Sony TC-252 D - Location of Controls and Connections

Feec Reei Spindle
Axe de ia bobine d’alimentation
Spulenteller fiir Votispule
Tepe Counter
Compteur ce bande
Banczahiwerk
Automatic Shut-off Switch
Commutateur de coupure
automatique
Astomatische Lauiwerkabschaltung
Leve! Meter
indicateur de niveau
Aussteverungsanzeiger
Headphone Jack
Prise de casque d’écoute
Xopfhoreranschlu,2
Microphone Jacks
Peses C'entree de microphone
Mikrophonanschlisse
Power Record Lamp
Lémse c‘alimentation enregis -
trement
Strom Aufnahrne-Lampe
an 7 onbendeingange
40 O06 aantO o
LOCATION OF CONTROLS
Tape Speed Selector
Séiecteur de vitesse de ie bande
Bandgeschwindigkeitswahler
Take-up Reel Spindle
Axe de la bobine de réception
Spulenteller fur Leerspule
Record Level Controis
Bouton de reglage de volume du san
Aussteuerungsregier
eeecs
|
Function
Selector
Sélecteur
de
marche
Laufhebel
Power Switch
Commutateur d’alimentation
Stromschalter
Record Lever
Leviers d’enregistrernent
Aufnahmehebel
Reel Cap
Serre-bobine
Gummistépsel
NOTES
1. Keep the set away from extremely high heat and avoid any
mechanical shock. The ventilation grille located at the
bottom should be free to permit proper ventiiation.
2. The TC-252D can be used in either horizontal or vertical
position. When using vertically, make sure to place the
reel caps on the spindles. Also, if necessary, attach the
supplied non-skid pads to the bottom of the cabinet.
3. When recording through the Auxiliary Input Jacks, remove
any input source connected to the Microphone Jacks,
otherwise any input source connected to the Auxiliary Input
Jacks will not be recorded.
4. Keep the heads clean. Dust and deposits onthe heads will
prevent optimum performance,
5. When the set is not in use, the Function Selector must be
placed in the stop position.
CONNECTION TO PRE-AMP/AMPLIFIER
With the use of the output and input jacks
Connect left and right Line Output Jacks of the recorder to
respective tape input jacks (or line input jacks) of an integrated
amplifier
(pre-amp/amplifier)
using
the
Connecting
Cord
RK-74
(supplied). Then connect left and right Auxiliary Imput Jacks of
the recorder to respective line output jacks (or recording output
jacks) of the integrated amplifier with the another Connectirig
Cord RK-74,
Connect the Record/Playcack Connector to tre matching
connector
of
an
integrated
stereo
amplifier
usinga
SONY
REC/
PB Connector Cable RC-2 (optional accessory).
When using .this connector, disconnect any conmmecting cord
from other output and input jacks.
“LINE QUT 3 aia AUX IN
RK-74
to tape mputs to recording outputs
aux
entrees
de
aux
sortes
d’enregistrement
With
the
use
of
the
record/playback
connector
(only
for
magnetophone
an
Tonbandausgange
the
European
type)
:
L | TED
