74
KV-29FX11
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
C225 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C226 1-126-967-11 ELECT 47MF 20% 16V
C227 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C228 1-126-967-11 ELECT 47MF 20% 16V
C229 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C230 1-216-295-00 SHORT 0
C233 1-126-967-11 ELECT 47MF 20% 16V
C238 1-126-967-11 ELECT 47MF 20% 16V
C239 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V
C242 1-164-489-91 CERAMIC CHIP 0.22MF 10% 16V
C243 1-164-489-91 CERAMIC CHIP 0.22MF 10% 16V
C251 1-163-087-00 CERAMIC CHIP 4PF 0.25PF 50V
C252 1-163-087-00 CERAMIC CHIP 4PF 0.25PF 50V
C253 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C254 1-163-109-00 CERAMIC CHIP 47PF 5% 50V
C255 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C256 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C257 1-126-965-11 ELECT 22MF 20% 50V
C258 1-126-964-11 ELECT 10MF 20% 50V
C259 1-164-336-11 CERAMIC CHIP 0.33MF 25V
C260 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C261 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C262 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C263 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C264 1-126-962-11 ELECT 3.3MF 20% 50V
C265 1-126-964-11 ELECT 10MF 20% 50V
C266 1-126-964-11 ELECT 10MF 20% 50V
C267 1-126-965-11 ELECT 22MF 20% 50V
C268 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C269 1-163-131-00 CERAMIC CHIP 390PF 5% 50V
C270 1-163-131-00 CERAMIC CHIP 390PF 5% 50V
C271 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V
C272 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V
C273 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V
C274 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V
C275 1-164-346-11 CERAMIC CHIP 1MF 16V
C276 1-164-346-11 CERAMIC CHIP 1MF 16V
C277 1-164-346-11 CERAMIC CHIP 1MF 16V
C278 1-164-346-11 CERAMIC CHIP 1MF 16V
C279 1-126-965-11 ELECT 22MF 20% 50V
C280 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C281 1-126-965-11 ELECT 22MF 20% 50V
C282 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C283 1-163-123-00 CERAMIC CHIP 180PF 5% 50V
C284 1-163-123-00 CERAMIC CHIP 180PF 5% 50V
C285 1-163-035-91 CERAMIC CHIP 4700PF 5% 50V
C286 1-163-035-91 CERAMIC CHIP 4700PF 5% 50V
C300 1-163-109-00 CERAMIC CHIP 47PF 5% 50V
C301 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C302 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V
C303 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V
C304 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C305 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C306 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C307 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C308 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C309 1-164-346-11 CERAMIC CHIP 1MF 16V
C310 1-164-346-11 CERAMIC CHIP 1MF 16V
C311 1-164-346-11 CERAMIC CHIP 1MF 16V
C312 1-164-505-11 CERAMIC CHIP 2.2MF 16V
C313 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V
C315 1-216-295-00 SHORT 0
C317 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C319 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C320 1-126-965-11 ELECT 22MF 20% 50V
C321 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C322 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C323 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C324 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C325 1-164-346-11 CERAMIC CHIP 1MF 16V
C326 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V
C327 1-136-167-91 FILM 0.15MF 5% 50V
C328 1-126-965-11 ELECT 22MF 20% 50V
C332 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C333 1-126-933-11 ELECT 100MF 20% 16V
C334 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C335 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C336 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C337 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C338 1-164-346-11 CERAMIC CHIP 1MF 16V
C339 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C340 1-126-933-11 ELECT 100MF 20% 16V
C341 1-164-005-11 CERAMIC CHIP 0.47MF 25V
C342 1-164-346-11 CERAMIC CHIP 1MF 16V
C343 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C344 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C347 1-164-005-11 CERAMIC CHIP 0.47MF 25V
C348 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C350 1-126-964-11 ELECT 10MF 20% 50V
C351 1-164-505-11 CERAMIC CHIP 2.2MF 16V
C352 1-164-005-11 CERAMIC CHIP 0.47MF 25V
C353 1-164-505-11 CERAMIC CHIP 2.2MF 16V
C354 1-164-005-11 CERAMIC CHIP 0.47MF 25V
C355 1-126-965-11 ELECT 22MF 20% 50V
