5-6.  BLOCK  DIAGRAM - PANEL, POWER SUPPLY Section -
RY900
RY406
RELAY DRIVE
Q406
ND101
FLUORESCENT
INDICATOR TUBE
SYSTEM CONTROLLER
IC2018 (5/5)
FL_DATA
141
FL_CLK
142
FL_LATCH
140
FL_BK
49
REMOTE CONTROL
SIGNAL RECEIVER
IC101
123 S I R C S
121 POWER_SWITCH_DET
99 AD_1
S101, S106 – 108
S102 – S105, S109 – S111
100 A D _ 2
98 VOL_DATA
ROTARY
ENCODER
MASTER
VOLUME
RV102
D2025
D2025
D2109
53 MHC_LED
54 WHT_LED
(AC IN)
T910 (US, CND)
T911 (UK, AUS, ECE)
SUB POWER
TRANSFORMER
137RST_TRIGGER
15STOP
16POWER_RELAY
131INTIX
128MD2
TH921
D905
D3513 – 3515
D3201, D3202
RELAY DRIVE
Q913
RECT
D901, D902,
D904, D961
RECT
D908
REGULATOR
Q911 – 912
D910D903
+5V
REG
IC900
–7V
REG
IC413
+3.3V
REG
IC2000
RESET SIGNAL
GENERATOR
IC2020
RESET
SWITCH
IC2019
RESET SIGNAL
BUFFER
IC2021
VCC +3.3V
B+
B–
F900
–7V
+9V
REG
IC2001
TUNER +9V
FOR FLUORESCENT
INDICATOR TUBE
RECT
D104 – 107
OSC
Q105, 106
T101
DC/DC
CONVERTER
+5V
REG
IC6205
+11V
REG
IC108
VIDEO +5V
LED B+
HDMI +3.3V
+7V
REG
IC412
+7V
+5V
REG
IC2010
+5V
+1.26V
REG
IC5004
 DSP +1.26V
-5V
REG
IC6206
VIDEO –5V
BRIDGEABLE RY
+15V
RECT
D407
RECT
D401 – 404
T901
MAIN POWER
TRANSFORMER
+4V
REG
IC960
+6.2V
REG
IC950
+3.3V
REG
IC3517
HDMI +5V
(FOR TX)
+5V
REG
IC3516
HDMI +5V
+5V
REG
IC3521
DMPORT +5V
+5
REV
IC2016
HDMI +1.2V
CVDD +1.8V
VDD +1.8V
TX_5VPWR
+1.2V
REG
IC3519
DSP +3.3V
+3.3
REV
IC2017
+2.5
REV
IC2005
S114
I / 1
S-AIR +4V
THERMAL
SENSOR
IC1952
THERMAL
SENSOR
IC1950
THERMAL
SENSOR
IC1951
101 THERMAL1
102 THERMAL2
(EXCEPT US)
(US ONLY)
STBY +5V
F401
F402
F901
F902
F403
F404
+9V
REG
IC901
LED DRIVE
Q110
MULTI
CHANNEL
DECODING
D101
D102
DIMMER
INDICATOR
+1.8
REG
IC3203
+1.8
REG
IC3210 (2/2)
D3511, D3516
HDMI +1.8V
+1.8V
REG
IC3515
+1.8V
+1.8
REG
IC3209
BUS SWITCH
IC2033
MD
RESET
LED
POWER_RELAY
Abbreviation
: Australian modelAUS
: Canadian modelCND
N
DIGITAL VIDEO SECTION
(Page 18)
Y
Z
DSP, SAIR, SIRIUS SECTION
(Page 20)
AUDIO SECTION
(Page 21)
T
DSP, SAIR, SIRIUS SECTION
(Page 20)
