Sony TRINITRON KV-27FV16 - Page 24

— 24 —
KV-27FV16/29FV16/29FV16C/32FS12/32FS16
Reg # ITEM FUNCTION RANGE
FIX
DATA NTSC 27 PAL M PAL N VIDEO NTSC 32 RF
A
VERAGE
DATA
27FV
AVERAGE
DATA
32FS
80 PDSO PDS OFF 0-1 0 00
81 CK CK 0-1 0 00
82 VNL VNL 0-15 3 33
83 HPK HPK 0-1 0 00
84 HPKO HPK OFF 0-1 Palette 0 0
85 CORE CORE 0-3 2 11
86 TRAP TRAP 0-1 1 11
87 CHTR CH TRAP 0-1 0 00
88 CBPF CBPF 0-1 1 11
89 ENHO ENHOFF 0-1 0 00
90 NMRD NMRD 0-3 0 00
91 YAPS YAPS 0-3 3 33
92 CLKS CLKS 0-3 0 00
93 NSTD NSTDS 0-3 0 00
94 MSS MSS 0-3 0 00
95 KILS KILS 0-3 1 11
96 ADIN ADIN 0-1 0 00
97 EXCS EXCSS 0-3 1 11
98 CPP CPP 0-3 2 22
99 HDP HDP 0-7 4 44
100 CDL CDL 0-7 4 44
101 DYCR DYCOR 0-15 2 22
102 DYGN DYGAIN 0-15 10 10 10
103 DCCR DCCOR 0-15 3 33
104 DCGN DCGAIN 0-15 6 66
105 YNRL YNRLIM 0-3 1 11
106 CNRL CNRLIM 0-3 1 11
107 WSC WSC 0-3 1 11
108 VTRH VTRH 0-3 1 11
109 VTRR VTRR 0-3 1 11
110 LDSR LDSR 0-3 2 22
111 VAPG VAPGAIN 0-7 3 33
112 VAPI VAPINV 0-31 6 66
113 TEST TEST 0-1 0 00
114 YPFT YPFT 0-3 3 33
115 YPFG YPFG 0-15 7 77
116 CC3N CC3N 0-1 0 00
117 SELD 0-1 1 11
118 D2GN D2GAIN 0-7 4 55
119 YHCR YHCOR 0-3 0 00
120 YPFC YPFCOR 0-1 0 00
121 SHT SHT 0-3 0 00
122 MVT MVT 0-1 0 00
123 OTT OTT 0-1 0 00
124 CL2D CL2D 0-1 1 11
125 CLKG CLKGGT 0-1 0 00
126 HPLL HPLLFS 0-1 1 11
127 BPLL BPLLFS 0-1 0 00
128 FSCF FSCFG 0-1 0 00
129 PLLS PLLS 0-1 1 11
130 KILR KILR 0-15 3 33
131 HSSL HSSL 0-15 12 12 12
132 VSSL VSSL 0-15 8 88
133 BGPS BGPS 0-15 4 44
134 BGPW BGPW 0-15 10 10 10
135 ADCK ADCLKS 0-3 3 33
136 NDSW NSDSW 0-1 1 11
137 PFRN FREE_RUN 0-1 0 00
138 PRVS RVS 0-1 0 00
139 PCON CONTRAST 0-127 45 45 45
140 PUCO U-DAC 0-127 16 16 16
141 PVCO V-DAC 0-127 24 24 24
142 PHUE 0-31 15 15 15
143 PKIL KILLER 1 0 00
144 PSEP EXT_SC_SEL 0-3 2 22
145 PHIM 0-1 0 00
146 PSUB 0-1 0 00
147 PBGS BG_START 0-63 14 14 14
148 PDL0 0-15 6 66
149 PDL1 0-15 13 13 13
150 PBRT Y_OFFSET 0-31 25 25 25
151 PVP1 0 00
152 PUP1 0 00
153 PVP2 0 00
154 PUP2 0 00
155 PVP3 0 00
156 PUP3 0 00
157 PACS SET_ACC 0-1 1 11
158 PSDL SYNC_DELAY 0-3 0 00
