— 23 —
KV-27FV16/29FV16/29FV16C/32FS12/32FS16
Reg # ITEM FUNCTION RANGE
FIX
DATA NTSC 27 PAL M PAL N VIDEO NTSC 32 RF
A
VERAGE
DATA
27FV
A
VERAGE
DATA
32FS
1 HSIZ Horizontal Size Adjustment 0-63 15 12 7 18 11 22
2 HPOS Horizontal Position Adjustment 0-63 13 8 9 13 20 22
3 VBOW Vertical Line Bowing Adj. 0-15 9 10 8 9 7 9
4 VANG Vertical Line Bowing Slant Adj. 0-15 8 10 9 3 9 7
5 VTRP TRAPEZIUM 0-31 19 14 14 18 21 17
6 HTRP Horiz. Trapezoid 0-15 6 7 5 6 0 2
7 TROT Tilt Correction 0-63 31 31 31 31 31 31
8 PAMP Horizontal PIN distortion Adj. 0-63 19 19 21 27 20 27
9 UPIN Upper PIN Distortion Adj. 0-63 34 33 36 41 37 38
10 LPIN Lower PIN Distortion Adj. 0-63 32 34 40 39 33 35
11 VSIZ Vertical Size Adjustment 0-63 32 43 29 51 33 51
12 VPOS Vertical Position Adj. 0-63 30 30 32 42 36 39
13 VLIN Vertical lineality Adj. 0-15 3 6 10 5 3 4
14 SCOR Vertical "S" Correction Adjustment 0-15 6 8 10 8 8 8
15 VZOM 16:9 CRT Z Mode on/off 0-1 0 00
16 EHT Vertical High-Voltage Compensation 0-15 5 55
17 ASP Aspect Ratio control 0-63 47 47 47
18 SCRL 16:9 CRT Z Mode Trans. Scroll 0-63 31 31 31
19 HBLK Horizontal Blanking on/off 0-1 1 11
20 LBLK Left Blanking Adjustment 0-15 13 13 13
21 RBLK Rigth Blanking Adjustment 0-15 8 78
22 HDW Horizontal Drive Pulse Width 1 11
23 EWDC "Parabola" EW, D.C. Adjustment 0-1 0 00
24 LVLN Lower Screen BTM Vertical Line Adj. 0-15 0 00
25 UVLN Uppe Screen BTM Vertical Line Adj. 0-15 0 00
26 INTL INTERLACE 0-3 0 00
27 G2SW 0-1 0 00
28 G2LV 0-7 0 00
29 HOSC Horizontal VCO Oscillation Freq. 0-15 7 77
30 VSS Vertical Sync Slice Level 0-3 0 00
31 HSS Horizontal Sync Slice Level 0-1 0 00
32 HMSK For Macro Vision 0-1 0 00
33 VTMS Select Signal VTIM Pin 0-3 0 00
34 CDMD Vertical Count Down Mode Switching 0-3 ***333
35 AFC AFC Loop Gain Switching 0-3 0 00
36 FIFR Field Frequency 0-3 ** 33
37 VBLK VBLKW 0-3 0 00
38 REFP REFP 0-1 0 00
39 JPSW JUMPSW 0-1 MENU 0 0
40 RDRV R Output Drive control 0-63 *** 31 40
41 GDRV G Output Drive control 0-63 25 22 42
42 BDRV B Output Drive control 0-63 25 21 31
43 RCUT R Output Cutoff control 0-63 31 31 31
44 GCUT G Output Cutoff control 0-63 15 13 12
45 BCUT B Output Cutoff control 0-63 12 14 15
46 SCON SUB CONT 0-15 8 11 11
47 SHUE Sub HUE adjustment 0-15 16 17 16
48 SCOL Sub COLOR adjustment 0-15 16 16 16 17 18
49 SBRT Sub BRIGHTNESS adjustment 0-31 16 15 16
50 CHUE SUB COLOR (RF) 0-31 7 66
51 CCOL SUB COLOR (RF) 0-31 7 7 7 7 4
52 UOFS YUV U OFFSET 0-15 7 77
53 VOFS YUV V OFFSET 0-15 7 77
54 RON R Output on/off 0-1 1 11
55 GON G Output on/off 0-1 1 11
56 BON B Output on/off 0-1 1 11
57 AXPL Axis PAL 0-1 0 00
58 AXNT Axis NTSC 0-1 1 11
59 CBPF Chroma BPF on/off 0-1 1 11
60 CTRP Y TRAP FILTER on/off 0-1 1 11
61 COFF Color On/off 0-1 0 00
62 KOFF Set Color Killer 0-1 0 00
63 SSHP Sub SHARPNESS 0-15 5 55
64 SHPF SHARPNESS Circuit Fo 0-3 Palette 2 2
65 PREL Pre-Shoot/ Over-Shoot 0-1 1 00
66 Y-DC DC transmition Ratio Switching 0-3 Palette 2 2
67 GAMM Gamma Correction 0-3 Palette 2 2
68 ABLM ABL Mode Switch 0-1 1 11
69 VTH ABL CD VHT Switching 0-1 1 11
70 YDEL Y Delay Time Control 0-15 7 77
71 NCOL No Color ID 0-1 1 11
72 FSC FSC Out on/off 0-1 1 11
73 K-ID Killer ID Control on/off 0-1 0 00
74 GDOF 0-31 3 33
75 BDOF 0-31 16 16 16
76 GCOF 0-31 16 16 16
77 BCOF 0-31 7 77
78 SYSC Color System 0-7 4 44
79 VENH Vertical Enhancement 0-7 Palette 5 3
Adjustment Items
