Sony TRINITRON CPD-G400 - Page 47

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified ¡ marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque ¡
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
CPD-G400
7-11
R926 1-216-073-00 RES,CHIP 10K 5% 1/10W
R927 1-220-823-91 CARBON 6.8K 5% 1/2W
R928 1-220-825-11 CARBON 330K 5% 1/2W
R929 1-216-089-91 RES,CHIP 47K 5% 1/10W
R930 1-219-748-11 CARBON 4.7K 5% 1/2W
R931 1-219-748-11 CARBON 4.7K 5% 1/2W
R932 1-216-673-11 METAL CHIP 8.2K 0.50%1/10W
R933 1-216-666-11 METAL CHIP 4.3K 0.50%1/10W
R934 1-249-377-11 CARBON 0.47 5% 1/4W F
R1001 1-216-675-91 METAL CHIP 10K 0.50%1/10W
R1003 1-216-025-91 RES,CHIP 100 5% 1/10W
R1004 1-216-033-00 RES,CHIP 220 5% 1/10W
R1005 1-247-815-91 CARBON 220 5% 1/4W
R1006 1-216-033-00 RES,CHIP 220 5% 1/10W
R1010 1-216-033-00 RES,CHIP 220 5% 1/10W
R1011 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1012 1-216-017-91 RES,CHIP 47 5% 1/10W
R1013 1-216-017-91 RES,CHIP 47 5% 1/10W
R1014 1-216-025-91 RES,CHIP 100 5% 1/10W
R1015 1-216-033-00 RES,CHIP 220 5% 1/10W
R1016 1-216-033-00 RES,CHIP 220 5% 1/10W
R1017 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R1018 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R1019 1-216-017-91 RES,CHIP 47 5% 1/10W
R1020 1-216-017-91 RES,CHIP 47 5% 1/10W
R1021 1-216-025-91 RES,CHIP 100 5% 1/10W
R1022 1-216-025-91 RES,CHIP 100 5% 1/10W
R1039 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1046 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1047 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1048 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1049 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1050 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1051 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1065 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1070 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1072 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1073 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1074 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1083 1-216-025-91 RES,CHIP 100 5% 1/10W
R1084 1-216-041-00 RES,CHIP 470 5% 1/10W
R1085 1-216-025-91 RES,CHIP 100 5% 1/10W
R1086 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1092 1-216-033-00 RES,CHIP 220 5% 1/10W
R1093 1-216-033-00 RES,CHIP 220 5% 1/10W
R1094 1-216-113-00 RES,CHIP 470K 5% 1/10W
R1095 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1096 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1097 1-216-077-91 RES,CHIP 15K 5% 1/10W
R1098 1-216-077-91 RES,CHIP 15K 5% 1/10W
R1099 1-216-033-00 RES,CHIP 220 5% 1/10W
R1104 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
<VARIABLE RESISTOR>
[RV9010 1-241-767-21 RES, ADJ, CERMET 100K
<RELAY>
RY6010 1-755-067-21 RELAY, AC POWER
RY6020 1-755-318-11 RELAY, POWER
<SWITCH>
S6010 1-771-727-11 SWITCH, AC POWER PUSH (POWER)
<SPARK GAP>
SG901 1-517-499-21 GAP, SPARK
SG902 1-519-422-11 GAP, SPARK
SG903 1-519-422-11 GAP, SPARK
<TRANSFORMER>
T501 1-435-188-11 TRANSFORMER, FERRITE (HDT)
T502 1-411-594-11 INDUCTOR 5mH
T503 1-435-140-11 TRANSFORMER, FERRITE (LCT)
T504 1-431-413-21 TRANSFORMER, FERRITE (HST)
T602 1-435-141-11 TRANSFORMER, CONVERTER (SRT)
T701 1-435-142-11 TRANSFORMER, FERRITE (DFT)
T901 0 X-4560-174-1 TRANSFORMER ASSY, FLYBACK
(NX4700//J1E4)
T902 1-419-345-11 COIL, CHOKE 500uH
<THERMISTOR>
TH6000 1-809-260-11 THERMISTOR, POWER
TH6010 1-803-540-11 THERMISTOR
<VARISTOR>
VA6010 1-801-268-51 VARISTOR TNR14V471K660
<CRYSTAL>
X1001 1-567-890-11 VIBRATOR, CRYSTAL (8MHz)
*******************************************************************************
* A-1390-954-A N BOARD, COMPLETE
****************************
<CAPACITOR>
C801 1-113-340-11 ELECT 47uF 20% 25V
C803 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C809 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C810 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C811 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C812 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
DN
The components identified by [ in
this manual have been carefully
factory-selected for each set in
order to satisfy regulations
regarding X-ray radiation. Should
replacement be required, replace
only with the value originally used.
