Sony TA-SP55 - 3-3. HP Board and Panel Board Disassembly

6
3-3. HP BOARD, PANEL BOARD
0 three screws
(BVTP 2.6x8)
qa panel board
0 screw
(BVTP 2.6x8)
1 panel (L), side
5 HP board
6 two knobs (DSG)
8 nut
7 knobs (VOL)
9 knobs (select)
3 panel (TA), front
4
1 panel (R), side
2 claw
2 claw
