45
STR-K785
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DISPLAY
R1573 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1574 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1635 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1636 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
< VIBRATOR >
X1101 1-813-448-21 PIEZOELECTRIC OSCILLATOR (24MHz)
X1301 1-795-126-21 VIBRATOR, CRYSTAL (12.88MHz)
X1502 1-813-276-21 QUARTZ CRYSTAL (13.9MHz)
*************************************************************
A-1157-676-A DISPLAY BOARD, COMPLETE
***********************
< CAPACITOR >
C100 1-135-798-11 CERAMIC 0.22uF 50V
C101 1-135-798-11 CERAMIC 0.22uF 50V
C108 1-135-798-11 CERAMIC 0.22uF 50V
C109 1-135-798-11 CERAMIC 0.22uF 50V
C110 1-127-868-11 CERAMIC 2200PF 10% 50V
C111 1-162-282-31 CERAMIC 100PF 10% 50V
C112 1-162-282-31 CERAMIC 100PF 10% 50V
C114 1-135-798-11 CERAMIC 0.22uF 50V
C115 1-124-261-00 ELECT 10uF 20% 50V
C144 1-135-798-11 CERAMIC 0.22uF 50V
C150 1-135-798-11 CERAMIC 0.22uF 50V
C151 1-124-261-00 ELECT 10uF 20% 50V
C152 1-162-286-31 CERAMIC 220PF 10% 50V
C153 1-162-286-31 CERAMIC 220PF 10% 50V
C154 1-162-286-31 CERAMIC 220PF 10% 50V
C155 1-135-798-11 CERAMIC 0.22uF 50V
C156 1-135-798-11 CERAMIC 0.22uF 50V
C157 1-135-798-11 CERAMIC 0.22uF 50V
< CONNECTOR >
CNS100 1-784-780-11 CONNECTOR, FFC 19P
< FLUORESCENT INDICATOR TUBE >
FL101 1-518-966-11 VOCUUM FLUORESENT DISPLAYS
< IC >
IC100 8-759-643-83 IC uPD16315GB-3BS
IC101 8-759-243-51 IC TC74ACT08P
IC102 6-600-309-01 IC RPM7240-H9
< RESISTOR >
R101 1-249-409-11 CARBON 220 5% 1/4W
R102 1-249-411-11 CARBON 330 5% 1/4W
R103 1-249-413-11 CARBON 470 5% 1/4W
R104 1-249-415-11 CARBON 680 5% 1/4W
R105 1-247-831-91 CARBON 1K 5% 1/4W
R106 1-249-419-11 CARBON 1.5K 5% 1/4W
R107 1-249-421-11 CARBON 2.2K 5% 1/4W
R108 1-247-847-91 CARBON 4.7K 5% 1/4W
R111 1-249-409-11 CARBON 220 5% 1/4W
R112 1-249-411-11 CARBON 330 5% 1/4W
R113 1-249-413-11 CARBON 470 5% 1/4W
R114 1-249-415-11 CARBON 680 5% 1/4W
R116 1-249-419-11 CARBON 1.5K 5% 1/4W
R137 1-249-419-11 CARBON 1.5K 5% 1/4W
R138 1-249-421-11 CARBON 2.2K 5% 1/4W
R139 1-247-847-91 CARBON 4.7K 5% 1/4W
R150 1-249-440-11 CARBON 82K 5% 1/4W
R153 1-247-807-31 CARBON 100 5% 1/4W
R172 1-247-807-31 CARBON 100 5% 1/4W
R173 1-247-807-31 CARBON 100 5% 1/4W
R174 1-247-807-31 CARBON 100 5% 1/4W
R175 1-249-393-11 CARBON 10 5% 1/4W
R198 1-249-385-11 CARBON 2.2 5% 1/4W
R199 1-249-385-11 CARBON 2.2 5% 1/4W
< VARIABLE RESISTOR >
RV102 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
< SWITCH >
S100 1-771-410-21 SWITCH, TACTILE (INPUT MODE)
S101 1-771-410-21 SWITCH, TACTILE (>)
S102 1-771-410-21 SWITCH, TACTILE (u)
S103 1-771-410-21 SWITCH, TACTILE (U)
S104 1-771-410-21 SWITCH, TACTILE (<)
S105 1-771-410-21 SWITCH, TACTILE (FM)
S106 1-771-410-21 SWITCH, TACTILE (AM)
S107 1-771-410-21 SWITCH, TACTILE (AMP MENU)
S108 1-771-410-21 SWITCH, TACTILE (ENTER)
S110 1-771-410-21 SWITCH, TACTILE (MUSIC)
S111 1-771-410-21 SWITCH, TACTILE (MOVIE)
S112 1-771-410-21 SWITCH, TACTILE (A. F. D.)
S113 1-771-410-21 SWITCH, TACTILE (2CH)
S116 1-771-410-21 SWITCH, TACTILE (SA-CD/CD)
S137 1-771-410-21 SWITCH, TACTILE (VIDEO 1)
S138 1-771-410-21 SWITCH, TACTILE (VIDEO 2)
S139 1-771-410-21 SWITCH, TACTILE (DVD)
*************************************************************
HEADPHONE BOARD
*****************
< CONNECTOR >
CNP701 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
< JACK >
J700 1-815-314-21 JACK (PHONES)
*************************************************************
A-1274-494-A MAIN BOARD, COMPLETE (AUS, SP, SP6)
A-1317-964-A MAIN BOARD, COMPLETE (AEP)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C400 1-127-888-11 CERAMIC 0.1uF 10% 50V
C402 1-126-964-11 ELECT 10uF 20% 50V
C403 1-162-294-31 CERAMIC 0.001uF 10% 50V
C404 1-162-294-31 CERAMIC 0.001uF 10% 50V
C421 1-126-963-11 ELECT 4.7uF 20% 50V
DIGITAL
HEADPHONE MAIN
Ver. 1.2
