9-3
BVM-D9H1U/D9H5U/D9H1E/D9H5E/D9H1A/D9H5A
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
CN308 * 1-564-512-11 PLUG, CONNECTOR 9P
CN411 * 1-506-611-11 PIN, CONNECTOR 8P
CN412 * 1-506-611-11 PIN, CONNECTOR 8P
CN421 * 1-779-070-21 PIN, CONNECTOR 12P
CN422 * 1-779-070-21 PIN, CONNECTOR 12P
<DIODE>
D1400 8-719-073-01 DIODE MA111-(K8).S0
D1401 8-719-073-01 DIODE MA111-(K8).S0
D1402 8-719-073-01 DIODE MA111-(K8).S0
D1403 8-719-073-01 DIODE MA111-(K8).S0
D1404 8-719-037-17 DIODE RD10SB3-T1
D1405 8-719-073-01 DIODE MA111-(K8).S0
D2345 8-719-157-72 DIODE RD22M-B
D2346 8-719-901-83 DIODE 1SS83
D2347 8-719-901-83 DIODE 1SS83
D2348 8-719-073-01 DIODE MA111-(K8).S0
D2349 8-719-073-01 DIODE MA111-(K8).S0
D2355 8-719-157-72 DIODE RD22M-B
D2356 8-719-901-83 DIODE 1SS83
D2357 8-719-901-83 DIODE 1SS83
D2358 8-719-073-01 DIODE MA111-(K8).S0
D2359 8-719-073-01 DIODE MA111-(K8).S0
D2365 8-719-157-72 DIODE RD22M-B
D2366 8-719-901-83 DIODE 1SS83
D2367 8-719-901-83 DIODE 1SS83
D2369 8-719-073-01 DIODE MA111-(K8).S0
D2370 8-719-073-01 DIODE MA111-(K8).S0
D3301 8-719-016-74 DIODE 1SS352
D3302 8-719-016-74 DIODE 1SS352
D3307 8-719-800-76 DIODE 1SS226
D3308 8-719-800-76 DIODE 1SS226
D4401 8-719-036-88 DIODE RD4.7SB1-T1
<IC>
IC300 8-759-011-65 IC MC74HC4053F
IC301 8-759-011-65 IC MC74HC4053F
IC302 8-759-011-65 IC MC74HC4053F
IC303 8-759-981-48 IC TL082M
IC304 8-759-981-48 IC TL082M
IC305 8-759-981-48 IC TL082M
IC306 8-752-054-80 IC CXA1521M
IC307 8-752-054-80 IC CXA1521M
IC308 8-752-054-80 IC CXA1521M
IC400 8-752-053-21 IC CXA1211M
IC401 8-752-053-21 IC CXA1211M
IC1300 8-759-011-65 IC MC74HC4053F
IC1302 8-759-011-65 IC MC74HC4053F
IC1303 8-759-011-65 IC MC74HC4053F
IC1304 8-759-011-65 IC MC74HC4053F
IC1305 8-759-981-48 IC TL082M
IC1306 8-759-981-48 IC TL082M
IC1307 8-759-981-48 IC TL082M
IC1308 8-759-011-65 IC MC74HC4053F
IC1309 8-759-011-65 IC MC74HC4053F
IC1400 8-759-038-15 IC MC74HC4538AF
IC1401 8-752-067-05 IC CXA1739S
IC2345 8-759-360-83 IC TDA6111Q/N4
IC2355 8-759-360-83 IC TDA6111Q/N4
IC2365 8-759-360-83 IC TDA6111Q/N4
IC2380 8-759-523-02 IC TC74HC4053AFT(EL)
IC2381 8-759-523-02 IC TC74HC4053AFT(EL)
IC2382 8-759-988-13 IC LM393PS
IC2383 8-759-083-94 IC TC7W74FU
IC3301 8-759-523-02 IC TC74HC4053AFT(EL)
IC3400 8-759-424-13 IC MC74HC00AFEL
IC3401 8-759-032-14 IC MC74HC08AF
IC3403 8-759-328-12 IC Z8622812PSC
IC3404 8-759-527-74 IC M24C02-MN6T
IC3406 8-759-084-79 IC TC7S14F
IC3407 8-759-242-76 IC TC7W08F
IC4300 8-752-072-94 IC CXA1875AM-T4
IC4301 8-752-072-94 IC CXA1875AM-T4
IC4302 8-752-072-94 IC CXA1875AM-T4
IC4350 8-752-072-94 IC CXA1875AM-T4
IC4351 8-759-482-47 IC M62399FP-TE2
IC4352 8-759-482-47 IC M62399FP-TE2
<COIL>
L300 1-406-669-11 INDUCTOR 470µH
<TRANSISTOR>
Q300 8-729-112-65 TRANSISTOR 2SA1462-Y33
Q301 8-729-107-31 TRANSISTOR 2SC3545-T43
Q302 8-729-920-59 TRANSISTOR IMX2-T109
Q303 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q304 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q330 8-729-112-65 TRANSISTOR 2SA1462-Y33
Q331 8-729-107-31 TRANSISTOR 2SC3545-T43
Q332 8-729-920-59 TRANSISTOR IMX2-T109
Q333 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q334 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q365 8-729-112-65 TRANSISTOR 2SA1462-Y33
Q366 8-729-107-31 TRANSISTOR 2SC3545-T43
Q367 8-729-920-59 TRANSISTOR IMX2-T109
Q368 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q369 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q450 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q451 8-729-107-31 TRANSISTOR 2SC3545-T43
Q452 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q453 8-729-112-65 TRANSISTOR 2SA1462-Y33
Q460 8-729-112-65 TRANSISTOR 2SA1462-Y33
Q461 8-729-107-31 TRANSISTOR 2SC3545-T43
Q462 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q463 8-729-107-31 TRANSISTOR 2SC3545-T43
Q464 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q465 8-729-026-50 TRANSISTOR 2SA1037AK-T146-QR
Q466 8-729-026-50 TRANSISTOR 2SA1037AK-T146-QR
Q485 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q486 8-729-107-31 TRANSISTOR 2SC3545-T43
Q487 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1300 8-729-112-65 TRANSISTOR 2SA1462-Y33
Q1301 8-729-107-31 TRANSISTOR 2SC3545-T43
Q1302 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1303 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1304 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1305 8-729-026-50 TRANSISTOR 2SA1037AK-T146-QR
Q1320 8-729-112-65 TRANSISTOR 2SA1462-Y33
Q1321 8-729-107-31 TRANSISTOR 2SC3545-T43
Q1322 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1323 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1340 8-729-112-65 TRANSISTOR 2SA1462-Y33
Q1341 8-729-107-31 TRANSISTOR 2SC3545-T43
Q1342 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1343 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1400 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q1401 8-729-120-28 TRANSISTOR 2SC1623-L5L6
