— 37 —
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
Note: Note:
Les composants identifies per un trame et une marque
sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
The components identified by shading and mark
are critical for safety. Replace only with part number
specified.
CPD-E210
A
DIODE
D001 8-719-970-02 DIODE 1SR139-400T31
D002 8-719-911-19 DIODE 1SS119-25
D003 8-719-911-19 DIODE 1SS119-25
D004 8-719-911-19 DIODE 1SS119-25
D005 8-719-911-19 DIODE 1SS119-25
D007 8-719-109-89 DIODE RD5.6ESB2
D008 8-719-109-89 DIODE RD5.6ESB2
D014 8-719-911-19 DIODE 1SS119-25
D015 8-719-911-19 DIODE 1SS119-25
D104 8-719-970-83 DIODE HSS82
D105 8-719-970-83 DIODE HSS82
D106 8-719-970-83 DIODE HSS82
D111 8-719-062-51 DIODE 1PS226-115
D204 8-719-970-83 DIODE HSS82
D205 8-719-970-83 DIODE HSS82
D206 8-719-970-83 DIODE HSS82
D211 8-719-062-51 DIODE 1PS226-115
D304 8-719-970-83 DIODE HSS82
D305 8-719-970-83 DIODE HSS82
D306 8-719-970-83 DIODE HSS82
D311 8-719-062-51 DIODE 1PS226-115
FERRITE BEAD
FB001 1-412-911-11 FERRITE 0µH
FB004 1-412-911-11 FERRITE 0µH
FB005 1-412-911-11 FERRITE 0µH
FB006 1-412-911-11 FERRITE 0µH
FB009 1-412-911-11 FERRITE 0µH
FB010 1-412-911-11 FERRITE 0µH
FB011 1-412-911-11 FERRITE 0µH
FB012 1-412-911-11 FERRITE 0µH
FB102 1-216-295-91 SHORT 0
FB202 1-216-295-91 SHORT 0
FB302 1-216-295-91 SHORT 0
FILTER
FL002 1-412-911-11 FERRITE 0µH
IC
IC001 8-752-090-63 IC CXA2067S
IC002 8-759-593-11 IC LM2415T
IC003 8-759-589-35 IC CXD9516P
IC004 8-749-016-27 IC H8D2957
IC005 8-759-100-96 IC NJM4558M-TE2
IC006 8-759-269-07 IC SN74HCT02ANSR
JACK
J001 1-251-598-11 SOCKET, CRT
CHIP CONDUCTOR
JR002 1-216-296-91 SHORT
JR005 1-216-296-91 SHORT
JR006 1-216-296-91 SHORT
JR007 1-216-296-91 SHORT
JR016 1-216-296-91 SHORT
JR017 1-216-296-91 SHORT
JR018 1-216-295-91 SHORT
JR019 1-216-296-91 SHORT
JR020 1-216-296-91 SHORT
JR021 1-216-296-91 SHORT
COIL
L002 1-410-682-31 INDUCTOR 470µH
L003 1-408-397-00 INDUCTOR 1µH
L005 1-412-529-11 INDUCTOR 22µH
L007 1-410-482-31 INDUCTOR 100µH
L009 1-216-295-91 SHORT
L010 1-412-911-11 FERRITE 0µH
L102 1-412-052-21 INDUCTOR CHIP 1µH
L103 1-414-137-31 INDUCTOR 0.22µH
L105 1-410-750-41 INDUCTOR 0.47µH
L203 1-414-137-31 INDUCTOR 0.22µH
L205 1-410-750-41 INDUCTOR 0.47µH
L303 1-414-137-31 INDUCTOR 0.22µH
L305 1-410-750-41 INDUCTOR 0.47µH
TRANSISTOR
Q001 8-729-046-80 TRANSISTOR 2SC4634LS-CB11
Q006 8-729-120-28 TRANSISTOR 2SC1623-L5L6
RESISTOR
R002 1-240-978-91 METAL CHIP 560 5% 1/10W
R003 1-240-992-91 METAL CHIP 8.2K 5% 1/10W
R004 1-240-984-91 METAL CHIP 1.8K 5% 1/10W
R005 1-242-774-91 METAL CHIP 330K 5% 1/10W
R006 1-240-969-91 METAL CHIP 100 5% 1/10W
R007 1-240-969-91 METAL CHIP 100 5% 1/10W
R009 1-240-993-91 METAL CHIP 10K 5% 1/10W
R011 1-240-993-91 METAL CHIP 10K 5% 1/10W
R012 1-240-993-91 METAL CHIP 10K 5% 1/10W
R013 1-240-969-91 METAL CHIP 100 5% 1/10W
R014 1-240-969-91 METAL CHIP 100 5% 1/10W
