Sony Trinitron KV-24LS35B - Page 45

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
57
VM
C
CN1801 *1-564-506-11 PLUG, CONNECTOR 3P
< DIODE >
D701 8-719-991-33 DIODE 1SS133T-77
D702 8-719-901-83 DIODE 1SS83
D703 8-719-901-83 DIODE 1SS83
D705 8-719-302-43 DIODE EL1Z
D706 8-719-901-83 DIODE 1SS83
D707 8-719-901-83 DIODE 1SS83
D708 8-719-109-97 DIODE RD6.8ES-B2
D709 8-719-109-97 DIODE RD6.8ES-B2
D710 8-719-109-97 DIODE RD6.8ES-B2
D1801 8-719-110-17 DIODE RD10ESB2
D1802 8-719-110-17 DIODE RD10ESB2
D1803 8-719-110-17 DIODE RD10ESB2
< IC >
IC701 8-759-562-43 IC TDA6108JF/N1B
IC1801 8-759-603-37 IC M5216P
< SOCKET >
J701 £ 1-251-732-11 SOCKET, CRT
< COIL >
L704 1-414-183-41 INDUCTOR 10UH
< RESISTOR >
R701 1-247-903-00 CARBON 1M 5% 1/4W
R702 1-249-429-11 CARBON 10K 5% 1/4W
R703 1-247-903-00 CARBON 1M 5% 1/4W
R704 1-535-143-21 LEAD, JUMPER (12.5)
R705 1-215-869-11 METAL OXIDE 1K 5% 1W
R706 1-249-411-11 CARBON 330 5% 1/4W
R712 1-215-869-11 METAL OXIDE 1K 5% 1W
R716 1-249-411-11 CARBON 330 5% 1/4W
R718 1-202-814-11 SOLID 33K 10% 1/2W
R726 1-215-869-11 METAL OXIDE 1K 5% 1W
R727 1-249-411-11 CARBON 330 5% 1/4W
R728 1-247-777-91 CARBON 5.6 5% 1/4W
R741 1-202-549-00 SOLID 100 20% 1/2W
R1801 1-249-441-11 CARBON 100K 5% 1/4W
R1805 1-249-429-11 CARBON 10K 5% 1/4W
R1806 1-247-899-11 CARBON 680K 5% 1/4W
R1807 1-249-429-11 CARBON 10K 5% 1/4W
R1808 1-249-429-11 CARBON 10K 5% 1/4W
R1809 1-249-429-11 CARBON 10K 5% 1/4W
R1810 1-249-429-11 CARBON 10K 5% 1/4W
< VARIABLE RESISTOR >
RV702 1-241-656-21 RES, ADJ, METAL FILM 110M
*A-1644-122-A VM Board, Complete
< CAPACITOR >
C1701 1-104-665-11 ELECT 100UF 20.00% 25V
C1702 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C1703 1-162-954-11 CERAMIC CHIP 120PF 5.00% 50V
C1704 1-104-665-11 ELECT 100UF 20.00% 25V
C1705 1-162-919-11 CERAMIC CHIP 22PF 5.00% 50V
C1710 1-106-375-12 MYLAR 0.022UF 10.00% 250V
C1711 1-106-375-12 MYLAR 0.022UF 10.00% 250V
C1721 1-107-639-11 ELECT 47UF 20.00% 160V
C1722 1-136-153-00 FILM 0.01UF 5.00% 50V
C1723 1-126-935-11 ELECT 470UF 20.00% 10V
C1728 1-126-935-11 ELECT 470UF 20.00% 10V
C1733 1-104-664-11 ELECT 47UF 20.00% 25V
C1734 1-104-664-11 ELECT 47UF 20.00% 25V
C1737 1-137-354-11 FILM 0.01UF 5.00% 100V
< CONNECTOR >
CN1701 *1-764-333-11 PLUG, CONNECTOR 10P
CN1702 *1-764-333-11 PLUG, CONNECTOR 10P
CN1718 *1-770-723-11 CONNECTOR, BOARD TO BOARD 8P
< DIODE >
D1701 8-719-988-61 DIODE 1SS355TE-17
D1702 8-719-988-61 DIODE 1SS355TE-17
D1711 8-719-988-61 DIODE 1SS355TE-17
D1719 8-719-991-33 DIODE 1SS133T-77
D1722 8-719-991-33 DIODE 1SS133T-77
D1733 8-719-921-40 DIODE MTZJ-4.7C
D1734 8-719-921-40 DIODE MTZJ-4.7C
< FERRITE BEAD >
FB1701 1-535-143-61 LEAD, JUMPER (5.0MM)
< IC >
IC1701 8-759-648-19 IC L7809CV/LSY
< COIL >
L1701 1-414-183-41 INDUCTOR 10UH
L1702 1-414-183-41 INDUCTOR 10UH
L1703 1-412-527-11 INDUCTOR 15UH
