Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R156 = 1-259-167-21 CARBON 1K 65% ~~ /4W < CAPACITOR >
R157 = 1-124-995-11 CARBON IM =e /AW
R158 1-259-167-21 CARBON 1K «65% ~~ /4W C201 1-104-290-11 POLYSTYRENE 330PF 5% 50V
C202 1-130-973-00 FILM 0. 022uF 2% 100V
R159 = 1-124-995-11 CARBON IM 65% ~~ 1/4W C203 =1-130-341-00 FILM 0. 056uF 2% 100V
R168 1-259-143-21 CARBON 100 5% 8 1/4W C204 1-130-971-00 FILM 0. 016uF 2% 100V
Ri69 1-124-995-11 CARBON iM 65%) /4W (205 1-124-929-11 ELECT 22uF 20% 100V (FASES)
R170 =1-124-995-11 CARBON IM 5% ~~ 1/4W
R171 =1-124-995-11 CARBON IM 865% = 1 /4W C205 1-110-390-11 ELECT 22uF 20% 63V (FATES)
C206 1-124-929-11 ELECT 22uF 20% 100V (FASES)
R172 1-249-226-11 CARBON 4.7K 5% 1/3W C206 = 1-110-390-11 ELECT 22uF 20% 63V (FATES)
R173 1-249-194-11 CARBON 220 5% 1/3W C207 =1-124-929-11 ELECT 22uF 20% 100V (FASES)
C207 =1-110-390-11 ELECT 22uF 20% 63V (FATES)
< RELAY >
(251 1-104-290-11 POLYSTYRENE 330PF 5% 50V
RY101 1-755-060-1141 RELAY C252 =1-130-973-00 FILM 0. 022uF 2% 100V
RY102 1-755-060-11 RELAY C253 = 1-130-341-00 FILM 0. 056uF 2% 100V
RY103 1-755-060-11 RELAY C254 1-130-971-00 FILM 0. 016uF 2% 100V
RY104 1-755-060~11 RELAY €255 1-124-929-11 ELECT 22uF 20% 100V (FASES)
RY105 1-755-060-11 RELAY
C255 1-110-390-11 ELECT 22uF 20% 63V (FATES)
RY106 1-755-060-11 RELAY C256 =1-124-929-11 ELECT 22uF 20% 100V (FASES)
RYi07 1-755-060-1141 RELAY C256 =1-110-390-11 ELECT 22uF 20% 63V (FATES)
RY108 1-755-Q60-11 RELAY C257 = 1-124-929-11 ELECT 22uF 20% 100V (FA5ES)
RY109 1-755-060-11 RELAY C257 = 1-110-390-11 ELECT 22uF 20% 63V (FATES)
RY110 1-755-060-11 RELAY
C401 1-104-274-11 POLYSTYRENE 47PF 10% 50V_ (FASES)
RY111 1-755-060-11 RELAY C401 1-104-322-11 POLYSTYRENE 47PF 10% 400V (FATES)
C402 =1-136-810-11 FILM 220PF a” 100V
< SWITCH > C405 =1-126-025-11 ELECT 330uF 20% 25V
C406 = =1-126-025-11 ELECT § 330uF 20% 25V
$101 1-570-076-11 SWITCH, SLIDE (REMOTE TYPE)
(REC OUT SELECTOR) 0408 1-110-390-11 ELECT 22uF 20% 63V
$102 1-762-181-11 SWITCH, SLIDE (AUX INPUT) (FA7ES) C409 = 1-110-512-11 FILM luF 10% 50V_ (FATES)
C410 1-104-274-11 POLYSTYRENE 47PF 10% 50V_ (FASES)
< BRACKET > C410 1-104-322-11 POLYSTYRENE 47PF 10% 400V (FA7ES)
C411 =1-126-025-11 ELECT 330uF 20% 25V
* YB101 4-946-336-01 BRACKET (GROUND)
SE OIGGO OIG GOOG IO IOI GE AIR A rok kok C412 1-126-025-11 ELECT 330uF 20% 25V
C413 = 1-110-390-11 ELECT 22uF 20% 63V
* 1-655-361-11 JUMPER BOARD (FA5ES) 0418 = 1-110-397-11 ELECT 1000uF 20% 63V
* 1-655-361-21 JUMPER BOARD (FA7ES) C419 = 1-110-397-11 ELECT 1000uF 20% 63V
Jere eck C425 1-128-474-11 ELECT 1000uF 20% 63V
< CONNECTOR > C426 = 1-128-474-11 ELECT 1000uF 20% 63V
C451 1-104-274-11 POLYSTYRENE 47PF 10% 50V (FASES)
* CNP101 1-560-531-11 PIN, CONNECTOR 5P C451 1-104-322-11 POLYSTYRENE 47PF 10% 400V (FATES)
* CNP102 1-560-532-00 PIN, CONNECTOR 7P C452 =1-136-810-11 FILM 220PF o% 100V
* CNP103 1-506-509-11 PIN, CONNECTOR 4P (FATES) C455 9=1-126-025-11 ELECT 330uF 20% 25V
* CNP104 1-560-532-00 PIN, CONNECTOR 7P
EGS IOIO OOOO IOC OOOO GIGI OO IO ROO IOI I IK C456 1-126-025-11 ELECT 330uF 20% 25V
C458 = =1-110-390-11 ELECT 22uF 20% 63V
* A-4378-507-A MAIN. A BOARD, COMPLETE (FA5ES) C459 = 1-110-512-11 FILM luF 10% 50V (FATES)
* A-4378-519-A MAIN. A BOARD, COMPLETE (FA7ES) C460 1-104-274-11 POLYSTYRENE 47PF 10% 50V_ (FASES)
FOIA AAA ITAA EER C460 1-104-322-11 POLYSTYRENE 47PF 10% 400V (FATES)
* 1-535-730-21 LEAD, JUMPER (OFC) C461 1-126-025-11 ELECT 330uF 20% 25V
C462 1-126-025-11 ELECT 330uF 20% 25V
—29—
