2-9
BVM-D9H1U/D9H5U/D9H1E/D9H5E/D9H1A/D9H5A
5 Insulated sheet (Bottom)
Power case (Bottom) assy
4 G board
3 Four screws
(+PSW 3 × 8)
2 Power case (Top) assy
1 Three screws
(+K 3 × 6)
2-2-12. G Board Removal
* Remove the power unit complete assy. (Refer to 2-2-1.)
