 TRANSISTOR MN2488-OPY-MK
IC613 6-702-391-01 TRANSISTOR MP1620-OPY-MK
IC614 6-702-390-01 TRANSISTOR MN2488-OPY-MK
IC615 6-702-391-01 TRANSISTOR MP1620-OPY-MK
IC616 6-702-390-01 TRANSISTOR MN2488-OPY-MK
IC617 6-702-391-01 TRANSISTOR MP1620-OPY-MK
0 T901 1-445-652-21 POWER TRANSFORMER (MAIN) (UK, AUS, ECE)
0 T901 1-445-797-11 POWER TRANSFORMER (MAIN) (US)
0 T901 1-445-824-11 POWER TRANSFORMER (MAIN) (CND)
TN1 1-693-737-21 TUNER (FM/AM) (UK, AUS, ECE)
TN1 1-693-779-11 TUNER (FM/AM) (US, CND)
*************************************************************
ACCESSORIES
************
1-126-947-11 CAP, ELECT 47M
1-487-852-11 REMOTE COMMANDER RM-AAP052
(UK, AUS, ECE)
1-487-857-11 REMOTE COMMANDER RM-AAP051 (US, CND)
1-501-374-12 ANTENNA, LOOP (AM loop antenna (aerial))
1-542-774-21 MEASUREMENT MIC (MONO)
(Optimizer microphone (ECM-AC2))
1-770-019-71 ADAPTOR, CONVERSION PLUG 3P (UK)
1-793-184-51 CONNECTOR (F TYPE ADAPTOR)
3-254-070-11 SCREW
4-174-068-12
INSTRUCTION MANUAL (ENGLISH)
VIDEO
Note: If wire (fl at type) is replaced, install it after bending
it in the same form as that before replacement.
