Sony TRINITRON KV-29FX11D - A Board Component List

73
KV-29FX11
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
SECTION 7
ELECTRICAL PARTS LIST
• Items marked “ * “ are not stocked since
they are seldom required for routine serv-
ice. Some delay should be anticipated
when ordering these items.
•
• All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
• RESISTORS
• All resistors are in ohms.
• F : nonflammable.
When indicating parts by reference number,
please include the board
name.
CAPACITORS COILS
MF : mF, PF : mmF MMH : mH , uH
A
*A-1632-783-A A BOARD, COMPLETE (KV-29FX11A)
*****************
*A-1632-782-A A BOARD, COMPLETE (KV-29FX11B)
*****************
*A-1632-769-A A BOARD, COMPLETE (KV-29FX11D)
*****************
*A-1632-784-A A BOARD, COMPLETE (KV-29FX11E)
*****************
*A-1632-785-A A BOARD, COMPLETE (KV-29FX11K)
*****************
*A-1632-786-A A BOARD, COMPLETE (KV-29FX11R)
*****************
*A-1632-781-A A BOARD, COMPLETE (KV-29FX11U)
*****************
1-750-797-11 SOCKET, PLCC
< CAPACITOR >
C1 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C2 1-126-967-11 ELECT 47MF 20% 16V
C3 1-163-104-00 CERAMIC CHIP 30PF 5% 50V
C4 1-163-104-00 CERAMIC CHIP 30PF 5% 50V
C8 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C14 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C15 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C18 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C19 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C20 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C21 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C22 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C24 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V
C45 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C80 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C81 1-126-959-11 ELECT 0.47MF 20% 50V
C82 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C90 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C101 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C102 1-126-934-11 ELECT 220MF 20% 16V
C103 1-126-965-11 ELECT 22MF 20% 50V
C104 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C110 1-126-967-11 ELECT 47MF 20% 16V
C112 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V
C113 1-126-967-11 ELECT 47MF 20% 16V
C120 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C121 1-163-113-00 CERAMIC CHIP 68PF 5% 50V
C122 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C123 1-163-113-00 CERAMIC CHIP 68PF 5% 50V
C124 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C125 1-163-141-91 CERAMIC CHIP 1000PF 5% 50V
C144 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C201 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C202 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C203 1-104-661-91 ELECT 330MF 20% 16V
C204 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C205 1-126-965-11 ELECT 22MF 20% 50V
C207 1-126-964-11 ELECT 10MF 20% 50V
C208 1-126-964-11 ELECT 10MF 20% 50V
C209 1-126-964-11 ELECT 10MF 20% 50V
C210 1-216-295-00 SHORT 0
C211 1-126-964-11 ELECT 10MF 20% 50V
C212 1-164-346-11 CERAMIC CHIP 1MF 16V
C213 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C214 1-164-346-11 CERAMIC CHIP 1MF 16V
C215 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C216 1-126-967-11 ELECT 47MF 20% 16V
C217 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C218 1-126-967-11 ELECT 47MF 20% 16V
C219 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C220 1-126-964-11 ELECT 10MF 20% 50V
C221 1-164-505-11 CERAMIC CHIP 2.2MF 16V
C222 1-164-346-11 CERAMIC CHIP 1MF 16V
C223 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C224 1-164-346-11 CERAMIC CHIP 1MF 16V
