Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 38 —
R954 1-249-437-11 CARBON 47K 5% 1/4W
R956 1-249-429-11 CARBON 10K 5% 1/4W
R957 1-249-429-11 CARBON 10K 5% 1/4W
R958 1-249-429-11 CARBON 10K 5% 1/4W
R959 1-249-429-11 CARBON 10K 5% 1/4W
R960 1-249-397-11 CARBON 22 5% 1/4W F
R961 1-249-397-11 CARBON 22 5% 1/4W F
R963 1-249-417-11 CARBON 1K 5% 1/4W F
R964 1-249-431-11 CARBON 15K 5% 1/4W
R965 1-249-441-11 CARBON 100K 5% 1/4W
! R970 1-217-156-00 WIREWOUND 0.22 10% 5W F
! R974 1-212-849-00 FUSIBLE 4.7 5% 1/4W F
************************************************************
* 1-666-060-11 AVIN BOARD
**********
< CAPACITOR >
C6301 1-162-286-31 CERAMIC 220PF 10% 50V
C6302 1-162-286-31 CERAMIC 220PF 10% 50V
C6303 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN6301 1-564-524-11 PLUG, CONNECTOR 9P
< DIODE >
D6300 8-719-987-63 DIODE 1N4148M
< JACK >
J6301 1-779-583-11 JACK, PIN 3P (AV INPUT)
< RESISTOR >
R6301 1-249-417-11 CARBON 1K 5% 1/4W F
R6302 1-249-417-11 CARBON 1K 5% 1/4W F
R6303 1-249-441-11 CARBON 100K 5% 1/4W
R6304 1-249-441-11 CARBON 100K 5% 1/4W
< RELAY >
RY6300 1-515-622-11 RELAY
************************************************************
* A-4398-446-A MAIN BAORD,COMPLETE(E,EA3,SP,MY,HK,
********************* TW,AR,AUS,JE)
* A-4398-447-A MAIN BAORD, COMPLETE (AEP,UK)
*********************
* A-4398-448-A MAIN BAORD, COMPLETE (EE,CIS)
*********************
* A-4398-449-A MAIN BAORD, COMPLETE (CND)
*********************
* A-4403-304-A MAIN BAORD, COMPLETE (EA4, TH)
*********************
* A-4403-316-A MAIN BOARD, COMPLETE (IA)
*********************
< CAPACITOR >
C101 1-136-167-00 FILM 0.15uF 5% 50V
C102 1-130-471-00 MYLAR 0.001uF 5% 50V
C103 1-136-169-00 FILM 0.22uF 5% 50V
C104 1-136-169-00 FILM 0.22uF 5% 50V
C105 1-137-375-11 FILM 0.068uF 5% 50V
C106 1-137-375-11 FILM 0.068uF 5% 50V
C107 1-137-440-11 FILM 0.018uF 5% 50V
C108 1-137-440-11 FILM 0.018uF 5% 50V
C109 1-137-437-11 FILM 0.0056uF 5% 50V
C110 1-130-479-00 MYLAR 0.0047uF 5% 50V
C111 1-130-479-00 MYLAR 0.0047uF 5% 50V
C112 1-126-964-11 ELECT 10uF 20% 50V
C113 1-126-963-11 ELECT 4.7uF 20% 50V
C114 1-136-166-00 FILM 0.12uF 5% 50V
C115 1-136-166-00 FILM 0.12uF 5% 50V
C116 1-126-961-11 ELECT 2.2uF 20% 50V
C117 1-162-306-11 CERAMIC 0.01uF 20% 16V
C118 1-126-964-11 ELECT 10uF 20% 50V
C120 1-126-959-11 ELECT 0.47uF 20% 50V
C123 1-126-963-11 ELECT 4.7uF 20% 50V
C129 1-162-294-31 CERAMIC 0.001uF 10% 50V
C130 1-164-159-11 CERAMIC 0.1uF 50V
C140 1-162-306-11 CERAMIC 0.01uF 20% 16V
C153 1-136-169-00 FILM 0.22uF 5% 50V
C154 1-136-169-00 FILM 0.22uF 5% 50V
C155 1-137-375-11 FILM 0.068uF 5% 50V
C156 1-137-375-11 FILM 0.068uF 5% 50V
C157 1-137-440-11 FILM 0.018uF 5% 50V
C158 1-137-440-11 FILM 0.018uF 5% 50V
C159 1-137-437-11 FILM 0.0056uF 5% 50V
C160 1-130-479-00 MYLAR 0.0047uF 5% 50V
C161 1-130-479-00 MYLAR 0.0047uF 5% 50V
C162 1-126-964-11 ELECT 10uF 20% 50V
C163 1-126-963-11 ELECT 4.7uF 20% 50V
C164 1-136-166-00 FILM 0.12uF 5% 50V
C165 1-136-166-00 FILM 0.12uF 5% 50V
C166 1-126-961-11 ELECT 2.2uF 20% 50V
C177 1-162-306-11 CERAMIC 0.01uF 20% 16V
C181 1-162-215-31 CERAMIC 47PF 5% 50V
C182 1-126-960-11 ELECT 1uF 20% 50V
C183 1-126-961-11 ELECT 2.2uF 20% 50V
C188 1-126-964-11 ELECT 10uF 20% 50V
C701 1-162-286-31 CERAMIC 220PF 10% 50V
(AEP,UK)
C702 1-162-286-31 CERAMIC 220PF 10% 50V
(AEP,UK)
C703 1-126-963-11 ELECT 4.7uF 20% 50V
C731 1-126-964-11 ELECT 10uF 20% 50V
C732 1-126-964-11 ELECT 10uF 20% 50V
C751 1-162-286-31 CERAMIC 220PF 10% 50V
(AEP,UK)
C752 1-162-286-31 CERAMIC 220PF 10% 50V
(AEP,UK)
C753 1-126-963-11 ELECT 4.7uF 20% 50V
C801 1-136-165-00 FILM 0.1uF 5% 50V
C802 1-136-165-00 FILM 0.1uF 5% 50V
C803 1-104-482-11 ELECT 4700uF 20% 63V
C804 1-104-482-11 ELECT 4700uF 20% 63V
C807 1-126-964-11 ELECT 10uF 20% 50V
C808 1-126-948-11 ELECT 100uF 20% 35V
C831 1-126-942-61 ELECT 1000uF 20% 25V
C832 1-126-942-61 ELECT 1000uF 20% 25V
C835 1-136-165-00 FILM 0.1uF 5% 50V
C836 1-136-165-00 FILM 0.1uF 5% 50V
AMP AVIN MAIN
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
