49
STR-K785
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R704 1-249-439-11 CARBON 68K 5% 1/4W
R705 1-249-421-11 CARBON 2.2K 5% 1/4W
R707 1-249-414-11 CARBON 560 5% 1/4W
0 R708 1-249-405-11 CARBON 100 5% 1/4W F
0 R709 1-249-405-11 CARBON 100 5% 1/4W F
0 R710 1-234-182-11 ENCAPSULATED COMPONENT F
R711 1-247-847-91 CARBON 4.7K 5% 1/4W
0 R712 1-240-855-81 CARBON 6.2K 5% 1/4W F
R713 1-249-419-11 CARBON 1.5K 5% 1/4W
R714 1-249-431-11 CARBON 15K 5% 1/4W
R715 1-247-863-91 CARBON 22K 5% 1/4W
R716 1-247-843-11 CARBON 3.3K 5% 1/4W
R717 1-249-431-11 CARBON 15K 5% 1/4W
R718 1-247-863-91 CARBON 22K 5% 1/4W
R719 1-247-863-91 CARBON 22K 5% 1/4W
R720 1-249-439-11 CARBON 68K 5% 1/4W
0 R721 1-249-393-11 CARBON 10 5% 1/4W F
R722 1-247-871-91 CARBON 47K 5% 1/4W
0 R724 1-249-404-00 CARBON 82 5% 1/4W F
R725 1-249-421-11 CARBON 2.2K 5% 1/4W
R729 1-247-871-91 CARBON 47K 5% 1/4W
R740 1-247-879-91 CARBON 100K 5% 1/4W
R752 1-247-873-91 CARBON 56K 5% 1/4W
R780 1-247-847-91 CARBON 4.7K 5% 1/4W
R782 1-247-879-91 CARBON 100K 5% 1/4W
R783 1-247-871-91 CARBON 47K 5% 1/4W
R791 1-249-421-11 CARBON 2.2K 5% 1/4W
0 R793 1-249-404-00 CARBON 82 5% 1/4W F
0 R802 1-249-409-11 CARBON 220 5% 1/4W F
0 R803 1-249-389-11 CARBON 4.7 5% 1/4W F
R804 1-249-429-11 CARBON 10K 5% 1/4W
R806 1-247-863-91 CARBON 22K 5% 1/4W
0 R815 1-249-381-11 CARBON 1 5% 1/4W F
0 R816 1-249-381-11 CARBON 1 5% 1/4W F
R840 1-249-427-11 CARBON 6.8K 5% 1/4W
R843 1-247-863-91 CARBON 22K 5% 1/4W
R844 1-247-863-91 CARBON 22K 5% 1/4W
R851 1-249-429-11 CARBON 10K 5% 1/4W
R852 1-249-429-11 CARBON 10K 5% 1/4W
R853 1-249-429-11 CARBON 10K 5% 1/4W
R854 1-249-435-11 CARBON 33K 5% 1/4W
R855 1-247-887-00 CARBON 220K 5% 1/4W
R856 1-247-895-00 CARBON 470K 5% 1/4W
R857 1-249-429-11 CARBON 10K 5% 1/4W
R858 1-215-889-00 METAL OXIDE 330 5% 2W
R859 1-216-453-00 METAL OXIDE 270 5% 2W
R881 1-247-871-91 CARBON 47K 5% 1/4W
R882 1-249-429-11 CARBON 10K 5% 1/4W
R883 1-249-427-11 CARBON 6.8K 5% 1/4W
R884 1-249-436-11 CARBON 39K 5% 1/4W
R885 1-247-831-91 CARBON 1K 5% 1/4W
0 R910 1-243-635-11 FUSIBLE 0.33 5% 1/2W F
< RESISTOR >
0 RR11 1-249-393-11 CARBON 10 5% 1/4W F
0 RR12 1-249-393-11 CARBON 10 5% 1/4W F
0 RR13 1-249-393-11 CARBON 10 5% 1/4W F
0 RR14 1-249-393-11 CARBON 10 5% 1/4W F
0 RR15 1-249-393-11 CARBON 10 5% 1/4W F
< RELAY >
RY501 1-755-421-11 RELAY
RY502 1-755-421-11 RELAY
RY601 1-755-421-11 RELAY
RY701 1-755-421-11 RELAY
RY702 1-755-267-11 RELAY
< TERMINAL >
TM600 1-694-805-11 TERMINAL BOARD
(SPEAKERS / CENTER, FRONT)
TM602 1-694-785-11 TERMINAL BOARD (SPEAKERS / SURROUND)
*************************************************************
POWER BOARD
*************
< RESISTOR >
R115 1-247-831-91 CARBON 1K 5% 1/4W
< SWITCH >
S114 1-771-410-21 SWITCH, TACTILE (DISPLAY)
S115 1-771-410-21 SWITCH, TACTILE (DIMMER)
S152 1-771-410-21 SWITCH, TACTILE (?/1)
*************************************************************
A-1157-640-A STANDBY BOARD, COMPLETE
************************
FH902 1-533-217-41 HOLDER, FUSE
FH952 1-533-217-41 HOLDER, FUSE
< CAPACITOR >
C901 1-135-798-11 CERAMIC 0.22uF 50V
C902 1-135-798-11 CERAMIC 0.22uF 50V
C911 1-135-798-11 CERAMIC 0.22uF 50V
C912 1-135-798-11 CERAMIC 0.22uF 50V
C913 1-126-959-11 ELECT 0.47uF 20% 50V
C914 1-126-936-11 ELECT 3300uF 20% 16V
C915 1-126-943-11 ELECT 2200uF 20% 25V
C916 1-126-942-61 ELECT 1000uF 20% 25V
< CONNECTOR >
CNP801 1-784-922-11 PIN, CONNECTOR 5P
CNP900 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CNP903 1-564-506-11 PLUG, CONNECTOR 3P
CNP904 1-794-577-21 PIN, CONNECTOR (POWER)
CNP906 1-766-203-11 PLUG, CONNECTOR PIN (PC BOARD) 5P
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-77
D910 6-500-522-11 DIODE 10EDB40-TA2B5
D911 6-500-522-11 DIODE 10EDB40-TA2B5
D912 6-500-522-11 DIODE 10EDB40-TA2B5
D913 6-500-522-11 DIODE 10EDB40-TA2B5
D914 8-719-991-33 DIODE 1SS133T-77
D915 8-719-991-33 DIODE 1SS133T-77
D920 6-500-522-11 DIODE 10EDB40-TA2B5
D921 6-500-522-11 DIODE 10EDB40-TA2B5
D922 6-500-522-11 DIODE 10EDB40-TA2B5
