Sony Trinitron KV-24LS35B - Page 46

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
58
VM
< FUSE >
F5601 £ 1-576-232-21 FUSE (H.B.C.) 5A/250V
*1-533-725-11 HOLDER, FUSE (F5601)
< RESISTOR >
R5601 1-202-719-00 SOLID 1M 10% 1/2W
< SWITCH >
S5601 £ 1-571-433-21 SWITCH, PUSH (AC POWER)
< VARISTOR >
VD5601 1-803-830-11 VARISTOR (ERZV14D621)
*A-1646-244-A H5 Board, Complete
< CAPACITOR >
C5100 1-104-665-11 ELECT 100UF 20.00% 16V
C5102 1-102-074-00 CERAMIC 0.001UF 10.00% 50V
C5103 1-102-074-00 CERAMIC 0.001UF 10.00% 50V
C5112 1-126-964-11 ELECT 10UF 20.00% 50V
C5113 1-126-964-11 ELECT 10UF 20.00% 50V
< CONNECTOR >
CN5100 *1-564-510-11 PLUG, CONNECTOR 7P
CN5101 *1-564-512-11 PLUG, CONNECTOR 9P
CN5102 *1-564-509-11 PLUG, CONNECTOR 6P
< DIODE >
D5100 8-719-109-89 DIODE RD5.6ES-B2
D5101 8-719-109-89 DIODE RD5.6ES-B2
D5102 8-719-081-56 DIODE L-59SRSGC-CC
D5103 8-719-929-15 DIODE HZS9.1NB2
D5104 8-719-929-15 DIODE HZS9.1NB2
D5105 8-719-929-15 DIODE HZS9.1NB2
D5106 8-719-109-89 DIODE RD5.6ES-B2
D5107 8-719-109-97 DIODE RD6.8ES-B2
D5108 8-719-109-97 DIODE RD6.8ES-B2
< IC >
IC5100 8-749-014-59 IC TSOP1740KS1
< JACK >
J5100 1-779-947-11 TERMINAL BLOCK, S
J5101 1-750-264-11 JACK
< TRANSISTOR >
Q5100 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q5101 8-728-027-38 TRANSISTOR DTA144EKA-T146
< TRANSISTOR >
Q1701 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1702 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1703 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1704 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1705 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1706 8-729-026-39 TRANSISTOR 2SA933AS
Q1707 8-729-049-09 TRANSISTOR BC327-25
Q1708 8-729-045-05 TRANSISTOR 2SA2005
Q1709 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1710 8-729-049-10 TRANSISTOR BC337-25
Q1711 8-729-045-04 TRANSISTOR 2SC5511
< RESISTOR >
JR1702 1-216-864-11 SHORT 0
R1701 1-216-814-11 RES-CHIP 270 5% 1/16W
R1702 1-216-814-11 RES-CHIP 270 5% 1/16W
R1709 1-216-825-11 RES-CHIP 2.2K 5% 1/16W
R1710 1-216-839-11 RES-CHIP 33K 5% 1/16W
R1711 1-216-823-11 RES-CHIP 1.5K 5% 1/16W
R1712 1-216-824-11 RES-CHIP 1.8K 5% 1/16W
R1713 1-216-809-11 RES-CHIP 100 5% 1/16W
R1714 1-260-089-11 CARBON 150 5% 1/2W
R1719 1-216-822-11 RES-CHIP 1.2K 5% 1/16W
R1720 1-216-837-11 RES-CHIP 22K 5% 1/16W
R1721 1-216-837-11 RES-CHIP 22K 5% 1/16W
R1722 1-216-822-11 RES-CHIP 1.2K 5% 1/16W
R1723 1-249-399-11 CARBON 33 5% 1/4W
R1724 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R1725 1-216-850-11 RES-CHIP 270K 5% 1/16W
R1726 1-216-850-11 RES-CHIP 270K 5% 1/16W
R1727 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R1728 1-249-399-11 CARBON 33 5% 1/4W
R1729 1-249-407-11 CARBON 150 5% 1/4W
R1732 1-249-407-11 CARBON 150 5% 1/4W
R1733 1-214-809-81 METAL 5.1 1% 1/2W
R1734 1-214-809-81 METAL 5.1 1% 1/2W
R1735 1-215-922-11 METAL OXIDE 6.8K 5% 3W
R1736 1-260-328-11 CARBON 1K 5% 1/2W
R1737 1-215-867-00 METAL OXIDE 470 5% 1W
*A-1624-105-A F5 Board, Complete
*4-374-846-01 COVER, CAPACITOR, CAP TYPE
< CONNECTOR >
CN5601 *1-580-843-11 PIN, CONNECTOR (POWER)
CN5602 1-695-915-11 TAB (CONTACT)
CN5603 *1-580-843-11 PIN, CONNECTOR (POWER)
H5F5
