REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified
¡
marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque
¡
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
CPD-G400
7-1
REF.NO. PART NO. DESCRIPTION REMARK
SECTION 7
ELECTRICAL PARTS LIST
REF.NO. PART NO. DESCRIPTION REMARK
A
NOTE:
The components identified
¡
marked are
critical for safety.
Replace only with the part number specified.
When indicating parts by reference
number, please include the board name.
Les composants identifiés par la marque
¡
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
The components identified by [ in this
manual have been carefully factory-
selected for each set in order to satisfy
regulations regarding X-ray radiation.
Should replacement be required, replace
only with the value originally used.
• All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
RESISTORS
• All resistors are in ohms
• F : nonflammable
• Items marked " * " are not stocked since
they are seldom required for routine
service. Some delay should be anticipated
when ordering these items.
• CAPACITORS
MF : µF
• COILS
UH : µH
CPD-G400
* A-1298-985-B A BOARD, COMPLETE
****************************
4-382-854-01 SCREW (M3X8), P, SW (+) (IC002)
<CAPACITOR>
C001 1-162-318-11 CERAMIC 0.001uF 10% 500V
C002 1-162-318-11 CERAMIC 0.001uF 10% 500V
C003 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C005 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C007 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C009 1-126-964-11 ELECT 10uF 20% 50V
C010 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C011 1-106-220-00 MYLAR 0.1uF 10% 100V
C012 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C013 1-107-888-11 ELECT 47uF 20% 25V
C014 1-107-932-11 ELECT 47uF 20% 100V
C015 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C016 1-126-935-11 ELECT 470uF 20% 16V
C018 1-107-652-11 ELECT 10uF 20% 250V
C019 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C020 1-126-935-11 ELECT 470uF 20% 16V
C021 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C022 1-126-934-11 ELECT 220uF 20% 10V
C027 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C028 1-104-664-11 ELECT 47uF 20% 25V
C029 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C031 1-162-318-11 CERAMIC 0.001uF 10% 500V
C032 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C033 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C035 1-162-134-11 CERAMIC 470pF 10% 2KV
C037 1-101-006-00 CERAMIC 0.047uF 50V
C038 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C039 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C040 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C041 1-162-318-11 CERAMIC 0.001uF 10% 500V
C042 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C043 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C045 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C046 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C047 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C048 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C049 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C053 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C054 1-104-341-11 MYLAR 0.1uF 10% 250V
C056 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C057 1-163-113-00 CERAMIC CHIP 68pF 5% 50V
C059 1-164-346-11 CERAMIC CHIP 1uF 16V
C060 1-104-664-11 ELECT 47uF 20% 25V
C061 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C063 1-126-964-11 ELECT 10uF 20% 50V
C064 1-104-664-11 ELECT 47uF 20% 25V
C065 1-104-664-11 ELECT 47uF 20% 25V
C066 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C067 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C068 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C069 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C070 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C090 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C092 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C093 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C094 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C095 1-126-935-11 ELECT 470uF 20% 16V
C096 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C102 1-163-087-00 CERAMIC CHIP 4pF 0.25pF 50V
C104 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C105 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C106 1-117-450-11 MYLAR 0.47uF 10% 250V
C108 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C109 1-104-664-11 ELECT 47uF 20% 25V
C111 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C112 1-163-227-11 CERAMIC CHIP 10pF 0.5pF 50V
C119 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C120 1-126-933-11 ELECT 100uF 20% 16V
C121 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C122 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C123 1-104-341-11 MYLAR 0.1uF 10% 250V
C130 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C152 1-126-933-11 ELECT 100uF 20% 16V
C204 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C205 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C206 1-117-450-11 MYLAR 0.47uF 10% 250V
C208 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C211 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C212 1-163-227-11 CERAMIC CHIP 10pF 0.5pF 50V
To Next Page
