Sony STR-DN1010 Service Manual

STR-DN1010
55
IC600, 601, 602 STK350-630T-E (MAIN BOARD (1/3))
IC603 STK350-630T-E (MAIN BOARD (2/3))
(For US and Canadian models only)
IC600, 601, 602 HIC CXD9986L (MAIN BOARD (1/3))
IC603 HIC CXD9986L (MAIN BOARD (2/3))
(For UK, Australian, Continental European, East European and Russian models only)
IC3205 TC7PA53FU (TE85L.F)
(DIGITAL VIDEO BOARD (4/5))
MALTIPLEXER/
DEMALTIPLEXER
1
CH1
3
CH0
2
GND
4
COMMON
6
A
5
VCC
IC3206 TC74LCX74FT (EKJ)
(DIGITAL VIDEO BOARD (4/5))
14
1 2 3 4 5 6 7
13 12 11 10 9 8
VCC
GND
CK
CLR
CK
CLR
Q
PR
Q
Q
PR
Q
D
D
MUTE
+VOUT1
-VOUT2
COMP1
NF1 NF2
COMP2
-VOUT2
+VOUT1
VCC VCC VEE
IN1 IN2
GND
1
2
3
4
5 6 7 8 9
10
11
12
13
14
15
MUTE
-VOUT1
+VOUT1
COMP1
NF1 NF2
COMP2
-VOUT
VCC VCC VEE
IN1
SUB
IN2
GND
1
2
3
4
5
6 7 8 9
10
11
13
+VOUT2
12
14
15

Sony STR-DN1010 Specifications

General

Impedance	8 Ω
Audio output channels	7.1 channels
HDMI	Yes
Output power	200 W
Dimensions (WxDxH)	430 x 157.5 x 324.5 mm
Supported video modes	1080p
Product color	Black
Connectivity technology	Wired
Headphone outputs	1
Component video (YPbPr/YCbCr) in	3
