Note
When you use a 6.1-channel connection, place a surround back speaker directly behind the listening
position.
Hint
As the subwoofer does not emit highly directional signals, you can place it wherever you want.
[12] Preparation 1. Installing speakers
Installing 5.1.2-channel speaker system using top
middle speakers
You can enjoy vertical sound effects by connecting additional two top middle speakers.
30°
100° - 120°
Hint
As the subwoofer does not emit highly directional signals, you can place it wherever you want.
[13] Preparation 1. Installing speakers
Installing 5.1.2-channel speaker system using front
Dolby Atmos enabled speakers
You can enjoy vertical sound effects by connecting additional two front Dolby Atmos enabled
speakers.
