The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
– 49 –
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
KV-G14M2
RM-869
* A-1298-616-A A BOARD, COMPLETE (F35821706)
*********************
* A-1298-617-A A BOARD, COMPLETE (F35821796)
*********************
* 1-580-798-11 CONNECTOR PIN (DY) 6P
* 4-059-707-01 HOLDER, FBT
4-382-854-11 SCREW (M3X10), P, SW (+)
7-685-648-79 SCREW +BVTP 3X12 TYPE2 IT-3
<CAPACITOR>
C001 1-163-011-11 CERAMIC CHIP 0.0015MF 10% 50V
C002 1-126-965-11 ELECT 22MF 20% 50V
C003 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C004 1-126-961-11 ELECT 2.2MF 20% 50V
C006 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C007 1-126-959-11 ELECT 0.47MF 20% 50V
C008 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C009 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C010 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C011 1-126-967-11 ELECT 47MF 20% 16V
C012 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C013 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C014 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C015 1-101-884-00 CERAMIC 56PF 5% 50V
C016 1-101-884-00 CERAMIC 56PF 5% 50V
C017 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C018 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C019 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C020 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C021 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C022 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C023 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C024 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C025 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C026 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C027 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C028 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C029 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C032 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C034 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C035 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C036 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C037 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C038 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C040 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C042 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C044 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C045 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C046 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C047 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C048 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C049 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C050 1-126-960-11 ELECT 1MF 20% 50V
C051 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C052 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C053 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C054 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C055 1-124-480-11 ELECT 470MF 20% 25V
C056 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C057 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C058 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C059 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C060 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C061 1-164-505-11 CERAMIC CHIP 2.2MF 16V
C064 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C072 1-124-480-11 ELECT 470MF 20% 25V
C074 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C101 1-163-029-11 CERAMIC CHIP 0.0047MF 50V
C105 1-104-665-11 ELECT 100MF 20% 16V
C106 1-126-964-11 ELECT 10MF 20% 50V
C108 1-126-942-61 ELECT 1000MF 20% 16V
C109 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C111 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C114 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C115 1-163-093-00 CERAMIC CHIP 10PF 5% 50V
C116 1-136-165-00 FILM 0.1MF 5% 50V
C117 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C118 1-126-965-11 ELECT 22MF 20% 50V
C119 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C120 1-130-493-00 MYLAR 0.068MF 5% 50V
C121 1-130-493-00 MYLAR 0.068MF 5% 50V
C122 1-104-665-11 ELECT 100MF 20% 16V
C124 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C125 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C127 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C128 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C234 1-126-964-11 ELECT 10MF 20% 50V
C235 1-126-967-11 ELECT 47MF 20% 16V
C236 1-104-666-11 ELECT 220MF 20% 25V
C237 1-104-665-11 ELECT 100MF 20% 16V
C238 1-136-167-00 FILM 0.15MF 5% 50V
C241 1-126-942-61 ELECT 1000MF 20% 25V
C242 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C243 1-126-965-11 ELECT 22MF 20% 50V
C244 1-126-942-61 ELECT 1000MF 20% 25V
C252 1-126-961-11 ELECT 2.2MF 20% 50V
C253 1-104-665-11 ELECT 100MF 20% 16V
C255 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C258 1-136-167-00 FILM 0.15MF 5% 50V
C300 1-126-967-11 ELECT 47MF 20% 16V
C301 1-126-964-11 ELECT 10MF 20% 50V
C304 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C305 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C306 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C307 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C308 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C309 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C310 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C311 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C312 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C313 1-104-665-11 ELECT 100MF 20% 16V
C314 1-164-161-11 CERAMIC CHIP 0.0022MF 10% 50V
C315 1-107-823-11 CERAMIC CHIP 0.47MF 10% 16V
C316 1-102-125-00 CERAMIC 0.0047MF 10% 50V
C317 1-164-505-11 CERAMIC CHIP 2.2MF 16V
A
()
F35821706
F35821796
