Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 39 —
C852 1-126-923-11 ELECT 220uF 20% 10V
C853 1-126-933-11 ELECT 100uF 20% 10V
C858 1-104-664-11 ELECT 47uF 20% 25V
C859 1-126-961-11 ELECT 2.2uF 20% 50V
C861 1-164-159-11 CERAMIC 0.1uF 50V
C921 1-137-375-11 FILM 0.068uF 5% 50V
C922 1-137-375-11 FILM 0.068uF 5% 50V
C971 1-137-375-11 FILM 0.068uF 5% 50V
C972 1-137-375-11 FILM 0.068uF 5% 50V
< CONNECTOR >
CN103 1-774-289-11 PIN, CONNECTOR (PC BOARD) 15P
CN105 1-774-336-11 SOCKET, CONNECTOR(PC BOARD)14P
CN106 1-774-336-11 SOCKET, CONNECTOR(PC BOARD)14P
* CN6002 1-568-937-11 PIN, CONNECTOR 10P
* CNP701 1-764-017-21 HOUSING,CONNECTOR(PC BOARD)17P
< DIODE >
D101 8-719-987-63 DIODE 1N4148M
D102 8-719-987-63 DIODE 1N4148M
D702 8-719-200-82 DIODE 11ES2
D801 8-719-302-38 DIODE RBV-602-01
D804 8-719-934-22 DIODE HZS30-2L
D809 8-719-987-63 DIODE 1N4148M
D810 8-719-987-63 DIODE 1N4148M
D821 8-719-987-63 DIODE 1N4148M
D824 8-719-200-82 DIODE 11ES2
D831 8-719-200-82 DIODE 11ES2
D832 8-719-200-82 DIODE 11ES2
D833 8-719-200-82 DIODE 11ES2
D834 8-719-200-82 DIODE 11ES2
D840 8-719-987-63 DIODE 1N4148M
D841 8-719-987-63 DIODE 1N4148M
D844 8-719-200-82 DIODE 11ES2
D852 8-719-987-63 DIODE 1N4148M
D1021 8-719-987-63 DIODE 1N4148M
< TERMINAL >
* E801 1-537-738-21 TERMINAL, EARTH
< IC >
IC101 8-759-634-50 IC M5218AL
IC105 8-759-460-02 IC M62427FP-A
IC701 8-759-000-47 IC MC14051BCP
IC751 8-759-000-47 IC MC14051BCP
IC850 8-759-111-68 IC UPC1237HA
< JACK >
J701 1-770-614-11 JACK, PIN 4P (MD/VIDEO) (EXCEPT EE,CIS)
J701 1-770-613-11 JACK, PIN 4P (MD/VIDEO) (EE,CIS)
J901 1-779-379-11 JACK, PIN 2P (SUPER WOOFER/MONITOR)
< COIL >
L921 1-420-872-00 COIL, AIR-CORE (AEP,UK)
L971 1-420-872-00 COIL, AIR-CORE (AEP,UK)
< TRANSISTOR >
Q111 8-729-119-78 TRANSISTOR 2SC403SP-51
Q112 8-729-119-78 TRANSISTOR 2SC403SP-51
Q161 8-729-119-78 TRANSISTOR 2SC403SP-51
Q162 8-729-119-78 TRANSISTOR 2SC403SP-51
Q190 8-729-900-63 TRANSISTOR DTA124ES
Q191 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q192 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q801 8-729-141-83 TRANSISTOR 2SB1094-LK
Q810 8-729-900-36 TRANSISTOR DTC124ES
Q856 8-729-900-36 TRANSISTOR DTC124ES
Q857 8-729-900-63 TRANSISTOR DTA124ES
Q2100 8-729-141-26 TRANSISTOR 2SC3622A-LK
< RESISTOR >
R101 1-249-429-11 CARBON 10K 5% 1/4W
R102 1-249-429-11 CARBON 10K 5% 1/4W
R103 1-249-429-11 CARBON 10K 5% 1/4W
R104 1-249-429-11 CARBON 10K 5% 1/4W
R105 1-249-429-11 CARBON 10K 5% 1/4W
R108 1-247-897-00 CARBON 560K 5% 1/4W
R109 1-249-419-11 CARBON 1.5K 5% 1/4W F
R110 1-249-433-11 CARBON 22K 5% 1/4W
R111 1-249-441-11 CARBON 100K 5% 1/4W
R112 1-249-421-11 CARBON 2.2K 5% 1/4W F
R113 1-249-441-11 CARBON 100K 5% 1/4W
R115 1-249-439-11 CARBON 68K 5% 1/4W
R116 1-249-437-11 CARBON 47K 5% 1/4W
R117 1-247-903-00 CARBON 1M 5% 1/4W
R118 1-249-417-11 CARBON 1K 5% 1/4W F
R119 1-249-433-11 CARBON 22K 5% 1/4W
R120 1-249-437-11 CARBON 47K 5% 1/4W
R122 1-247-903-00 CARBON 1M 5% 1/4W
R123 1-249-431-11 CARBON 15K 5% 1/4W
R124 1-249-437-11 CARBON 47K 5% 1/4W
R125 1-247-807-31 CARBON 100 5% 1/4W
R126 1-249-429-11 CARBON 10K 5% 1/4W
R129 1-247-887-00 CARBON 220K 5% 1/4W
R135 1-247-807-31 CARBON 100 5% 1/4W
(AEP,UK)
R136 1-247-807-31 CARBON 100 5% 1/4W
(AEP,UK)
R137 1-247-807-31 CARBON 100 5% 1/4W
R138 1-247-807-31 CARBON 100 5% 1/4W
R139 1-247-807-31 CARBON 100 5% 1/4W
R140 1-247-807-31 CARBON 100 5% 1/4W
R141 1-247-807-31 CARBON 100 5% 1/4W
R142 1-247-807-31 CARBON 100 5% 1/4W
R143 1-247-807-31 CARBON 100 5% 1/4W
R144 1-247-807-31 CARBON 100 5% 1/4W
R145 1-247-807-31 CARBON 100 5% 1/4W
R146 1-247-807-31 CARBON 100 5% 1/4W
R147 1-247-807-31 CARBON 100 5% 1/4W
R151 1-249-429-11 CARBON 10K 5% 1/4W
R152 1-249-429-11 CARBON 10K 5% 1/4W
R153 1-249-429-11 CARBON 10K 5% 1/4W
R154 1-249-429-11 CARBON 10K 5% 1/4W
MAIN
