The parts on this page belong to the following model(s) only:
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
— 81 —
S SERIES
BOARD VARIANT PARTS LIST
A
KV-32S45/34SL45
* A-1298-631-A A BOARD, COMPLETE
CAPACITOR
C370 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C513 ¡ 1-130-895-00 FILM 0.056MF 5% 400V
C514 ¡ 1-104-844-11 FILM 0.62MF 5% 200V
C520 1-164-645-11 CERAMIC CHIP 1000PF 10% 500V
C521 1-164-161-11 CERAMIC CHIP 0.0022MF 10% 50V
C537 1-126-941-11 ELECT 470MF 20% 25V
C539 ¡ 1-126-935-11 ELECT 470MF 20% 16V
C1241 1-136-161-00 FILM 0.047MF 5% 50V
C1242 1-126-960-11 ELECT 1MF 20% 50V
C1243 1-126-960-11 ELECT 1MF 20% 50V
C1501 1-115-462-11 FILM 0.12MF 5% 200V
CONNECTOR
CN1001* 1-564-512-11 PLUG, CONNECTOR 9P
CN3001 1-573-298-11 CONNECTOR, BOARD TO BOARD
DIODE
D368 8-719-991-33 DIODE 1SS133T-77
IC
IC1261 8-759-534-81 IC MM1313AD
JACK
J1233 1-774-749-11 JACK BLOCK, PIN
RESISTOR
R012 1-216-033-00 RES, CHIP 220 5% 1/10W
R022 1-249-429-11 CARBON 10K 5% 1/4W
R031 1-247-815-91 CARBON 220 5% 1/4W
R358 1-247-815-91 CARBON 220 5% 1/4W
R359 1-247-815-91 CARBON 220 5% 1/4W
R360 1-247-815-91 CARBON 220 5% 1/4W
R365 1-216-101-00 RES, CHIP 150K 5% 1/10W
R374 1-216-125-00 RES, CHIP 1.5M 5% 1/10W
R386 1-216-049-91 RES, CHIP 1K 5% 1/10W
R469 1-216-069-00 RES, CHIP 6.8K 5% 1/10W
R472 1-216-069-00 RES, CHIP 6.8K 5% 1/10W
R511 ¡ 1-215-885-00 METAL 68 5% 2W
R515 1-216-083-00 RES, CHIP 27K 5% 1/10W
A BOARD VARIANT LIST: KV-32S45/34SL45
R523 1-216-073-00 RES, CHIP 10K 5% 1/10W
R529 1-208-814-11 RES, CHIP 22K 0.50% 1/10W
R531 ¡ 1-208-826-11 RES, CHIP 68K 0.50% 1/10W
R533 ¡ 1-215-902-11 METAL 47K 5% 1W
R535 1-216-101-00 RES, CHIP 150K 5% 1/10W
R546 1-215-453-00 METAL 22K 1% 1/4W
R1249 1-216-022-00 RES, CHIP 75 5% 1/10W
R1250 1-216-113-00 RES, CHIP 470K 5% 1/10W
R1251 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R1252 1-216-113-00 RES, CHIP 470K 5% 1/10W
R1253 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R1273 1-216-033-00 RES, CHIP 220 5% 1/10W
R1274 1-216-025-91 RES, CHIP 100 5% 1/10W
R1283 1-247-791-91 CARBON 22 5% 1/4W
R1297 1-216-025-91 RES, CHIP 100 5% 1/10W
TRANSFORMER
T502 ¡ 1-424-545-11 TRANSFORMER FERRITE (PMT)
T503 ¡ 1-453-207-11 FLYBACK TRANSFORMER ASSY, NX-2609//X4C
TUNER
TU102 ¡ 8-598-431-00 TUNER, FSS BTF-WA411
[
Note:
The components identified by
[
in this
manual have been carefully factory-selected
for each set in order to satisfy regulations re-
garding X-ray radiation. Should replacement
be required, replace only with the value origi-
nally used.
Note:
The components identified
with shading and a critical
symbol (
¡¡
¡¡
¡
) are critical for
safety. Replace only with
part number specified.
