— 38 —
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
Note: Note:
Les composants identifies per un trame et une marque
sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
The components identified by shading and mark
are critical for safety. Replace only with part number
specified.
CPD-E210
D
A
R017 1-240-969-91 METAL CHIP 100 5% 1/10W
R018 1-240-969-91 METAL CHIP 100 5% 1/10W
R020 1-240-969-91 METAL CHIP 100 5% 1/10W
R021 1-240-969-91 METAL CHIP 100 5% 1/10W
R022 1-240-973-91 METAL CHIP 220 5% 1/10W
R023 1-240-981-91 METAL CHIP 1K 5% 1/10W
R024 1-240-989-91 METAL CHIP 4.7K 5% 1/10W
R028 1-240-989-91 METAL CHIP 4.7K 5% 1/10W
R029 1-242-769-91 METAL CHIP 120K 5% 1/10W
R030 1-240-969-91 METAL CHIP 100 5% 1/10W
R031 1-240-981-91 METAL CHIP 1K 5% 1/10W
R035 1-216-295-91 SHORT
R041 1-240-969-91 METAL CHIP 100 5% 1/10W
R045 1-240-985-91 METAL CHIP 2.2K 5% 1/10W
R046 1-242-768-91 METAL CHIP 100K 5% 1/10W
R047 1-240-993-91 METAL CHIP 10K 5% 1/10W
R048 1-219-398-51 METAL 2.2M 5% 1W
R049 1-216-697-91 METAL CHIP 82K 0.50% 1/10W
R051 1-240-981-91 METAL CHIP 1K 5% 1/10W
R052 1-240-993-91 METAL CHIP 10K 5% 1/10W
R053 1-219-621-91 METAL 22M 10% 1/4W
R062 1-216-295-91 SHORT
R064 1-202-830-00 SOLID 10K 20% 1/2W
R102 1-242-776-91 METAL CHIP 470K 5% 1/10W
R104 1-240-965-91 METAL CHIP 47 5% 1/10W
R106 1-216-673-11 METAL CHIP 8.2K 0.50% 1/10W
R107 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R108 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R109 1-242-776-91 METAL CHIP 470K 5% 1/10W
R111 1-249-405-11 CARBON 100 5% 1/4W F
R117 1-216-295-91 SHORT
R118 1-216-295-91 SHORT
R119 1-242-776-91 METAL CHIP 470K 5% 1/10W
R130 1-216-022-00 RES,CHIP 75 5% 1/10W
R151 1-202-549-00 SOLID 100 20% 1/2W
R161 1-215-394-00 METAL 75 1% 1/4W
R202 1-242-776-91 METAL CHIP 470K 5% 1/10W
R204 1-240-965-91 METAL CHIP 47 5% 1/10W
R206 1-216-673-11 METAL CHIP 8.2K 0.50% 1/10W
R207 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R208 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R209 1-242-776-91 METAL CHIP 470K 5% 1/10W
R211 1-249-405-11 CARBON 100 5% 1/4W F
R217 1-216-295-91 SHORT
R218 1-240-965-91 METAL CHIP 47 5% 1/10W
R219 1-242-776-91 METAL CHIP 470K 5% 1/10W
R230 1-240-962-91 METAL CHIP 27 5% 1/10W
R251 1-202-549-00 SOLID 100 20% 1/2W
R261 1-215-394-00 METAL 75 1% 1/4W
R302 1-242-776-91 METAL CHIP 470K 5% 1/10W
R304 1-240-965-91 METAL CHIP 47 5% 1/10W
R306 1-216-673-11 METAL CHIP 8.2K 0.50% 1/10W
R307 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R308 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R309 1-242-776-91 METAL CHIP 470K 5% 1/10W
R311 1-249-404-00 CARBON 82 5% 1/4W F
R317 1-216-295-91 SHORT
R318 1-216-295-91 SHORT
R319 1-242-776-91 METAL CHIP 470K 5% 1/10W
R330 1-216-022-00 RES,CHIP 75 5% 1/10W
R351 1-202-549-00 SOLID 100 20% 1/2W
R361 1-215-394-00 METAL 75 1% 1/4W
SPARK GAP
SG001 1-519-422-11 GAP, SPARK
SG002 1-517-499-21 GAP, SPARK
SG101 1-517-499-21 GAP, SPARK
SG201 1-517-499-21 GAP, SPARK
SG301 1-517-499-21 GAP, SPARK
* A-1346-865-A D COMPLETE PC BOARD
1-533-223-11 CLIP, FUSE
3-703-319-01 PURSE LOCK (DIA.15)
4-382-854-01 SCREW (M3X8), P, SW (+)
4-382-854-21 SCREW (M3X14), P, SW (+)
CAPACITOR
C401 1-128-528-11 ELECT 470µF 20% 25V
C402 1-117-667-31 FILM 0.47µF 5% 250V
C403 1-107-911-11 ELECT 220µF 20% 50V
C404 1-128-528-11 ELECT 470µF 20% 25V
C405 1-104-760-11 CERAMIC CHIP 0.047µF 10% 50V
C406 1-137-368-11 MYLAR 0.0047µF 5% 50V
C407 1-137-372-11 MYLAR 0.022µF 5% 50V
C410 1-164-005-11 CERAMIC CHIP 0.47µF 25V
C501 1-126-964-11 ELECT 10µF 20% 50V
C502 1-137-370-11 MYLAR 0.01µF 5% 50V
C503 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C504 1-102-030-00 CERAMIC 330PF 10% 500V
C505 1-109-878-11 CERAMIC 15PF 5% 2KV
C506 1-126-960-11 ELECT 1µF 20% 50V
C507 1-131-653-11 FILM 0.19µF 5% 400V
C508 1-128-526-11 ELECT 100µF 20% 25V
C509 1-162-117-00 CERAMIC 100PF 10% 500V
To Next Page
