Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 40 —
R155 1-249-429-11 CARBON 10K 5% 1/4W
R156 1-249-429-11 CARBON 10K 5% 1/4W
R158 1-247-897-00 CARBON 560K 5% 1/4W
R159 1-249-419-11 CARBON 1.5K 5% 1/4W F
R160 1-249-433-11 CARBON 22K 5% 1/4W
R161 1-249-441-11 CARBON 100K 5% 1/4W
R162 1-249-421-11 CARBON 2.2K 5% 1/4W F
R163 1-249-441-11 CARBON 100K 5% 1/4W
R165 1-249-439-11 CARBON 68K 5% 1/4W
R167 1-249-441-11 CARBON 100K 5% 1/4W
R172 1-247-903-00 CARBON 1M 5% 1/4W
R173 1-249-431-11 CARBON 15K 5% 1/4W
R174 1-249-437-11 CARBON 47K 5% 1/4W
R176 1-249-429-11 CARBON 10K 5% 1/4W
R177 1-249-437-11 CARBON 47K 5% 1/4W
R178 1-249-433-11 CARBON 22K 5% 1/4W
R181 1-247-895-00 CARBON 470K 5% 1/4W
R182 1-247-895-00 CARBON 470K 5% 1/4W
R183 1-249-435-11 CARBON 33K 5% 1/4W
R184 1-249-425-11 CARBON 4.7K 5% 1/4W F
R185 1-249-417-11 CARBON 1K 5% 1/4W F
R186 1-249-425-11 CARBON 4.7K 5% 1/4W F
R187 1-249-441-11 CARBON 100K 5% 1/4W
R188 1-249-417-11 CARBON 1K 5% 1/4W F
R190 1-249-441-11 CARBON 100K 5% 1/4W
R192 1-249-425-11 CARBON 4.7K 5% 1/4W F
R195 1-249-425-11 CARBON 4.7K 5% 1/4W F
R196 1-247-807-31 CARBON 100 5% 1/4W
R702 1-249-425-11 CARBON 4.7K 5% 1/4W F
R703 1-249-425-11 CARBON 4.7K 5% 1/4W F
R704 1-249-417-11 CARBON 1K 5% 1/4W F
R705 1-249-441-11 CARBON 100K 5% 1/4W
R707 1-249-441-11 CARBON 100K 5% 1/4W
R708 1-249-417-11 CARBON 1K 5% 1/4W F
R710 1-249-417-11 CARBON 1K 5% 1/4W F
R752 1-249-425-11 CARBON 4.7K 5% 1/4W F
R753 1-249-425-11 CARBON 4.7K 5% 1/4W F
R754 1-249-417-11 CARBON 1K 5% 1/4W F
R755 1-249-441-11 CARBON 100K 5% 1/4W
R757 1-249-441-11 CARBON 100K 5% 1/4W
R758 1-249-417-11 CARBON 1K 5% 1/4W F
R759 1-249-417-11 CARBON 1K 5% 1/4W F
R760 1-249-417-11 CARBON 1K 5% 1/4W F
R762 1-249-417-11 CARBON 1K 5% 1/4W F
! R801 1-212-982-00 FUSIBLE 100 5% 1/2W F
R804 1-249-429-11 CARBON 10K 5% 1/4W
R818 1-249-427-11 CARBON 6.8K 5% 1/4W F
R819 1-249-427-11 CARBON 6.8K 5% 1/4W F
R840 1-249-429-11 CARBON 10K 5% 1/4W
R851 1-249-431-11 CARBON 15K 5% 1/4W
R853 1-249-397-11 CARBON 22 5% 1/4W F
R854 1-249-441-11 CARBON 100K 5% 1/4W
R856 1-249-429-11 CARBON 10K 5% 1/4W
R857 1-249-435-11 CARBON 33K 5% 1/4W
R858 1-249-437-11 CARBON 47K 5% 1/4W
R859 1-249-439-11 CARBON 68K 5% 1/4W
! R870 1-215-892-11 METAL OXIDE 1K 5% 2W F
(EXCEPT CND)
! R870 1-215-893-11 METAL OXIDE 1.5K 5% 2W F
(CND)
R921 1-249-397-11 CARBON 22 5% 1/4W F
(AEP,UK)
R922 1-249-397-11 CARBON 22 5% 1/4W F
(AEP,UK)
R944 1-249-417-11 CARBON 1K 5% 1/4W F
R971 1-249-397-11 CARBON 22 5% 1/4W F
(AEP,UK)
R972 1-249-397-11 CARBON 22 5% 1/4W F
(AEP,UK)
R1002 1-249-429-11 CARBON 10K 5% 1/4W
R1020 1-249-425-11 CARBON 4.7K 5% 1/4W F
R1021 1-249-417-11 CARBON 1K 5% 1/4W F
< RELAY >
RY801 1-515-920-11 RELAY (24V)
< TERMINAL >
TB901 1-537-801-11 TERMINAL BOARD FRONT SREAKER (AEP,UK)
TB901 1-537-240-31 TERMINAL BOARD FRONT SREAKER
(CHECKER PIN) (EXCEPT AEP,UK)
************************************************************
* 1-666-062-11 JOG BOARD
*********
< DIODE >
D512 8-719-046-44 DIODE SEL5221S
D513 8-719-046-44 DIODE SEL5221S
D514 8-719-046-44 DIODE SEL5221S
< RESISTOR >
R537 1-249-407-11 CARBON 150 5% 1/4W F
R538 1-249-401-11 CARBON 47 5% 1/4W F
R541 1-249-419-11 CARBON 1.5K 5% 1/4W F
R644 1-249-429-11 CARBON 10K 5% 1/4W
R645 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S534 1-762-751-11 SWITCH, TACTILE (ENTER/NEXT)
S536 1-762-874-11 SWITCH, JOG (MULTI JOG STATION)
************************************************************
* 1-666-057-11 MIC ECHO BOARD
**************
< CAPACITOR >
C6001 1-162-306-11 CERAMIC 0.01uF 20% 16V
C6003 1-124-257-00 ELECT 2.2uF 20% 50V
C6005 1-162-215-31 CERAMIC 47PF 5% 50V
C6006 1-162-290-31 CERAMIC 470PF 10% 50V
C6023 1-162-215-31 CERAMIC 47PF 5% 50V
MAIN JOG
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
MIC ECHO
