Sony Trinitron KV-24LS35B - Page 48

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
60
D1907 8-719-970-87 DIODE ERA38-06
D1908 8-719-300-33 DIODE RU-3AM
D1909 8-719-991-33 DIODE 1SS133T-77
< IC >
IC1901 8-759-450-95 IC LM393N
IC1902 8-759-008-70 IC LM358N
< COIL >
L1843 1-406-989-21 INDUCTOR 10MH
L1901 1-406-677-11 INDUCTOR 10MH
L1959 1-406-679-11 INDUCTOR 22MH
< TRANSISTOR >
Q1840 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q1841 8-729-039-68 TRANSISTOR IRF620
Q1901 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1902 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1903 8-729-043-95 TRANSISTOR 2SC3840(3)
Q1904 8-729-026-49 TRANSISTOR 2SA1037AK-T146
Q1906 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1907 8-729-140-97 TRANSISTOR 2SB734-34
< RESISTOR >
R1842 1-216-809-11 RES-CHIP 100 5% 1/16W
R1846 1-216-825-11 RES-CHIP 2.2K 5% 1/16W
R1847 1-215-911-11 METAL OXIDE 100 5% 3W
R1848 1-215-911-11 METAL OXIDE 100 5% 3W
R1901 1-216-841-11 RES-CHIP 47K 5% 1/16W
R1903 1-216-833-11 RES-CHIP 10K 5% 1/16W
R1904 1-216-839-11 RES-CHIP 33K 5% 1/16W
R1905 1-216-845-11 RES-CHIP 100K 5% 1/16W
R1906 1-216-825-11 RES-CHIP 2.2K 5% 1/16W
R1907 1-216-845-11 RES-CHIP 100K 5% 1/16W
R1908 1-216-813-11 RES-CHIP 220 5% 1/16W
R1909 1-215-489-00 METAL 680K 1% 1/4W
R1910 1-216-864-11 SHORT 0
R1911 1-216-833-11 RES-CHIP 10K 5% 1/16W
R1912 1-216-857-11 RES-CHIP 1M 5% 1/16W
R1913 1-216-821-11 RES-CHIP 1K 5% 1/16W
R1914 1-216-825-11 RES-CHIP 2.2K 5% 1/16W
R1915 1-216-829-11 RES-CHIP 4.7K 5% 1/16W
R1916 1-216-830-11 RES-CHIP 5.6K 5% 1/16W
R1917 1-216-825-91 RES-CHIP 2.2K 5% 1/16W
R1918 1-215-921-11 METAL OXIDE 4.7K 5% 3W
R1919 1-216-833-11 RES-CHIP 10K 5% 1/16W
R1920 1-216-295-91 SHORT 0
R1921 1-215-921-11 METAL OXIDE 4.7K 5% 3W
R1922 1-215-919-11 METAL OXIDE 2.2K 5% 3W
R1923 1-216-097-91 RES-CHIP 100K 5% 1/10W
R1924 1-216-097-91 RES-CHIP 100K 5% 1/10W
R1925 1-216-097-91 RES-CHIP 100K 5% 1/10W
R1953 1-216-841-91 RES-CHIP 47K 5% 1/16W
R1954 1-216-851-11 RES-CHIP 330K 5% 1/16W
R1955 1-216-849-11 RES-CHIP 220K 5% 1/16W
R1956 1-216-858-11 RES-CHIP 1.2M 5% 1/16W
R1957 1-216-833-11 RES-CHIP 10K 5% 1/16W
R1958 1-216-809-11 RES-CHIP 100 5% 1/16W
R1959 1-216-828-11 RES-CHIP 3.9K 5% 1/16W
R1960 1-216-837-91 RES-CHIP 22K 5% 1/16W
R1961 1-216-839-91 RES-CHIP 33K 5% 1/16W
R1962 1-216-839-11 RES-CHIP 33K 5% 1/16W
R1964 1-216-809-11 RES-CHIP 100 5% 1/16W
R1965 1-216-817-11 RES-CHIP 470 5% 1/16W
R1966 1-216-450-00 METAL OXIDE 82 5% 2W
R1967 1-216-485-11 METAL OXIDE 5.6K 5% 3W
R1968 1-216-450-00 METAL OXIDE 82 5% 2W
R1969 1-216-485-11 METAL OXIDE 5.6K 5% 3W
< TRANSFORMER >
T1901 1-424-584-11 TRANSFORMER, DYNAMIC FOCUS
D4
