Sony TRINITRON CPD-G400 - Timing Specification

CPD-G400
– 4 –
TIMING SPECIFICATION
MODE TEST MODE
MODE AT PRODUCTION MODE 1 MODE 2 MODE 3
RESOLUTION 738 X 414 1600 X 1200 1600 X 1200
CLOCK 28.322 MHz 229.500 MHz 202.500 MHz
HORIZONTAL
H-FREQ 31.469 kHz 106.250 kHz 93.750 kHz
usec usec usec
H. TOTAL 31.777 9.412 10.667
H. BLK 5.720 2.440 2.765
H. FP 0.318 0.279 0.316
H. SYNC 3.813 0.837 0.948
H. BP 1.589 1.325 1.501
H. ACTIV 26.057 6.972 7.901
– VERTICAL –
V. FREQ(HZ) 70.087 Hz 85.000 Hz 75.000 Hz
lines lines lines
V. TOTAL 449 1250 1250
V. BLK 35 50 50
V. FP 5 1 1
V. SYNC 2 3 3
V. BP 28 46 46
V. ACTIV 414 1200 1200
– SYNC –
INT(G) NO NO NO
EXT(H/V)/POLARITY YES N/P YES P/P YES P/P
EXT(CS) /POLARITY NO NO NO
INT/NON INT NON INT NON INT NON INT
SIZE 352 X 264 mm 352 X 264 mm 352 X 264 mm
99.07.01 VER.
