The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
– 56 –
KV-G14M2
RM-869
<JACK>
J701 ! 1-251-192-11 SOCKET, CRT
<TRANSISTOR>
Q701 8-729-200-17 TRANSISTOR 2SA1091-O
Q702 8-729-200-17 TRANSISTOR 2SA1091-O
Q703 8-729-200-17 TRANSISTOR 2SA1091-O
Q704 8-729-326-11 TRANSISTOR 2SC2611
Q705 8-729-326-11 TRANSISTOR 2SC2611
Q706 8-729-326-11 TRANSISTOR 2SC2611
<RESISTOR>
R701 1-260-133-11 CARBON 680K 5% 1/2W
R702 1-260-123-11 CARBON 100K 5% 1/2W
R703 1-260-135-11 CARBON 1M 5% 1/2W
R705 1-260-079-11 CARBON 22 5% 1/2W
R706 1-260-105-11 CARBON 3.3K 5% 1/2W
R707 1-260-105-11 CARBON 3.3K 5% 1/2W
R708 1-260-105-11 CARBON 3.3K 5% 1/2W
R709 1-215-899-11 METAL OXIDE 15K 5% 2W F
R711 1-215-899-11 METAL OXIDE 15K 5% 2W F
R713 1-215-899-11 METAL OXIDE 15K 5% 2W F
R714 1-247-807-31 CARBON 100 5% 1/4W
R717 1-215-409-00 METAL 330 1% 1/4W
R718 1-249-409-11 CARBON 220 5% 1/4W F
R719 1-247-807-31 CARBON 100 5% 1/4W
R720 1-216-346-00 METAL OXIDE 0.56 5% 1W F
R722 1-215-411-00 METAL 390 1% 1/4W
R725 1-249-409-11 CARBON 220 5% 1/4W F
R726 1-215-479-00 METAL 270K 1% 1/4W
R727 1-215-487-00 METAL 560K 1% 1/4W
R728 1-215-479-00 METAL 270K 1% 1/4W
R730 1-247-807-31 CARBON 100 5% 1/4W
R731 1-249-409-11 CARBON 220 5% 1/4W F
R732 1-215-411-00 METAL 390 1% 1/4W
R733 1-247-791-91 CARBON 22 5% 1/4W
R734 1-247-791-91 CARBON 22 5% 1/4W
R735 1-247-791-91 CARBON 22 5% 1/4W
R749 1-249-424-11 CARBON 3.9K 5% 1/4W
R750 1-249-424-11 CARBON 3.9K 5% 1/4W
R751 1-249-424-11 CARBON 3.9K 5% 1/4W
<VARIABLE RESISTOR>
RV701 1-230-641-11 RES, ADJ, METAL GLAZE 2.2M
RV703 1-230-641-11 RES, ADJ, METAL GLAZE 2.2M
******************************************************************
* A-1241-204-A F1 BOARD, COMPLETE (F35430206/F35430296)
*********************
* A-1241-210-A F1 BOARD, COMPLETE (F35821706/F35821796)
*********************
1-533-223-11 CLIP, FUSE
<CAPACITOR>
C1601 ! 1-104-705-51 FILM 0.1MF 20% 250V
<CONNECTOR>
CN1601* 1-580-843-11 PIN, CONNECTOR (POWER)
CN1602* 1-580-843-11 PIN, CONNECTOR (POWER)
<FUSE>
F1601 ! 1-532-237-11 FUSE, TIME-LAG (BET) 3.15A/250V
<RESISTOR>
R1601 ! 1-202-916-91 SOLID 5.6M 20% 1/2W
<TRANSFORMER>
T1601 ! 1-424-391-11 TRANSFORMER, LINE FILTER
T1602 ! 1-424-391-11 TRANSFORMER, LINE FILTER
******************************************************************
MISCELLANEOUS (FOR F35430206/F35430296)
*****************
1-417-151-21 MATCHING TRANSFORMER, ANTENNA
! 1-426-145-21 COIL, DEGAUSSING
1-452-032-00 MAGNET,DISC
1-452-277-00 MAGNET, BMC
1-501-372-81 ANTENNA, TELESCOPIC
1-505-547-11 SPEAKER (5X9CM)
! 1-569-008-11 ADAPTOR, CONVERSION 2P (F35430206)
! 1-574-062-11 CORD, POWER (WITH CONNECTOR) 2.5A/250V
! 8-451-418-21 DEFLECTION YOKE (Y14NDA2)
! 8-735-562-05 PICTURE TUBE (A34JBU70X)
MISCELLANEOUS (FOR F35821706/F35821796)
*************
1-417-151-21 MATCHING TRANSFORMER, ANTENNA
! 1-426-145-21 COIL, DEMAGNETIZATION
1-452-032-00 MAGNET,DISC
1-452-277-00 MAGNET, BMC
1-501-372-81 ANTENNA, TELESCOPIC
1-505-547-11 SPEAKER (5X9CM)
! 1-574-062-11 CORD, POWER (WITH CONNECTOR) 2.5A/250V
C F1
