Sony Trinitron KV-25K5A - SECTION 6 EXPLODED VIEWS; Picture Tube

6-2. PICTURE TUBE
REF. NO. PART.NO DESCRIPTION
REF. NO,
51 X-4200-306-5 | BEZNET ASSY
(KV-25K5A/25K5B/25K5D/25K5E/25K5U)
51 X-4200-305-7 | BEZNET ASSY
(KV-29K5A/29K5B/29K5D/29K5E/25K5U)
52 4-047-464-01 CATCHER PUSH
53 4-203-693-11 DOOR, ORNAMENTAL (KV-29K5A)
4-203-693-21 DOOR, CONTROL (KV-25K5B/25K5E/25K5U/
29K5B/29K5E/29K5U)
4-203-693-31 DOOR, CONTROL (KV-25K5A/25K5D/29K5D)
4-203-693-31 DOOR, CONTROL (KV-25K5A/25K5D/29K5D)
54 4-204-071-01 PLATE, ORNAMENTAL
55 4-203-704-01 BUTTON POWER
56 4-202-964-01 | SPRING
57 GUIDE, LIGH
67
PART.NO
KV-25K5/29K5
Note : Les composants indentifies par une
trame et par une marque 4 sonte
d'une importance critiquepour la
securite. Ne les remplacer que par
des pieces du numero specifie.
The components identified by shading
and marked & are critica for safety.
Replace only with the pat numbers
specified in the parts list.
DESCRIPTION REMARK
*A-1644-090-A
*A-1638-112-A
8-31
4-369-31
ee
4-203-390-01
4-203-877-01
4-203-878-01
1-505-484-11
1-505-674-11
1-505-673-11
4-039-358-01
4-308-870-00
1-452-094-00
1-452-032-00
X-4387-214-1
3-701-007-00
VM BOARD, COMPLETE
(KV-29K5A/29K5B/29K5D/29KS5E/2 9K5U)
C BOARD, COMPLETE
CUSHION, DGC
HOLDER, DGC BRACKET 25”
(KV-25K5A/25K5B/25K5D/25K5E2 SK5U)
HOLDER, DGC BRACKET 29”
(KV-29K5A/29K5B/29K5D/29K5E2 OK5U)
SPEAKER (2. 6CM)
SPEAKER MID RANGE (8CM)
SPEAKER WOOFER (10CM)
SCREW (4X16), (+) BV TAPPIN
CLIP, LEAD WIRE
MAGNET, ROTATABLE DISK; 156 @
MAGNET, DISK; 10MM 9
PERMALLOY ASSY, CORRECTION
BAND, BINDING
Pires ree smane rot
