Sony Trinitron KV-35S45 - Kv-34 Sl40 T

The parts on this page belong to the following model(s) only:
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
— 84 —
S SERIES
BOARD VARIANT PARTS LIST
A
KV-34SL40T
A BOARD VARIANT LIST: KV-34SL40T
* A-1298-661-A A BOARD, COMPLETE
CAPACITOR
C068 1-164-096-11 CERAMIC CHIP 0.01MF 50V
C370 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C375 1-165-319-11 CERAMIC CHIP 0.1MF 50V
C513 ¡ 1-130-895-00 FILM 0.056MF 5% 400V
C514 ¡ 1-104-844-11 FILM 0.62MF 5% 200V
C520 1-164-645-11 CERAMIC CHIP 1000PF 10% 500V
C521 1-164-161-11 CERAMIC CHIP 0.0022MF 10% 50V
C537 1-126-941-11 ELECT 470MF 20% 25V
C539 ¡ 1-126-935-11 ELECT 470MF 20% 16V
C1501 1-115-462-11 FILM 0.12MF 5% 200V
DIODE
D005 8-719-991-33 DIODE 1SS133T-77
D006 1-810-039-31 LED UNIT
IC
IC003 8-742-014-11 HYB IC SBX1981-51
IC1261 8-759-366-77 IC MM1311AD
CHIP CONDUCTOR
JR351 1-216-295-91 SHORT
JR352 1-216-295-91 SHORT
JR1264 1-216-295-91 SHORT
RESISTOR
R059 1-216-047-91 RES, CHIP 820 5% 1/10W
R060 1-216-049-91 RES, CHIP 1K 5% 1/10W
R061 1-216-055-00 RES, CHIP 1.8K 5% 1/10W
R062 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R063 1-216-073-00 RES, CHIP 10K 5% 1/10W
R365 1-216-101-00 RES, CHIP 150K 5% 1/10W
R374 1-216-125-00 RES, CHIP 1.5M 5% 1/10W
R469 1-216-069-00 RES, CHIP 6.8K 5% 1/10W
R472 1-216-069-00 RES, CHIP 6.8K 5% 1/10W
R511 ¡ 1-215-885-00 METAL 68 5% 2W
R515 1-216-083-00 RES, CHIP 27K 5% 1/10W
R523 1-216-073-00 RES, CHIP 10K 5% 1/10W
R529 1-208-814-11 RES, CHIP 22K 0.50% 1/10W
R531 ¡ 1-208-826-11 RES, CHIP 68K 0.50% 1/10W
R533 ¡ 1-215-902-11 METAL 47K 5% 1W
R535 1-216-101-00 RES, CHIP 150K 5% 1/10W
R546 1-215-453-00 METAL 22K 1% 1/4W
R1009 1-216-033-00 RES, CHIP 220 5% 1/10W
R1010 1-216-033-00 RES, CHIP 220 5% 1/10W
SWITCH
S001 1-692-431-21 SWITCH, TACTILE
S002 1-692-431-21 SWITCH, TACTILE
S003 1-692-431-21 SWITCH, TACTILE
S004 1-692-431-21 SWITCH, TACTILE
S005 1-692-431-21 SWITCH, TACTILE
S006 1-692-431-21 SWITCH, TACTILE
S007 1-692-431-21 SWITCH, TACTILE
TRANSFORMER
T502 ¡ 1-424-545-11 TRANSFORMER, FERRITE (PMT)
T503 ¡ 1-453-207-11 FLYBACK TRANSFORMER ASSY, NX-2609//X4C
TUNER
TU102 ¡ 8-598-477-00 FSS TUNER BTF-WG411
Note:
The components identified by [ in this
manual have been carefully factory-selected
for each set in order to satisfy regulations re-
garding X-ray radiation. Should replacement
be required, replace only with the value origi-
nally used.
Note:
The components identified
with shading and a critical
symbol (
¡¡
¡¡
¡ ) are critical for
safety. Replace only with
part number specified.
[
