Sony Trinitron KV-24LS35B - Page 47

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
59
< RESISTOR >
R5100 1-216-813-91 CARBON 220 5% 1/4W
R5101 1-216-833-91 CARBON 10K 5% 1/16W
R5102 1-216-835-91 CARBON 15K 5% 1/16W
R5103 1-216-827-91 CARBON 3.3K 5% 1/16W
R5104 1-216-831-91 CARBON 6.8K 5% 1/16W
R5106 1-216-823-91 CARBON 1.5K 5% 1/16W
R5107 1-216-829-91 CARBON 4.7K 5% 1/16W
R5108 1-216-825-91 CARBON 2.2K 5% 1/16W
R5109 1-249-401-11 CARBON 47 5% 1/4W
R5110 1-247-895-91 CARBON 470K 5% 1/4W
R5111 1-247-895-91 CARBON 470K 5% 1/4W
R5112 1-249-406-11 CARBON 120 5% 1/4W
R5113 1-249-406-11 CARBON 120 5% 1/4W
R5114 1-249-406-11 CARBON 120 5% 1/4W
R5115 1-249-406-11 CARBON 120 5% 1/4W
R5116 1-247-807-31 CARBON 100 5% 1/4W
R5117 1-247-807-31 CARBON 100 5% 1/4W
R5119 1-216-815-91 CARBON 330 5% 1/16W
R5120 1-216-841-91 CARBON 47K 5% 1/16W
R5121 1-216-809-91 RES-CHIP 100 5% 1/16W
< SWITCH >
S5101 1-571-532-21 SWITCH, TACTIL
S5102 1-571-532-21 SWITCH, TACTIL
S5103 1-571-532-21 SWITCH, TACTIL
S5104 1-571-532-21 SWITCH, TACTIL
S5105 1-571-532-21 SWITCH, TACTIL
S5106 1-571-532-21 SWITCH, TACTIL
*A-1642-282-A D2 Board, Complete
< CAPACITOR >
C8802 1-117-661-11 FILM 0.15UF 5.00% 250V
C8803 1-117-665-11 FILM 0.33UF 5.00% 250V
< CONNECTOR >
CN8801 *1-778-770-11 CONNECTOR, BOARD TO BOARD (PLUG)
< DIODE >
D8801 8-719-923-60 DIODE MTZJ-T-77-9.1A
D8802 8-719-302-43 DIODE EL1Z
< IC >
IC8801 8-749-010-64 PHOTO COUPLER PC123F2
< COIL >
L8802 1-406-978-21 COIL CHOKE 150UH
D4
< TRANSISTOR >
Q8801 8-729-034-09 TRANSISTOR 2SK2518-01MR
Q8802 8-729-027-59 TRANSISTOR DTC144EKA-T146
Q8803 8-729-027-59 TRANSISTOR DTC144EKA-T146
< RESISTOR >
JR8801 1-216-864-91 SHORT 0
R8803 1-249-441-11 CARBON 100K 5% 1/4W
R8804 1-216-825-91 RES-CHIP 2.2K 5% 1/16W
R8805 1-216-833-91 RES-CHIP 10K 5% 1/16W
R8806 1-216-809-91 RES-CHIP 100 5% 1/16W
*A-1640-434-A D4 Board, Complete
< CAPACITOR >
C1844 1-129-715-00 FILM 0.012UF 5.00% 630V
C1845 1-129-725-00 FILM 0.082UF 5.00% 400V
C1901 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C1903 1-126-964-11 ELECT 10UF 20.00% 50V
C1904 1-137-366-11 MYLAR 0.0022UF 5.00% 50V
C1905 1-137-374-11 MYLAR 0.047UF 5.00% 50V
C1906 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C1911 1-109-954-11 ELECT 0.47UF 20.00% 160V
C1913 1-129-992-00 FILM 0.0024UF 5.00% 630V
C1914 1-102-244-00 CERAMIC 220PF 10.00% 500V
C1915 1-136-205-11 MYLAR 0.022UF 10.00% 250V
C1917 1-102-228-00 CERAMIC 470PF 10.00% 500V
C1951 1-126-964-11 ELECT 10UF 20.00% 50V
C1952 1-126-964-11 ELECT 10UF 20.00% 50V
C1953 1-130-489-00 MYLAR 0.033UF 5.00% 50V
C1954 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C1955 1-125-779-21 CAP, CERAMIC 0.022MF B (1608)
C1957 1-126-964-11 ELECT 10UF 20.00% 50V
C1958 1-136-169-00 FILM 0.22UF 5.00% 50V
C1959 1-136-169-00 FILM 0.22UF 5.00% 50V
< CONNECTOR >
CN1701 *1-764-333-11 PLUG, CONNECTOR 10P
CN1702 *1-564-506-51 PLUG, CONNECTOR 3P
CN1809 1-695-915-11 TAB (CONTACT)
< DIODE >
D1840 8-719-302-43 DIODE EL1Z
D1901 8-719-991-33 DIODE 1SS133T-77
D1902 8-719-991-33 DIODE 1SS133T-77
D1903 8-719-991-33 DIODE 1SS133T-77
D1904 8-719-991-33 DIODE 1SS133T-77
D1905 8-719-110-41 DIODE RD15ES-B2
D1906 8-719-970-87 DIODE ERA38-06
