Sony STR-DN1010 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DN1010
8383
D2016 8-719-049-09 DIODE 1SS367-T3SONY
D2017 8-719-049-09 DIODE 1SS367-T3SONY
D2018 8-719-049-09 DIODE 1SS367-T3SONY
D2019 6-501-817-01 DIODE MA2J1110GLS0
D2022 8-719-989-03 DIODE DAN222
D2023 8-719-989-03 DIODE DAN222
D2024 6-501-817-01 DIODE MA2J1110GLS0
D2025 8-719-989-03 DIODE DAN222
D2383 6-501-817-01 DIODE MA2J1110GLS0
< FERRITE BEAD >
FB2000 1-400-862-11 BEAD, FERRITE
FB2001 1-400-862-11 BEAD, FERRITE
FB2003 1-216-864-11 SHORT CHIP 0
FB2004 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB2005 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB2006 1-400-862-11 BEAD, FERRITE
FB2007 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB2008 1-400-862-11 BEAD, FERRITE
FB2009 1-400-862-11 BEAD, FERRITE
FB2010 1-400-862-11 BEAD, FERRITE
FB2011 1-400-862-11 BEAD, FERRITE
FB2012 1-400-862-11 BEAD, FERRITE
FB2013 1-216-797-11 METAL CHIP 10 5% 1/10W
FB2014 1-400-862-11 BEAD, FERRITE
FB2015 1-400-862-11 BEAD, FERRITE
* FB2016 1-400-973-21 INDUCTOR (EMI FERRITE)
FB2017 1-400-862-11 BEAD, FERRITE
FB2018 1-400-862-11 BEAD, FERRITE
FB2019 1-400-862-11 BEAD, FERRITE
* FB2020 1-400-973-21 INDUCTOR (EMI FERRITE)
FB2021 1-400-862-11 BEAD, FERRITE
FB2022 1-400-862-11 BEAD, FERRITE
FB2023 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB2024 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB2025 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB2027 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB2028 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB2029 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB2031 1-469-139-21 FERRITE, EMI (SMD) (2012)
< IC >
IC2000 6-708-742-01 IC MM1663DTRE
IC2001 6-713-032-01 IC KIA7809API-U/PF
IC2002 6-600-466-01 IC TORX147L (SONY) (DIGITAL (ASSIGNABLE)
OPTICAL SAT/CATV IN)
IC2003 6-600-466-01 IC TORX147L (SONY) (DIGITAL (ASSIGNABLE)
OPTICAL BD IN)
IC2004 6-600-466-01 IC TORX147L (SONY) (TV OPTICAL IN)
IC2005 6-712-613-01 IC SI-3010KM-TLS
IC2006 6-713-642-01 IC LC89058W-E
IC2007 8-759-524-48 IC TC74VHC393FT (EL)
IC2008 8-759-524-10 IC TC74VHC157FT (EL)
IC2009 8-759-447-77 IC TC7WH74FU (TE12R)
IC2010 6-705-337-01 IC TK11150CSCL-G
IC2011 8-759-523-81 IC TC74VHC08FT (EL)
IC2012 6-710-554-01 IC PCM1808PWR
IC2013 8-759-082-61 IC TC4W53FU
IC2015 8-759-096-87 IC TC7WU04FU (TE12R)
IC2016 6-712-614-01 IC SI-3050KM-TLS
IC2017 6-712-616-01 IC SI-3033KM-TLS
IC2018 A-1755-487-A IC MB91F467RAPMC-GE1 (for SERVICE)
IC2019 8-759-058-62 IC TC7S08FU (TE85R)
IC2020 6-702-913-01 IC S-80929CNMC-G8ZT2G
IC2021 8-759-277-63 IC TC7W14FU (TE12R)
IC2022 (Not supplied) IC CAT24C64WI-GT3
IC2023 6-707-870-01 IC TC74VHC157FT (EKJ)
IC2024 6-711-874-01 IC WM8768GEDS/R
IC2025 8-759-710-97 IC NJM4565M-D
IC2026 8-759-710-97 IC NJM4565M-D
IC2027 8-759-710-97 IC NJM4565M-D
IC2028 8-759-710-97 IC NJM4565M-D
IC2029 6-706-487-01 IC TC7SH08FU (T5RSOYJF) (US, CND)
IC2030 6-706-478-01 IC TC7SET08FU (T5RSOJF) (US, CND)
IC2031 6-706-478-01 IC TC7SET08FU (T5RSOJF) (US, CND)
IC2032 6-707-870-01 IC TC74VHC157FT (EKJ)
IC2033 6-709-861-01 IC TC7SH126FU (T5RSOYF)
IC2034 6-702-913-01 IC S-80929CNMC-G8ZT2G
IC2035 6-706-487-01 IC TC7SH08FU (T5RSOYJF)
< JACK >
J2000 1-784-431-11 JACK, PIN 1P
(DIGITAL (ASSIGNABLE) COAXIAL DVD IN)
< JUMPER RESISTOR >
JR2000 1-211-950-11 SHORT CHIP 0
JR2001 1-211-950-11 SHORT CHIP 0
JR2002 1-211-950-11 SHORT CHIP 0
JR2003 1-211-950-11 SHORT CHIP 0
JR2004 1-211-950-11 SHORT CHIP 0
JR2005 1-211-950-11 SHORT CHIP 0
JR2006 1-211-950-11 SHORT CHIP 0
JR2007 1-211-950-11 SHORT CHIP 0
JR2008 1-211-950-11 SHORT CHIP 0
JR2009 1-211-950-11 SHORT CHIP 0
JR2010 1-216-296-11 SHORT CHIP 0
< COIL >
L2000 1-469-555-21 INDUCTOR 10UH
< TRANSISTOR >
Q2000 6-551-690-01 TRANSISTOR RT3N11M-TP-1
Q2002 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q2003 6-551-272-01 TRANSISTOR RT3CLLM
Q2005 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R2002 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(UK, AUS, ECE)
R2002 1-216-864-11 SHORT CHIP 0 (US, CND)
R2003 1-216-841-11 METAL CHIP 47K 5% 1/10W
(UK, AUS, ECE)
R2004 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2005 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2006 1-216-817-11 METAL CHIP 470 5% 1/10W
R2007 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2008 1-216-809-11 METAL CHIP 100 5% 1/10W
R2009 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2010 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2011 1-216-833-11 METAL CHIP 10K 5% 1/10W
DIGITAL
Note: IC2022 cannot exchange with single. When this part is
damaged, exchange the entire mounted board.
