Sony STR-DN1010 - VIDEO DEINTERLACING IC Pin Functions

STR-DN1010
61
DIGITAL VIDEO BOARD (5/5) IC3000 R5F3640DDFBR-128 (HDMI CONTROLLER)
Pin No. Pin Name I/O Description
1 to 5 NC O Not used
6 BYTE I External data bus width selection signal input terminal “L”: 16 bit Fixed at “L” in this set
7 CNVSS I
Processor mode selection signal input terminal “L”: single chip mode
Fixed at “L” in this set
8, 9 NC O Not used
10 RESET I Reset signal input from the system controller “L”: reset
11 XOUT O System clock output terminal (10 MHz)
12 VSS - Ground terminal
13 XIN I System clock input terminal (10 MHz)
14 VCC_3.3V - Power supply terminal (+3.3V)
15 NMI I Non-maskable interrupt signal input terminal Not used
16 to 18 NC O Not used
19 RX_RST O Reset signal output to the HDMI receiver “L”: reset
20 RX_INT I Interrupt signal input from the HDMI receiver
21 1444_HPD O Hot plug detection control signal output to the HDMI input selector
22 HPD_IN1 O Hot plug detection control signal output to the HDMI IN 1 connector
23 to 26 NC O Not used
27 CSCL O I2C clock signal output to the EEPROM, HDMI receiver and HDMI transmitter
28 CSDA I/O I2C data bus with the EEPROM, HDMI receiver and HDMI transmitter
29 232COUT (VU TX) O Serial data output to the connector (for RS-232C) and DSP
30 232CIN (VU RX) I Serial data input from the connector (for RS-232C) and DSP
31 CLK 1 O Not used
32 RTS 1 O Not used
33 VUCOM_SDA I/O I2C data bus with the system controller
34 VUCOM_SCL I I2C clock signal input from the system controller
35 EDID_SELA O Write protect signal output to the EEPROM
36 EDID_SELB O Input data selection signal output to the data selector
37 to 39 NC O Not used
40 VDAC_RESET O Not used
41 TX_5VPWR O Power supply on/off control signal output terminal for HDMI OUT connector “H”: power on
42 TX_RST O Reset signal output to the HDMI transmitter “L”: reset
43 TX_INT I Interrupt signal input from the HDMI transmitter
44 to 50 NC O Not used
51 to 53
1444_SELA to
1444_SELC
O HDMI input selection signal output to the HDMI input selector
54 1444_OEB O Output enable signal output to the HDMI input selector
55, 56 P5V_SELA, P5V_SELB O HDMI +5V power input selection signal output terminal
57 to 59 NC O Not used
60 VCC_3.3V - Power supply terminal (+3.3V)
61 NC O Not used
62 VSS - Ground terminal
63 NC O Not used
64 NON LPCM O Non-LPCM setting signal output to the DSP “L”: LPCM
65 MUTE O Error signal output to the system controller and DSP
66 to 90 NC O Not used
91 to 93
MODEL_SW3 to
MODEL_SW1
I Model setting terminal
94 AVSS - Ground terminal
95 NC O Not used
96 VREF I Reference voltage (+3.3V) input terminal
97 AVCC - Power supply terminal (+3.3V)
98 to 100 NC O Not used
