Ref. No. Part No. Description Remark
STR-KM5/KM7
82
* R4189 1-250-507-11 METAL CHIP 3.3K 1% 1/16W
(EXCEPT SAF, AR)
R4190 1-218-965-11 METAL CHIP 10K 5% 1/16W
(EXCEPT SAF, AR)
R4193 1-218-941-81 METAL CHIP 100 5% 1/16W
(EXCEPT SAF, AR)
VD4170 1-811-155-11 ELEMENT, ESD PROTECT (EXCEPT SAF, AR)
VD4171 1-811-155-11 ELEMENT, ESD PROTECT (EXCEPT SAF, AR)
< VIBRATOR >
X4102 1-814-482-11 QUARTZ CRYSTAL UNIT (16.9344MHz)
(EXCEPT SAF, AR)
************************************************************
MISCELLANEOUS
**************
55 1-828-341-61 WIRE (FLAT TYPE) (15 CORE)
101 1-828-368-61 WIRE (FLAT TYPE) (21 CORE)
104 1-828-310-61 WIRE (FLAT TYPE) (9 CORE)
105 A-1846-561-A TUNER1AMPR ASSY (EXCEPT KM5: US)
105 A-1846-564-A TUNER1AMF ASSY (KM5: US)
0 109 1-777-071-83 CORD, POWER
(KM5: E51, SAF, E12/KM7: SAF, SP)
0 109 1-833-566-21 POWER-SUPPLY CORD (KM7: AUS)
0 109 1-834-288-21 CORD, POWER (KM5: TH)
0 109 1-835-078-31 CORD, POWER (EA)
0 109 1-837-308-11 CORD, POWER-SUPPLY (KM5: US)
0 109 1-837-312-11 CORD, POWER-SUPPLY (AR)
0 110 1-785-504-21 ADAPTOR, CONVERSION (KM5: E51)
0 F901 1-532-504-33 FUSE (T4AL/250V) (EXCEPT KM5: US)
0 F901 1-533-311-12 FUSE, GLASS (DIA.5) (8A/125V) (KM5: US)
0 F902 1-532-506-33 FUSE (T6.3AL/250V) (KM5: E51, EA/KM7: EA)
0 F954 1-533-949-33 FUSE (T8AL/250V)
0 F955 1-533-949-33 FUSE (T8AL/250V)
0 M1 1-855-006-11 FAN, DC
0 M2 1-787-955-21 DC FAN
Q403 6-702-390-01 TRANSISTOR MN2488-OPY-MK (KM7)
Q404 6-702-391-01 TRANSISTOR MP1620-OPY-MK (KM7)
Q453 6-702-390-01 TRANSISTOR MN2488-OPY-MK (KM7)
Q454 6-702-391-01 TRANSISTOR MP1620-OPY-MK (KM7)
Q502 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q503 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q552 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q553 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q602 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q603 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q652 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q653 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q702 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q703 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q752 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q753 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q802 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q803 6-702-391-01 TRANSISTOR MP1620-OPY-MK
0 T901 1-697-213-11 POWER TRANSFORMER (MAIN)
(KM5: E51, EA/KM7: EA)
0 T901 1-697-214-11 POWER TRANSFORMER (MAIN)
(KM5: EXCEPT US, E51, EA/KM7: EXCEPT EA)
0 T901 1-697-318-11 POWER TRANSFORMER (MAIN) (KM5: US)
Ver. 1.5
Note: If wire (fl at type) is replaced, install it after bending it in the
same form as that before replacement.
