The parts on this page belong to the following model(s) only:
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
— 92 —
V SERIES
BOARD VARIANT PARTS LIST
A
KV-34VL65C/34VL65/32V65CND
A BOARD VARIANT LIST:
KV-34VL65C/34VL65/32V65CND
* A-1298-613-A A BOARD COMPLETE
CAPACITOR
C461 1-126-966-11 ELECT 33MF 20% 16V
C478 1-126-934-11 ELECT 220MF 20% 16V
C513 ¡ 1-130-895-00 FILM 0.056MF 5% 400V
C514 ¡ 1-104-844-11 FILM 0.62MF 5% 200V
C520 1-164-645-11 CERAMIC CHIP 1000PF 10% 500V
C521 1-164-161-11 CERAMIC CHIP 0.0022MF 10% 50V
C537 1-126-941-11 ELECT 470MF 20% 25V
C539 ¡ 1-126-935-11 ELECT 470MF 20% 16V
C1501 1-115-462-11 FILM 0.12MF 5% 200V
CONNECTOR
CN461 1-564-508-11 PLUG, CONNECTOR 5P
CN1101 1-573-298-11 CONNECTOR, BOARD TO BOARD
CN3001 1-573-298-11 CONNECTOR, BOARD TO BOARD
DIODE
D368 8-719-991-33 DIODE 1SS133T-77
CHIP CONDUCTOR
JR001 1-216-295-91 SHORT
JR201 1-216-295-91 SHORT
JR202 1-216-295-91 SHORT
JR463 1-216-295-91 SHORT
COIL
L461 1-408-612-31 INDUCTOR 56UH
TRANSISTOR
Q1103 8-729-422-27 TRANSISTOR 2SD601A-Q
RESISTOR
R006 1-247-815-91 CARBON 220 5% 1/4W
R008 1-247-815-91 CARBON 220 5% 1/4W
R012 1-216-033-00 RES,CHIP 220 5% 1/10W
R031 1-247-815-91 CARBON 220 5% 1/4W
R040 1-247-815-91 CARBON 220 5% 1/4W
R041 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R042 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R045 1-247-815-91 CARBON 220 5% 1/4W
R088 1-216-033-00 RES,CHIP 220 5% 1/10W
R090 1-216-033-00 RES,CHIP 220 5% 1/10W
R358 1-247-815-91 CARBON 220 5% 1/4W
R359 1-247-815-91 CARBON 220 5% 1/4W
R360 1-247-815-91 CARBON 220 5% 1/4W
R386 1-216-049-91 RES,CHIP 1K 5% 1/10W
R466 1-249-382-11 CARBON 1.2 5% 1/4W
R511 ¡ 1-215-885-00 METAL 68 5% 2W
R515 1-216-083-00 RES, CHIP 27K 5% 1/10W
R523 1-216-073-00 RES,CHIP 10K 5% 1/10W
R529 1-208-814-11 RES,CHIP 22K 0.50% 1/10W
R531 ¡ 1-208-826-11 RES,CHIP 68K 0.50% 1/10W
R533 ¡ 1-215-902-11 METAL 47K 5% 1W
R546 1-215-453-00 METAL 22K 1% 1/4W
TRANSFORMER
T502 ¡ 1-424-545-11 TRANSFORMER FERRITE (PMT)
T503 ¡ 1-453-207-11 FLYBACK TRANSFORMER ASSY, NX-2609//X4C
Note:
The components identified by
[
in this
manual have been carefully factory-selected
for each set in order to satisfy regulations re-
garding X-ray radiation. Should replacement
be required, replace only with the value origi-
nally used.
Note:
The components identified
with shading and a critical
symbol (
¡¡
¡¡
¡
) are critical for
safety. Replace only with
part number specified.
[
