Sony TRINITRON CPD-G400 - Page 44

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified ¡ marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque ¡
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
CPD-G400
7-8
D
IC1001 8-759-656-95 IC CXD9523S/JCN (Ver. 1.2)
IC1003 8-759-420-77 IC PST574CMT-T1
IC1005 8-759-641-86 IC BR24C16F-E2
<CHIP CONDUCTOR>
JR43 1-216-296-91 SHORT 0
JR45 1-216-295-91 SHORT 0
JR002 1-216-296-91 SHORT 0
JR004 1-216-296-91 SHORT 0
JR005 1-216-295-91 SHORT 0
JR006 1-216-296-91 SHORT 0
JR007 1-216-295-91 SHORT 0
JR008 1-216-296-91 SHORT 0
JR009 1-216-296-91 SHORT 0
JR010 1-216-296-91 SHORT 0
JR011 1-216-296-91 SHORT 0
JR015 1-216-296-91 SHORT 0
JR016 1-216-296-91 SHORT 0
JR017 1-216-296-91 SHORT 0
JR019 1-216-296-91 SHORT 0
JR020 1-216-296-91 SHORT 0
JR021 1-216-296-91 SHORT 0
JR022 1-216-295-91 SHORT 0
JR023 1-216-296-91 SHORT 0
JR024 1-216-295-91 SHORT 0
JR026 1-216-296-91 SHORT 0
JR027 1-216-295-91 SHORT 0
JR028 1-216-295-91 SHORT 0
JR029 1-216-295-91 SHORT 0
JR030 1-216-296-91 SHORT 0
JR031 1-216-295-91 SHORT 0
JR032 1-216-296-91 SHORT 0
JR033 1-216-296-91 SHORT 0
JR034 1-216-296-91 SHORT 0
JR035 1-216-296-91 SHORT 0
JR036 1-216-295-91 SHORT 0
JR037 1-216-296-91 SHORT 0
JR038 1-216-296-91 SHORT 0
JR039 1-216-296-91 SHORT 0
JR040 1-216-295-91 SHORT 0
JR042 1-216-296-91 SHORT 0
JR046 1-216-296-91 SHORT 0
JR050 1-216-295-91 SHORT 0
JR051 1-216-296-91 SHORT 0
JR052 1-216-296-91 SHORT 0
JR602 1-216-295-91 SHORT 0
JR603 1-216-295-91 SHORT 0
JR604 1-216-295-91 SHORT 0
JR605 1-216-295-91 SHORT 0
JR606 1-216-295-91 SHORT 0
<COIL>
L501 1-412-541-21 INDUCTOR 220uH
L502 1-419-299-11 COIL, HORIZONTAL LINEARITY
L503 1-419-298-11 COIL, HORIZONTAL CENTER
L504 1-406-675-11 INDUCTOR 4.7mH
L505 1-406-675-11 INDUCTOR 4.7mH
L506 1-406-675-11 INDUCTOR 4.7mH
L507 1-412-537-31 INDUCTOR 100uH
L603 1-412-537-31 INDUCTOR 100uH
L604 1-406-665-11 INDUCTOR 100uH
L606 1-406-665-11 INDUCTOR 100uH
L607 1-414-158-11 INDUCTOR 2.2uH
L608 1-414-487-41 INDUCTOR 1uH
L901 1-412-537-31 INDUCTOR 100uH
L902 1-406-659-11 INDUCTOR 10uH
<FILTER>
LF6020 1-429-180-11 TRANSFORMER, LINE FILTER
<TRANSISTOR>
Q501 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q502 8-729-901-87 TRANSISTOR 2SC2411K-CQ
Q503 8-729-026-50 TRANSISTOR 2SA1037AK-T146-QR
Q504 8-729-042-34 TRANSISTOR IRFU110A
Q505 8-729-050-12 TRANSISTOR 2SC5445(LBSONY1)
Q506 8-729-050-13 TRANSISTOR 2SJ585LS-CC11
Q507 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q508 8-729-901-87 TRANSISTOR 2SC2411K-CQ
Q509 8-729-901-97 TRANSISTOR 2SA1036K-Q
Q510 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q511 8-729-043-41 TRANSISTOR 2SK2098-01MR-F119
Q512 8-729-043-41 TRANSISTOR 2SK2098-01MR-F119
Q513 8-729-043-41 TRANSISTOR 2SK2098-01MR-F119
Q514 8-729-047-72 TRANSISTOR 2SK3155-01
Q515 8-729-047-72 TRANSISTOR 2SK3155-01
Q516 8-729-047-72 TRANSISTOR 2SK3155-01
Q517 8-729-140-50 TRANSISTOR 2SC3209LK
Q519 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q605 8-729-050-14 TRANSISTOR 2SK3265LB2SONY
Q606 8-729-043-27 TRANSISTOR PDTC114EK-115
Q607 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q608 8-729-029-92 TRANSISTOR DTC143ESA
Q609 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q701 8-729-800-32 TRANSISTOR 2SC2362K-G
Q702 8-729-178-43 TRANSISTOR 2SC2784-E
Q703 8-729-204-91 TRANSISTOR 2SA1049-GR
Q704 8-729-207-82 TRANSISTOR 2SC3421-Y
Q705 8-729-207-89 TRANSISTOR 2SA1358-Y
Q706 8-729-031-89 TRANSISTOR 2SC3941A-Q (TA)
Q901 8-729-050-13 TRANSISTOR 2SJ585LS-CC11
Q902 8-729-041-45 TRANSISTOR FS5KM-16A
Q903 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q904 8-729-901-97 TRANSISTOR 2SA1036K-Q
<RESISTOR>
R401 1-249-383-11 CARBON 1.5 5% 1/4W F
R402 1-215-866-11 METAL OXIDE 330 5% 1W F
