– 60 –
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
KV-BM142M70
RM-W101
<FUSE>
F600 ! 1-576-232-12 FUSE 5A 250V
<FERRITE BEAD>
FB001 1-410-397-21 FERRITE 1.1UH
FB101 1-414-229-11 FERRITE 0UH
FB603 1-410-397-21 FERRITE 1.1UH
FB608 1-412-911-31 FERRITE 0UH
FB800 1-410-397-21 FERRITE 1.1UH
FB2602 1-410-397-21 FERRITE 1.1UH
<FUSE HOLDER>
FH601 1-533-223-11 FUSE HOLDER 0A 0V
FH602 1-533-223-11 FUSE HOLDER 0A 0V
<IC>
IC001 6-705-441-41 IC TDA11010H/N1B000QL
IC002 6-704-532-01 IC RPM7240-H5
IC003 6-705-864-01 IC CAT24WC16WI-TE13
IC200 6-703-474-01 IC AN17804A
IC601 6-704-263-01 IC STR-F6267S LF1357
IC602 6-703-479-01 IC PQ09RD1SJ00H
IC603 6-703-478-01 IC PQ018EF01SZH
IC604 8-759-231-53 IC TA7805S
IC605 6-705-063-01 IC SE135N-LF38
IC606 8-759-445-59 IC BA033T
IC607 8-759-832-05 IC BA18BC0FP-E2
IC801 6-703-708-01 IC LM2903DT
IC802 6-701-937-01 IC TJM4558CDT
IC804 6-706-023-01 IC AN15524A
<JACK>
J202 1-770-785-13 JACK
J903 1-770-329-13 JACK, PIN 3P
J906 1-817-296-11 PHONO JACK 3P
J908 1-817-295-11 PHONO JACK 2P
<CHIP CONDUCTOR>
JR001 1-216-864-11 SHORT CHIP 0
JR002 1-216-864-11 SHORT CHIP 0
JR003 1-216-864-11 SHORT CHIP 0
JR004 1-216-864-11 SHORT CHIP 0
JR005 1-216-864-11 SHORT CHIP 0
JR007 1-216-864-11 SHORT CHIP 0
JR008 1-216-864-11 SHORT CHIP 0
JR009 1-216-864-11 SHORT CHIP 0
JR012 1-216-864-11 SHORT CHIP 0
JR013 1-216-864-11 SHORT CHIP 0
JR014 1-216-864-11 SHORT CHIP 0
JR015 1-216-864-11 SHORT CHIP 0
JR016 1-216-864-11 SHORT CHIP 0
JR017 1-216-864-11 SHORT CHIP 0
JR018 1-216-864-11 SHORT CHIP 0
JR019 1-216-864-11 SHORT CHIP 0
JR020 1-216-864-11 SHORT CHIP 0
JR024 1-216-864-11 SHORT CHIP 0
JR025 1-216-864-11 SHORT CHIP 0
JR026 1-216-864-11 SHORT CHIP 0
JR027 1-216-864-11 SHORT CHIP 0
JR036 1-216-864-11 SHORT CHIP 0
JR037 1-216-864-11 SHORT CHIP 0
JR038 1-216-864-11 SHORT CHIP 0
JR040 1-216-864-11 SHORT CHIP 0
JR041 1-216-864-11 SHORT CHIP 0
JR042 1-216-864-11 SHORT CHIP 0
JR043 1-216-864-11 SHORT CHIP 0
JR046 1-216-864-11 SHORT CHIP 0
JR047 1-216-864-11 SHORT CHIP 0
JR049 1-216-864-11 SHORT CHIP 0
JR051 1-216-864-11 SHORT CHIP 0
JR300 1-216-864-11 SHORT CHIP 0
JR301 1-216-864-11 SHORT CHIP 0
JR302 1-216-864-11 SHORT CHIP 0
JR600 1-216-864-11 SHORT CHIP 0
JR601 1-216-864-11 SHORT CHIP 0
JR602 1-216-864-11 SHORT CHIP 0
JR1006 1-216-864-11 SHORT CHIP 0
JR1011 1-216-864-11 SHORT CHIP 0
JR1012 1-216-864-11 SHORT CHIP 0
JR1013 1-216-864-11 SHORT CHIP 0
JR1014 1-216-864-11 SHORT CHIP 0
JR1101 1-216-864-11 SHORT CHIP 0
JR1110 1-216-864-11 SHORT CHIP 0
JR1903 1-216-864-11 SHORT CHIP 0
<COIL>
L003 1-414-856-11 INDUCTOR 10UH
L004 1-414-187-11 INDUCTOR 47UH
L005 1-414-856-11 INDUCTOR 10UH
L006 1-414-856-11 INDUCTOR 10UH
L007 1-414-856-11 INDUCTOR 10UH
L008 1-414-856-11 INDUCTOR 10UH
L009 1-414-856-11 INDUCTOR 10UH
L010 1-469-525-91 INDUCTOR 10UH
L011 1-469-525-91 INDUCTOR 10UH
L012 1-412-058-11 INDUCTOR 10UH
L013 1-469-525-91 INDUCTOR 10UH
L031 1-469-525-91 INDUCTOR 10UH
L032 1-469-525-91 INDUCTOR 10UH
L033 1-469-525-91 INDUCTOR 10UH
L035 1-469-525-91 INDUCTOR 10UH
L036 1-469-525-91 INDUCTOR 10UH
L100 1-414-857-11 INDUCTOR 100UH
L101 1-410-498-11 INDUCTOR 1.2UH
L103 1-410-987-42 INDUCTOR 0.33UH
L106 1-414-187-11 INDUCTOR 47UH
L107 1-412-062-11 INDUCTOR 47UH
L600 1-412-533-21 INDUCTOR 47UH
L601 1-412-533-21 INDUCTOR 47UH
L602 1-412-529-11 INDUCTOR 22UH
L800 1-424-795-11 COIL, HORIZONTAL LINEARITY
L802 1-406-679-11 INDUCTOR 22MH
L803 1-414-493-41 INDUCTOR 4.7MH
L805 1-408-947-00 INDUCTOR 2.2MH
L902 1-414-187-11 INDUCTOR 47UH
L2601 1-412-525-31 INDUCTOR 10UH
A
To Next Page
