The parts on this page belong to the following model(s) only:
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
— 91 —
V SERIES
BOARD VARIANT PARTS LIST
A
KV-32V40
refno1 partno1 descrip1 volt-
age1 percent1
A-1298-611-AA COMPLETE
BOARD
C1501 1-115-462-11 FILM 5% 200V
C461 1-126-964-11 ELECT 20%
50V
C462 1-126-961-11 ELECT 20%
50V
C463 1-126-961-11 ELECT 20%
50V
C464 1-163-017-00 CERAMIC CHIP
10% 5 0 V
C466 1-104-666-11 ELECT 20%
25V
C467 1-163-017-00 CERAMIC CHIP
10% 5 0 V
C468 1-104-664-11 ELECT 20%
25V
C470 1-126-961-11 ELECT 20%
50V
C471 1-104-666-11 ELECT 20%
25V
C472 1-136-173-00 FILM 5% 5 0 V
C473 1-136-169-00 FILM 5% 5 0 V
C474 1-126-942-61 ELECT 20%
25V
C475 1-136-169-00 FILM 5% 5 0 V
C476 1-126-942-61 ELECT 20%
25V
C477 1-126-942-61 ELECT 20%
25V
C513 1-130-895-00 FILM 5% 400V
C514 1-104-844-11 FILM 5% 200V
C537 1-126-941-11 ELECT 20%
25V
C539 1-126-935-11 ELECT 20%
16V
C463
1-
126-
961-
11
ELECT
20%
50V
C464
1-
163-
017-
00
CERAMIC
CHIP
10%
50V
C466
1-
104-
666-
11
ELECT
20%
25V
C467
1-
163-
017-
00
CERAMIC
CHIP
10%
50V
C468
1-
104-
664-
A BOARD VARIANT LIST: KV-32V40
* A-1298-611-A A BOARD, COMPLETE
CAPACITOR
C461 1-126-964-11 ELECT 10MF 20% 50V
C462 1-126-961-11 ELECT 2.2MF 20% 50V
C463 1-126-961-11 ELECT 2.2MF 20% 50V
C464 1-163-017-00 CERAMIC 0.0047MF 10% 50V
C466 1-104-666-11 ELECT 220MF 20% 25V
C467 1-163-017-00 CERAMIC 0.0047MF 10% 50V
C468 1-104-664-11 ELECT 47MF 20% 25V
C470 1-126-961-11 ELECT 2.2MF 20% 50V
C471 1-104-666-11 ELECT 220MF 20% 25V
C472 1-136-173-00 FILM 0.47MF 5% 50V
C473 1-136-169-00 FILM 0.22MF 5% 50V
C474 1-126-942-61 ELECT 1000MF 20% 25V
C475 1-136-169-00 FILM 0.22MF 5% 50V
C476 1-126-942-61 ELECT 1000MF 20% 25V
C477 1-126-942-61 ELECT 1000MF 20% 25V
C513 ¡ 1-130-895-00 FILM 0.056MF 5% 400V
C514 ¡ 1-104-844-11 FILM 0.62MF 5% 200V
C520 1-164-645-11 CERAMIC CHIP 1000PF 10% 500V
C521 1-164-161-11 CERAMIC CHIP 0.0022MF 10% 50V
C537 1-126-941-11 ELECT 470MF 20% 25V
C539 ¡ 1-126-935-11 ELECT 470MF 20% 16V
C1501 1-115-462-11 FILM 0.12MF 5% 200V
CONNECTOR
CN461 1-564-507-11 PLUG, CONNECTOR 4P
IC
IC461 8-759-980-43 IC TDA2009A
CHIP CONDUCTOR
JR351 1-216-295-91 SHORT
JR352 1-216-295-91 SHORT
JR1417 1-216-295-91 SHORT
COIL
L461 1-410-472-41 INDUCTOR 15UH
IC LINK
PS461¡ 1-532-984-11 LINK, IC 2A/90V
TRANSISTOR
Q461 8-729-422-27 TRANSISTOR 2SD601A-Q
Q462 8-729-216-22 TRANSISTOR 2SA1162-G
Q1103 8-729-422-27 TRANSISTOR 2SD601A-Q
RESISTOR
R461 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R462 1-216-089-91 RES, CHIP 47K 5% 1/10W
R463 1-249-435-11 CARBON 33K 5% 1/4W
R464 1-216-097-91 RES, CHIP 100K 5% 1/10W
R465 1-249-413-11 CARBON 470 5% 1/4W
R466 1-249-385-11 CARBON 2.2 5% 1/4W
R467 1-216-069-00 RES, CHIP 6.8K 5% 1/10W
R469 1-216-055-00 RES, CHIP 1.8K 5% 1/10W
R470 1-216-077-00 RES, CHIP 15K 5% 1/10W
R471 1-216-069-00 RES, CHIP 6.8K 5% 1/10W
R472 1-216-055-00 RES, CHIP 1.8K 5% 1/10W
R473 1-249-398-11 CARBON 27 5% 1/4W
R474 1-216-077-00 RES, CHIP 15K 5% 1/10W
R475 1-249-430-11 CARBON 12K 5% 1/4W
R476 1-249-430-11 CARBON 12K 5% 1/4W
R477 1-249-398-11 CARBON 27 5% 1/4W
R478 1-249-418-11 CARBON 1.2K 5% 1/4W
R479 1-249-418-11 CARBON 1.2K 5% 1/4W
R480 1-249-385-11 CARBON 2.2 5% 1/4W
R481 1-249-385-11 CARBON 2.2 5% 1/4W
R482 1-249-421-11 CARBON 2.2K 5% 1/4W
R483 1-249-421-11 CARBON 2.2K 5% 1/4W
R511 ¡ 1-215-885-00 METAL 68 5% 2W
R515 1-216-083-00 RES, CHIP 27K 5% 1/10W
R523 1-216-073-00 RES, CHIP 10K 5% 1/10W
R529 1-208-814-11 RES, CHIP 22K 0.50% 1/10W
R531 ¡ 1-208-826-11 RES, CHIP 68K 0.50% 1/10W
R533 ¡ 1-215-902-11 METAL 47K 5% 1W
R546 1-215-453-00 METAL 22K 1% 1/4W
TRANSFORMER
T502 ¡ 1-424-545-11 TRANSFORMER FERRITE (PMT)
T503 ¡ 1-453-207-11 FLYBACK TRANSFORMER ASSY, NX-2609//X4C
Note:
The components identified by
[
in this
manual have been carefully factory-selected
for each set in order to satisfy regulations re-
garding X-ray radiation. Should replacement
be required, replace only with the value origi-
nally used.
Note:
The components identified
with shading and a critical
symbol (
¡¡
¡¡
¡
) are critical for
safety. Replace only with
part number specified.
[
