48
GB
Additional Information
FM tuner section
Tuning range 87.5 - 108.0 MHz
Antenna terminals
75 ohms, unbalanced
Sensitivity Mono: 18.3 dBf, 2.2 µV/
75 ohms
Stereo: 38.3 dBf, 22.5
µV/75 ohms
Usable sensitivity
11.2 dBf, 1 µV/75 ohms
S/N Mono: 76 dB
Stereo: 70 dB
Harmonic distortion at 1 kHz
Mono: 0.3%
Stereo: 0.5%
Separation 45 dB at 1 kHz
Frequency response
30 Hz - 15 kHz +0.5/–2
dB
Selectivity 60 dB at 400 kHz
AM tuner section
Tuning range Australia, Singapore and
Malaysia models:
531 - 1602 kHz (9 kHz
step)
Canada model:
530 - 1710 kHz (10 kHz
step)
c)
531 - 1710 kHz (9 kHz
step)
c)
Other countries models:
530 - 1610 kHz (10 kHz
step)
c)
531 - 1602 kHz (9 kHz
step)
c)
Antenna Loop antenna
Usable sensitivity
50 dB/m (at 999 kHz)
S/N 54 dB (at 50 mV/m)
Harmonic distortion
0.5 % (50 mV/m, 400
kHz)
Selectivity At 9 kHz: 35 dB
c) You can change the AM tuning interval to 9
kHz. After tuning in any AM station, turn
off the receiver. Hold down the TUNING +
button and press the ?/1 button. All preset
stations will be erased when you change the
tuning interval. To reset the scale to 10 kHz,
repeat the procedure.
Video section
Inputs Video: 1 Vp-p 75 ohms
S-video*:
Y: 1 Vp-p 75 ohms
C: 0.286 Vp-p 75 ohms
Outputs Video: 1 Vp-p 75 ohms
S-video*:
Y: 1 Vp-p 75 ohms
C: 0.286 Vp-p 75 ohms
* STR-DE545 and STR-SE501 only.
General
System Tuner section:
PLL quartz-locked
digital synthesizer
system
Preamplifier section:
Low-noise NF type
equalizer
Power amplifier section:
Pure-complementary
SEPP
Power requirements
Canada model: 120 V
AC, 60 Hz
Australia model: 240 V
AC, 50 Hz
Singapore and Malaysia
models: 220 - 230 V
AC, 50/60 Hz
Power consumption
Canada model:
STR-DE545 : 310 VA
STR-DE445 : 280 VA
Australia, Singapore and
Malaysia models:
STR-DE545/SE501 :
220 W
Other countries:
STR-DE545/SE501:
265 W
AC outlets (STR-DE545 and STR-SE501
only)
1 switched, max 100 W
Dimensions 430 × 303 × 157 mm
including projecting
parts and controls
Mass (Approx.)
Canada model:
STR-DE545: 7.9 kg
STR-DE445: 7.7 kg
Australia model:
STR-DE545: 7.9 kg
STR-SE501: 8.2 kg
Singapore and Malaysia
models:
STR-DE545: 7.9 kg
STR-SE501: 8.2 kg
Other countries:
STR-DE545/SE501:
8.0 kg
Supplied accessories
See page 4.
The specification measured is under
• 230 AC 50 Hz condition (Singapore
and Malaysia models)
• 240 AC 50 Hz condition (Australia
model).
Design and specifications are subject to
change without notice.
