9-8
BVM-D9H1U/D9H5U/D9H1E/D9H5E/D9H1A/D9H5A
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
C404 1-163-031-11 CERAMIC CHIP0.01µF 50V
C407 1-163-038-91 CERAMIC CHIP0.1µF 25V
C410 1-163-038-91 CERAMIC CHIP0.1µF 25V
C411 1-165-319-11 CERAMIC CHIP0.1µF 50V
C412 1-163-031-11 CERAMIC CHIP0.01µF 50V
C502 1-163-031-11 CERAMIC CHIP0.01µF 50V
C503 1-163-031-11 CERAMIC CHIP0.01µF 50V
<CONNECTOR>
CN401 * 1-568-015-11 SOCKET, CONNECTOR 8P
CN402 * 1-568-015-11 SOCKET, CONNECTOR 8P
<DELAY LINE>
DL400 1-411-450-11 DELAY LINE
DL401 1-411-450-11 DELAY LINE
DL402 1-234-455-21 DELAY LINE
DL403 1-234-455-21 DELAY LINE
DL404 1-411-451-11 DELAY LINE
DL405 1-234-456-21 DELAY LINE
DL501 1-402-770-11 DELAY LINE
DL502 1-416-476-21 DELAY LINE
DL503 1-402-770-11 DELAY LINE
DL504 1-416-476-21 DELAY LINE
<IC>
IC410 8-759-011-65 IC MC74HC4053F
IC450 8-752-053-21 IC CXA1211M
IC501 8-759-011-65 IC MC74HC4053F
<TRANSISTOR>
Q400 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q401 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q402 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q403 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q404 8-729-026-50 TRANSISTOR 2SA1037AK-T146-QR
Q405 8-729-112-65 TRANSISTOR 2SA1462-T1Y33
Q406 8-729-112-65 TRANSISTOR 2SA1462-T1Y33
Q407 8-729-112-65 TRANSISTOR 2SA1462-T1Y33
Q408 8-729-107-31 TRANSISTOR 2SC3545-T43
Q409 8-729-107-31 TRANSISTOR 2SC3545-T43
Q410 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q411 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q412 8-729-107-31 TRANSISTOR 2SC3545-T43
Q413 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q414 8-729-107-31 TRANSISTOR 2SC3545-T43
Q501 8-729-026-50 TRANSISTOR 2SA1037AK-T146-QR
Q502 8-729-107-31 TRANSISTOR 2SC3545-T43
Q503 8-729-112-65 TRANSISTOR 2SA1462-T1Y33
Q504 8-729-026-50 TRANSISTOR 2SA1037AK-T146-QR
Q505 8-729-107-31 TRANSISTOR 2SC3545-T43
Q506 8-729-112-65 TRANSISTOR 2SA1462-T1Y33
Q511 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q512 8-729-107-31 TRANSISTOR 2SC3545-T43
Q513 8-729-112-65 TRANSISTOR 2SA1462-T1Y33
Q514 8-729-107-31 TRANSISTOR 2SC3545-T43
Q515 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q516 8-729-107-31 TRANSISTOR 2SC3545-T43
Q517 8-729-112-65 TRANSISTOR 2SA1462-T1Y33
Q518 8-729-107-31 TRANSISTOR 2SC3545-T43
<RESISTOR>
R400 1-216-025-91 RES,CHIP 100 5% 1/10W
R401 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R402 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R403 1-216-025-91 RES,CHIP 100 5% 1/10W
R404 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R405 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R406 1-216-025-91 RES,CHIP 100 5% 1/10W
R407 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R408 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R409 1-216-089-91 RES,CHIP 47K 5% 1/10W
R410 1-216-025-91 RES,CHIP 100 5% 1/10W
R411 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R412 1-216-643-11 METAL CHIP 470 0.50% 1/10W
R413 1-216-025-91 RES,CHIP 100 5% 1/10W
R414 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R415 1-216-643-11 METAL CHIP 470 0.50% 1/10W
R416 1-216-025-91 RES,CHIP 100 5% 1/10W
R417 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R418 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R419 1-216-085-00 RES,CHIP 33K 5% 1/10W
R420 1-216-025-91 RES,CHIP 100 5% 1/10W
R421 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R422 1-216-025-91 RES,CHIP 100 5% 1/10W
R423 1-216-025-91 RES,CHIP 100 5% 1/10W
R424 1-216-643-11 METAL CHIP 470 0.50% 1/10W
R425 1-216-643-11 METAL CHIP 470 0.50% 1/10W
R426 1-216-025-91 RES,CHIP 100 5% 1/10W
R427 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R428 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R429 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R430 1-216-025-91 RES,CHIP 100 5% 1/10W
R431 1-216-025-91 RES,CHIP 100 5% 1/10W
R432 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R433 1-216-075-00 RES,CHIP 12K 5% 1/10W
R434 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R435 1-216-051-00 RES,CHIP 1.2K 5% 1/10W
R436 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R437 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R438 1-216-073-00 RES,CHIP 10K 5% 1/10W
R439 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R440 1-216-049-91 RES,CHIP 1K 5% 1/10W
R441 1-216-295-91 SHORT 0
R442 1-216-025-91 RES,CHIP 100 5% 1/10W
R443 1-216-025-91 RES,CHIP 100 5% 1/10W
R444 1-216-025-91 RES,CHIP 100 5% 1/10W
R501 1-216-025-91 RES,CHIP 100 5% 1/10W
R502 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R503 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R504 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R505 1-216-025-91 RES,CHIP 100 5% 1/10W
R506 1-216-025-91 RES,CHIP 100 5% 1/10W
R507 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R508 1-216-025-91 RES,CHIP 100 5% 1/10W
R509 1-216-037-00 RES,CHIP 330 5% 1/10W
R510 1-216-631-11 METAL CHIP 150 0.50% 1/10W
R511 1-216-631-11 METAL CHIP 150 0.50% 1/10W
R512 1-216-025-91 RES,CHIP 100 5% 1/10W
R513 1-216-025-91 RES,CHIP 100 5% 1/10W
R514 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R515 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R516 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R517 1-216-025-91 RES,CHIP 100 5% 1/10W
R518 1-216-025-91 RES,CHIP 100 5% 1/10W
R519 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R520 1-216-025-91 RES,CHIP 100 5% 1/10W
