Sony STR-DN1010 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DN1010
9393
R5045 1-216-801-11 METAL CHIP 22 5% 1/10W
R5046 1-216-801-11 METAL CHIP 22 5% 1/10W
R5047 1-216-801-11 METAL CHIP 22 5% 1/10W
R5048 1-216-801-11 METAL CHIP 22 5% 1/10W
R5049 1-216-801-11 METAL CHIP 22 5% 1/10W
R5357 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5358 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5359 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5360 1-216-801-11 METAL CHIP 22 5% 1/10W
R5361 1-216-801-11 METAL CHIP 22 5% 1/10W
R5362 1-216-801-11 METAL CHIP 22 5% 1/10W
R5363 1-216-801-11 METAL CHIP 22 5% 1/10W
R5366 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5367 1-216-801-11 METAL CHIP 22 5% 1/10W
R5368 1-216-801-11 METAL CHIP 22 5% 1/10W
R5373 1-216-801-11 METAL CHIP 22 5% 1/10W
R5374 1-216-801-11 METAL CHIP 22 5% 1/10W
R5375 1-216-801-11 METAL CHIP 22 5% 1/10W
R5376 1-216-801-11 METAL CHIP 22 5% 1/10W
R5377 1-216-801-11 METAL CHIP 22 5% 1/10W
R5378 1-216-801-11 METAL CHIP 22 5% 1/10W
R5379 1-216-801-11 METAL CHIP 22 5% 1/10W
R5380 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5381 1-216-864-11 SHORT CHIP 0
R5382 1-216-864-11 SHORT CHIP 0
R5383 1-216-864-11 SHORT CHIP 0
R5384 1-216-864-11 SHORT CHIP 0
R5385 1-216-864-11 SHORT CHIP 0
R5386 1-216-864-11 SHORT CHIP 0
R5387 1-216-864-11 SHORT CHIP 0
R5388 1-218-946-11 METAL CHIP 270 5% 1/16W
R5389 1-218-946-11 METAL CHIP 270 5% 1/16W
R5390 1-218-946-11 METAL CHIP 270 5% 1/16W
R5391 1-218-946-11 METAL CHIP 270 5% 1/16W
R5392 1-218-946-11 METAL CHIP 270 5% 1/16W
R5393 1-218-946-11 METAL CHIP 270 5% 1/16W
R5394 1-218-946-11 METAL CHIP 270 5% 1/16W
R5395 1-218-946-11 METAL CHIP 270 5% 1/16W
R5396 1-218-946-11 METAL CHIP 270 5% 1/16W
R5397 1-218-946-11 METAL CHIP 270 5% 1/16W
R5398 1-218-946-11 METAL CHIP 270 5% 1/16W
R5399 1-218-946-11 METAL CHIP 270 5% 1/16W
R5400 1-218-946-11 METAL CHIP 270 5% 1/16W
R5401 1-218-946-11 METAL CHIP 270 5% 1/16W
R5402 1-218-946-11 METAL CHIP 270 5% 1/16W
R5403 1-218-946-11 METAL CHIP 270 5% 1/16W
R5404 1-218-946-11 METAL CHIP 270 5% 1/16W
R5405 1-218-946-11 METAL CHIP 270 5% 1/16W
R5406 1-218-946-11 METAL CHIP 270 5% 1/16W
R5407 1-218-946-11 METAL CHIP 270 5% 1/16W
R5408 1-218-946-11 METAL CHIP 270 5% 1/16W
R5409 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5410 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5411 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5414 1-216-833-11 METAL CHIP 10K 5% 1/10W
< COMPOSITION CIRCUIT BLOCK >
RB5001 1-200-051-21 RES, NETWORK 150 (1005X4)
RB5002 1-200-051-21 RES, NETWORK 150 (1005X4)
RB5003 1-200-051-21 RES, NETWORK 150 (1005X4)
RB5004 1-200-051-21 RES, NETWORK 150 (1005X4)
< VIBRATOR >
X5001 1-814-271-11 QUARTS CRYSTAL UNIT (25MHz)
************************************************************
HEADPHONE BOARD
*****************
< CONNECTOR >
* CNP300 1-564-507-11 PLUG, CONNECTOR 4P
< JACK >
J300 1-822-967-11 JACK (PHONES)
************************************************************
A-1755-465-A MAIN BOARD, COMPLETE (US, CND)
A-1755-500-A MAIN BOARD, COMPLETE (UK, AUS, ECE)
********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C401 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
C402 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
C403 1-126-943-11 ELECT 2200uF 20% 25V
C404 1-126-942-61 ELECT 1000uF 20% 25V
C406 1-137-958-91 MYLAR 0.22uF 5% 100V
C407 1-137-958-91 MYLAR 0.22uF 5% 100V
C408 1-109-932-15 ELECT (BLOCK) 10000uF 20% 71V
C409 1-109-932-15 ELECT (BLOCK) 10000uF 20% 71V
C412 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C413 1-112-084-11 ELECT 470uF 20% 16V
C414 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C415 1-112-084-11 ELECT 470uF 20% 16V
C441 1-112-100-11 ELECT 10uF 20% 50V
C502 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(UK, AUS, ECE)
C503 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(UK, AUS, ECE)
C504 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(UK, AUS, ECE)
C505 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(UK, AUS, ECE)
C506 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(UK, AUS, ECE)
C507 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(UK, AUS, ECE)
C508 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(UK, AUS, ECE)
C521 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(UK, AUS, ECE)
C522 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(UK, AUS, ECE)
C523 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(UK, AUS, ECE)
C524 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(UK, AUS, ECE)
C525 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(UK, AUS, ECE)
C526 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(UK, AUS, ECE)
HEADPHONE MAINDSP

Sony STR-DN1010 Specifications

General

Impedance	8 Ω
Audio output channels	7.1 channels
HDMI	Yes
Output power	200 W
Dimensions (WxDxH)	430 x 157.5 x 324.5 mm
Supported video modes	1080p
Product color	Black
Connectivity technology	Wired
Headphone outputs	1
Component video (YPbPr/YCbCr) in	3
