Sony STR-DN1010 - Page 59

STR-DN1010
59
Pin No. Pin Name I/O Description
57 VCC3_(3.3V) - Power supply terminal (+3.3V)
58 VSS_(GND) - Ground terminal
59 NO_USE - Not used
60 NO_USE - Not used
61 NO_USE - Not used
62 to 65
COMPOSITE_SW4 to
COMPOSITE_SW1
O Composite video selection signal output to the video amplifi er
66, 67
COMPONENT_SW1,
COMPONENT_SW2
O Component video selection signal output to the video amplifi er
68 V_MUTE O Video muting control signal output to the video amplifi er
69 PROTECT I Protect detection signal input terminal
70 E_VOL_DATA O Serial data output to the electrical volume
71 E_VOL_CLK O Serial data transfer clock signal output to the electrical volume
72 NO_USE - Not used
73 VCC3_(3.3V) - Power supply terminal (+3.3V)
74 VSS_(GND) - Ground terminal
75 to 83 NO_USE - Not used
84 NO_USE O Not used
85 NO_USE O Not used
86 COMPO_DET I Component video detection signal input from video amplifi er
87 VIDEO_DET I Composite video detection signal input from video amplifi er
88 VSS_(GND) - Ground terminal
89 VCC3_(3.3V) - Power supply terminal (+3.3V)
90 TUNER_RDS_DATA I RDS serial data input from the tuner (FM/AM) (AEP and UK models only)
91 TUNER_MISO I Serial data input from the tuner (FM/AM)
92 TUNER_CLK O Serial data transfer clock signal output to the tuner (FM/AM)
93 TUNER_MOSI O Serial data output to the tuner (FM/AM)
94 TUNER_CE O Serial data latch pulse signal output to the tuner (FM/AM)
95 TUNER_SD I FM stereo detection signal input from the tuner (FM/AM)
96 SAIR_SELECT O Not used
97 NO_USE O Not used
98 VOL_DATA I Volume jog
99 to 100 AD_1 to AD_3 I Front panel key input terminal (A/D input)
101, 102
THERMAL1,
THERMAL2
I Thermal detection signal input from the thermal sensor
103 MAIN_LIMITER I Limiter detection signal input terminal
104 VERSION I Destination setting terminal
105 COM_CLK O
Serial data transfer clock signal output to the digital audio interface receiver and D/A
converter
106 DAC_LATCH O Serial data latch pulse signal output to the D/A converter
107 COM_DATA O Serial data output to the digital audio interface receiver and D/A converter
108 DAC_MUTE O Muting control signal output to the D/A converter
109 S_AIR_RESET O Reset signal output to the wireless transmitter (EZW-T100)
110 S_AIR_ADC_SEL O A/D converter selection signal output to the wireless transmitter (EZW-T100)
111 SRC_MUTE O Sampling rate converter muting signal output to the wireless transmitter (EZW-T100)
112 S_AIR_DETECT I
Wireless transmitter (EZW-T100) connection detection signal input terminal
“L”: wireless transmitter (EZW-T100) is connected
113 SPDIF_UP_SW O Update selection signal output to the switching
114 AVSS/AVRL - Ground terminal (for A/D converter)
115 AVCC3(3.3V A/D) - Power supply terminal (+3.3V) (for A/D converter)
116 AVRH I Reference voltage (+3.3V) input terminal (for A/D converter)
117 S_AIR_SDA I/O Two-way I2C data bus with the wireless transmitter (EZW-T100)
118 S_AIR_SCL O Two-way I2C clock bus with the wireless transmitter (EZW-T100)
119 S_AIR_INT I Interrupt signal input from wireless transmitter (EZW-T100)
120 NO_USE - Not used
121
POWER_SWITCH_
DET
I Power switch input terminal
122 DIR_XMODE O Reset signal output to the digital audio interface receiver “L”: reset
