Sony STR-DN1010 - Main Board Parts List

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DN1010
9595
CN554 1-564-242-00 PIN, CONNECTOR (3.96mm PITCH) 5P
CN555 1-770-385-11 CONNECTOR, BOARD TO BOARD 18P
CN556 1-770-385-11 CONNECTOR, BOARD TO BOARD 18P
< ENCAPSULATED COMPONENT >
CP600 1-234-182-11 ENCAPSULATED COMPONENT 0.22
CP601 1-234-182-11 ENCAPSULATED COMPONENT 0.22
CP602 1-234-182-11 ENCAPSULATED COMPONENT 0.22
CP603 1-234-182-11 ENCAPSULATED COMPONENT 0.22
CP604 1-234-182-11 ENCAPSULATED COMPONENT 0.22
CP605 1-234-182-11 ENCAPSULATED COMPONENT 0.22
CP606 1-234-182-11 ENCAPSULATED COMPONENT 0.22
< DIODE >
D401 8-719-053-18 DIODE 1SR154-400TE-25
D402 8-719-053-18 DIODE 1SR154-400TE-25
D403 8-719-053-18 DIODE 1SR154-400TE-25
D404 8-719-053-18 DIODE 1SR154-400TE-25
D406 6-501-817-01 DIODE MA2J1110GLS0
D407 8-719-061-07 DIODE D5SBA60-F
D412 8-719-053-18 DIODE 1SR154-400TE-25
D422 6-501-817-01 DIODE MA2J1110GLS0
D423 6-501-817-01 DIODE MA2J1110GLS0
D424 6-501-817-01 DIODE MA2J1110GLS0
D425 6-501-817-01 DIODE MA2J1110GLS0
D451 6-501-817-01 DIODE MA2J1110GLS0
D581 6-500-335-01 DIODE MC2838-T112-1
D582 6-500-335-01 DIODE MC2838-T112-1
D600 6-501-817-01 DIODE MA2J1110GLS0
D601 6-501-817-01 DIODE MA2J1110GLS0
D602 6-501-817-01 DIODE MA2J1110GLS0
D603 6-501-817-01 DIODE MA2J1110GLS0
D604 6-501-817-01 DIODE MA2J1110GLS0
D605 6-501-817-01 DIODE MA2J1110GLS0
D606 6-501-817-01 DIODE MA2J1110GLS0
D607 6-501-817-01 DIODE MA2J1110GLS0
D608 6-501-817-01 DIODE MA2J1110GLS0
D609 6-501-817-01 DIODE MA2J1110GLS0
D610 6-501-817-01 DIODE MA2J1110GLS0
D611 6-501-817-01 DIODE MA2J1110GLS0
D612 6-501-817-01 DIODE MA2J1110GLS0
D613 6-501-817-01 DIODE MA2J1110GLS0
D614 6-501-734-01 DIODE MAZ8056GMLS0
D615 6-501-817-01 DIODE MA2J1110GLS0
< EARTH TERMINAL >
ET002 1-537-738-21 TERMINAL, GROUND
< FUSE >
0 F401 1-523-084-11 FUSE 2A 250V
0 F402 1-523-084-11 FUSE 2A 250V
0 F403 1-523-080-11 FUSE 6.3A 250V
0 F404 1-523-080-11 FUSE 6.3A 250V
< IC >
IC412 6-712-294-01 IC KIA7807API-U/PF
IC413
6-712-295-01 IC KIA7907PI
IC551 6-711-760-01 IC BD3471KS2
IC600 6-715-129-01 IC STK350-630T-E (US, CND)
IC600 6-715-227-01 IC HIC CXD9986L (UK, AUS, ECE)
IC601 6-715-129-01 IC STK350-630T-E (US, CND)
IC601 6-715-227-01 IC HIC CXD9986L (UK, AUS, ECE)
IC602 6-715-129-01 IC STK350-630T-E (US, CND)
IC602 6-715-227-01 IC HIC CXD9986L (UK, AUS, ECE)
IC603 6-715-129-01 IC STK350-630T-E (US, CND)
IC603 6-715-227-01 IC HIC CXD9986L (UK, AUS, ECE)
< JACK >
J521 1-774-411-11 JACK, PIN 6P
(SA-CD/CD/CD-R AUDIO OUT/IN, TV AUDIO IN)
J522 1-794-981-11 JACK, PIN 4P
(SAT/CATV AUDIO IN, BD AUDIO IN)
J523 1-794-981-11 JACK, PIN 4P (VIDEO 1 AUDIO OUT/IN)
J524 1-774-785-11 JACK, PIN 1P (SUBWOOFER AUDIO OUT)
< JUMPER RESISTOR >
JR1 1-216-864-11 SHORT CHIP 0
JR2 1-216-864-11 SHORT CHIP 0
JR3 1-216-864-11 SHORT CHIP 0
JR4 1-216-864-11 SHORT CHIP 0
JR755 1-216-864-11 SHORT CHIP 0 (US, CND)
JR756 1-216-864-11 SHORT CHIP 0 (US, CND)
JR757 1-216-864-11 SHORT CHIP 0 (US, CND)
JR758 1-216-864-11 SHORT CHIP 0 (US, CND)
JR759 1-216-864-11 SHORT CHIP 0 (US, CND)
JR760 1-216-864-11 SHORT CHIP 0 (US, CND)
JR761 1-216-864-11 SHORT CHIP 0 (US, CND)
< COIL >
L600 1-420-872-52 COIL, AIR-CORE
L601 1-420-872-52 COIL, AIR-CORE
L602 1-420-872-52 COIL, AIR-CORE
L603 1-420-872-52 COIL, AIR-CORE
L604 1-420-872-52 COIL, AIR-CORE
L605 1-420-872-52 COIL, AIR-CORE
L606 1-420-872-52 COIL, AIR-CORE
< TRANSISTOR >
Q406 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q422 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q423 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q424 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q425 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q441 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q451 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q581 6-550-327-01 TR 2SA1514KT146S
Q583 6-550-327-01 TR 2SA1514KT146S
Q585 8-729-271-31 TRANSISTOR 2SC2713-G
Q600 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q601 8-729-922-39 TRANSISTOR 2SD2144S-V
Q602 6-550-327-01 TR 2SA1514KT146S
Q603 6-550-327-01 TR 2SA1514KT146S
Q604 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q605 8-729-922-39 TRANSISTOR 2SD2144S-V
Q606 6-550-327-01 TR 2SA1514KT146S
Q607 6-550-327-01 TR 2SA1514KT146S
Q608 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q609 8-729-922-39 TRANSISTOR 2SD2144S-V
Q610 6-550-327-01 TR 2SA1514KT146S
Q611 6-550-327-01 TR 2SA1514KT146S
MAIN
