Sony TRINITRON BVM-D9H5U - Cabinet Assy Removal

2-2
BVM-D9H1U/D9H5U/D9H1E/D9H5E/D9H1A/D9H5A
2-2-1. Cabinet Assy Removal
B
A
1 Push lever in the
direction shown by the arrow A.
2 Remove power unit
complete assy in the
direction shown by the arrow B.
3 Four screws
(Case screw OS)
4 Four screws
(Case screw OS)
6 Cabinet assy
5 Screw
(+B 3 × 8)
