The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF. NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF. NO. PART NO. DESCRIPTION REMARKREF. NO. PART NO. DESCRIPTION REMARKREF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK
KV-PF14DK7/PF14L70/PF14M40/PF14M70
KV-PF14P10/PF14P70/PF14Q70
RM-952
KV-PF14DK7/PF14L70/PF14M40/PF14M70
KV-PF14P10/PF14P70/PF14Q70
RM-952
KV-PF14DK7/PF14L70/PF14M40/PF14M70
KV-PF14P10/PF14P70/PF14Q70
RM-952
C051 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C053 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C054 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C055 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C103 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C104 1-104-665-11 ELECT 100MF 20% 10V
C107 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C108 1-104-664-11 ELECT 47MF 20% 16V
C109 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C110 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C111 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C112 1-104-664-11 ELECT 47MF 20% 16V
C113 1-104-664-11 ELECT 47MF 20% 25V
C114 1-126-967-11 ELECT 47MF 20% 50V
C204 1-136-169-00 FILM 0.22MF 5% 50V
C206 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C209 1-126-965-11 ELECT 22MF 20% 50V
C210 1-126-933-11 ELECT 100MF 20% 16V
C211 1-126-941-11 ELECT 470MF 20% 25V
C212 1-126-933-11 ELECT 100MF 20% 16V
C215 1-126-942-61 ELECT 1000MF 20% 25V
C216 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C218 1-136-167-00 FILM 0.15MF 5% 50V
C220 1-126-942-61 ELECT 1000MF 20% 25V
C221 1-126-964-11 ELECT 10MF 20% 50V
C223 1-126-965-11 ELECT 22MF 20% 50V
C224 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C226 1-109-982-11 CERAMIC CHIP 1MF 10% 10V
C227 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C228 1-163-024-00 CERAMIC CHIP 0.018MF 10% 50V
C229 1-163-018-00 CERAMIC CHIP 0.0056MF 10% 50V
C230 1-163-024-00 CERAMIC CHIP 0.018MF 10% 50V
C231 1-163-018-00 CERAMIC CHIP 0.0056MF 10% 50V
C232 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C233 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C234 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C235 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C236 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C238 1-164-505-11 CERAMIC CHIP 2.2MF 16V
C240 1-164-505-11 CERAMIC CHIP 2.2MF 16V
C241 1-164-346-11 CERAMIC CHIP 1MF 16V
C242 1-164-505-11 CERAMIC CHIP 2.2MF 16V
C243 1-216-295-91 SHORT 0
C244 1-164-700-11 CERAMIC CHIP 0.68MF 16V
C245 1-164-346-11 CERAMIC CHIP 1MF 16V
C246 1-163-018-00 CERAMIC CHIP 0.0056MF 10% 50V
C248 1-163-010-11 CERAMIC CHIP 0.0012MF 10% 50V
SECTION 7
ELECTRICAL PARTS LIST
NOTE:
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
When indicating parts by reference
number, please include the board name.
• Items marked " ∗ " are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when or-
dering these items.
• All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
A
• All resistors are in ohms
• F : nonflammable
CAPACITORS
• MF : µF, PF : µµF
COILS
• MMH : mH, UH : µH
C521 1-126-934-11 ELECT 220MF 20% 16V
C522 1-126-933-11 ELECT 100MF 20% 16V
C523 1-102-002-00 CERAMIC 680PF 10% 500V
C524 1-126-967-11 ELECT 47MF 20% 50V
C526 1-130-495-00 MYLAR 0.1MF 5% 50V
C527 1-102-820-00 CERAMIC 330PF 5% 50V
C528 1-162-115-00 CERAMIC 330PF 10% 2KV
C530 1-137-372-11 FILM 0.022MF 5% 50V
C531 1-126-961-11 ELECT 2.2MF 20% 50V
C532 1-126-941-11 ELECT 470MF 20% 25V
C533 1-126-941-11 ELECT 470MF 20% 25V
C536 1-136-165-00 FILM 0.1MF 5% 50V
C537 1-126-969-11 ELECT 220MF 20% 50V
C538 1-104-492-11 FILM 0.0056MF 3% 2KV
C539 1-129-744-61 FILM 0.027MF 5% 400V
C540 1-136-171-00 FILM 0.33MF 5% 50V
C546 1-165-319-11 CERAMIC CHIP 0.1MF 50V
C548 1-164-690-91 CERAMIC CHIP 0.0022MF 5% 50V
C549 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C550 1-106-220-00 MYLAR 0.1MF 10% 100V
C551 1-126-960-11 ELECT 1MF 20% 50V
C552 1-162-116-00 CERAMIC 680PF 10% 2KV
C553 1-162-116-00 CERAMIC 680PF 10% 2KV
C554 1-137-417-11 MYLAR 0.0047MF 10% 200V
C556 1-126-941-11 ELECT 470MF 20% 25V
C557 1-126-941-11 ELECT 470MF 20% 25V
C558 1-123-024-21 ELECT 33MF 160V
C560 1-102-228-00 CERAMIC 470PF 10% 500V
C562 1-102-228-00 CERAMIC 470PF 10% 500V
C563 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C564 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C565 1-107-655-11 ELECT 47MF 20% 250V
C566 1-102-244-00 CERAMIC 220PF 10% 500V
C567 1-115-520-11 FILM 0.68MF 5% 250V
C568 1-102-228-00 CERAMIC 470PF 10% 500V
C570 1-115-517-11 FILM 0.39MF 5% 250V
C573 1-137-350-11 MYLAR 0.015MF 10% 100V
C574 1-107-957-11 ELECT 1MF 20% 250V
C576 1-130-495-00 MYLAR 0.1MF 5% 50V
C577 1-106-395-00 MYLAR 0.15MF 10% 200V
C582 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C586 1-216-295-91 SHORT 0
C600 ! 1-104-705-11 FILM 0.1MF 20% 250V
C602 ! 1-104-705-11 FILM 0.1MF 20% 250V
C603 1-104-664-11 ELECT 47MF 20% 25V
C604 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C605 ! 1-127-942-51 CERAMIC 330PF 10% 250V
C606 ! 1-127-942-51 CERAMIC 330PF 10% 250V
C607 1-161-830-00 CERAMIC 0.0047MF 99% 500V
C608 1-161-830-00 CERAMIC 0.0047MF 99% 500V
C611 1-161-830-00 CERAMIC 0.0047MF 99% 500V
C612 1-161-830-00 CERAMIC 0.0047MF 99% 500V
C613 1-117-752-11 ELECT(BLOCK) 330MF 20% 450V
C618 1-125-893-11 FILM 680PF 3% 1.5KV
C619 ! 1-119-886-51 CERAMIC 470PF 10% 250V
C620 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C621 1-102-114-00 CERAMIC 470PF 10% 50V
A
D311 8-719-988-61 DIODE 1SS355TE-17
D312 8-719-988-61 DIODE 1SS355TE-17
D313 8-719-988-61 DIODE 1SS355TE-17
D314 8-719-988-61 DIODE 1SS355TE-17
D315 8-719-988-61 DIODE 1SS355TE-17
D316 8-719-069-60 DIODE UDZS-TE17-9.1B
D320 8-719-069-60 DIODE UDZS-TE17-9.1B
D321 8-719-069-60 DIODE UDZS-TE17-9.1B
D402 8-719-158-35 DIODE RD9.1SB
D403 8-719-158-35 DIODE RD9.1SB
D405 8-719-158-35 DIODE RD9.1SB
D406 8-719-158-35 DIODE RD9.1SB
D504 8-719-302-43 DIODE EL1Z
D506 8-719-911-19 DIODE 1SS119-25
D507 8-719-988-61 DIODE 1SS355TE-17
D508 8-719-988-61 DIODE 1SS355TE-17
D509 1-216-073-00 RES,CHIP 10K 5% 1/10W
D510 8-719-988-61 DIODE 1SS355TE-17
D511 8-719-988-61 DIODE 1SS355TE-17
D512 8-719-988-61 DIODE 1SS355TE-17
D513 8-719-908-03 DIODE GP08D
D517 8-719-945-80 DIODE ERC06-15S
D518 8-719-979-85 DIODE EGP20G
D520 1-216-295-91 SHORT 0
D521 8-719-302-43 DIODE EL1Z
D522 8-719-302-43 DIODE EL1Z
D523 8-719-302-43 DIODE EL1Z
D527 8-719-908-03 DIODE GP08D
D528 8-719-908-03 DIODE GP08D
D534 1-216-295-91 SHORT 0
D602 8-719-911-19 DIODE 1SS119-25
D605 8-719-510-53 DIODE D4SB60L
D610 8-719-043-76 DIODE AK04V0
D611 8-719-046-74 DIODE AU-01Z-V1
D613 8-719-046-74 DIODE AU-01Z-V1
D614 8-719-046-74 DIODE AU-01Z-V1
D615 8-719-312-10 DIODE RU4AM-T3
D618 8-719-067-18 DIODE RN4Z
D620 8-719-110-72 DIODE RD30ESB2
D623 8-719-978-65 DIODE DTZ-TT11-15B
D624 8-719-073-01 DIODE MA111-(K8).S0
D625 8-719-158-39 DIODE RD10SB
D628 8-719-911-19 DIODE 1SS119-25
D631 8-719-068-00 DIODE ERC04-06SE
D632 8-719-068-00 DIODE ERC04-06SE
D633 8-719-948-45 DIODE ERA22-08
D634 8-719-073-01 DIODE MA111-(K8).S0
D635 8-719-073-01 DIODE MA111-(K8).S0
D636 8-719-510-02 DIODE D1NS4
D637 8-719-109-96 DIODE RD6.8ESB1
D638 8-719-510-48 DIODE D1N20R
D901 8-719-158-35 DIODE RD9.1SB
D902 8-719-158-35 DIODE RD9.1SB
D904 8-719-158-35 DIODE RD9.1SB
D905 8-719-158-35 DIODE RD9.1SB
D906 8-719-045-19 DIODE SPB-26MVWF
A
– 68 –– 67 –– 66 –
REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK
* A-1299-033-A A BOARD COMPLETE (KV-PF14DK7)
* A-1299-062-A A BOARD COMPLETE (KV-PF14L70)
* A-1299-034-A A BOARD COMPLETE (KV-PF14M70/PF14M40 (E))
* A-1299-042-A A BOARD COMPLETE (KV-PF14M70 (Hong Kong)
* A-1299-059-A A BOARD COMPLETE (KV-PF14M70 (ME))
* A-1298-995-A A BOARD COMPLETE (KV-PF14P10)
* A-1299-022-A A BOARD COMPLETE (KV-PF14P70)
* A-1299-064-A A BOARD COMPLETE (KV-PF14Q70 (E))
* A-1299-023-A A BOARD COMPLETE (KV-PF14Q70 (ME))
*************************************
* 4-055-304-01 HOLDER, LED
4-070-202-01 HOLDER, FBT
4-382-854-11 SCREW (M3X10), P, SW (+)
7-685-648-79 SCREW +BVTP 3X12 TYPE2 IT-3
<CAPACITOR>
C004 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C005 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C006 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C007 1-104-664-11 ELECT 47MF 20% 16V
C008 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C010 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C012 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C013 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C014 1-104-664-11 ELECT 47MF 20% 25V
C015 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C016 1-163-113-00 CERAMIC CHIP 68PF 5% 50V
C017 1-163-113-00 CERAMIC CHIP 68PF 5% 50V
C019 1-104-664-11 ELECT 47MF 20% 25V
C022 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C023 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C024 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C026 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C027 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C028 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C030 1-126-965-11 ELECT 22MF 20% 50V
C031 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C032 1-107-823-11 CERAMIC CHIP 0.47MF 10% 16V
C034 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C041 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C042 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C043 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C044 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C047 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C048 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C050 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C249 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C251 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C252 1-164-346-11 CERAMIC CHIP 1MF 16V
C253 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C254 1-126-965-11 ELECT 22MF 20% 50V
C255 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C256 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C259 1-126-933-11 ELECT 100MF 20% 16V
C265 1-164-505-11 CERAMIC CHIP 2.2MF 16V
C301 1-126-935-11 ELECT 470MF 20% 16V
C302 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C303 1-126-964-11 ELECT 10MF 20% 50V
C304 1-126-967-11 ELECT 47MF 20% 50V
C305 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C306 1-163-233-11 CERAMIC CHIP 18PF 5% 50V
C307 1-163-233-11 CERAMIC CHIP 18PF 5% 50V
(except KV-PF14DK7/PF14Q70)
C308 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C309 1-126-957-11 ELECT 0.22MF 20% 50V
C310 1-126-963-11 ELECT 4.7MF 20% 50V
C311 1-126-962-11 ELECT 3.3MF 20% 50V
C312 1-164-346-11 CERAMIC CHIP 1MF 16V
C313 1-164-346-11 CERAMIC CHIP 1MF 16V
C315 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C316 1-104-664-11 ELECT 47MF 20% 25V
C317 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C318 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C319 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C320 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C322 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C324 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C325 1-126-960-11 ELECT 1MF 20% 50V
C327 1-126-965-11 ELECT 22MF 20% 50V
C328 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C330 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C332 1-126-963-11 ELECT 4.7MF 20% 50V
C335 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C336 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C337 1-126-961-11 ELECT 2.2MF 20% 50V
C338 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C341 1-115-340-11 CERAMIC CHIP 0.22MF 10% 25V
C342 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C402 1-164-346-11 CERAMIC CHIP 1MF 16V
C404 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C405 1-126-935-11 ELECT 470MF 20% 16V
C407 1-164-346-11 CERAMIC CHIP 1MF 16V
C408 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C409 1-126-963-11 ELECT 4.7MF 20% 50V
C502 1-163-275-11 CERAMIC CHIP 0.001MF 5% 50V
C506 1-107-638-11 ELECT 33MF 20% 160V
C507 1-161-830-00 CERAMIC 0.0047MF 500V
C510 1-102-112-00 CERAMIC 330PF 10% 50V
C512 1-163-989-11 CERAMIC CHIP 0.033MF 10% 25V
C513 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C514 1-106-383-00 MYLAR 0.047MF 10% 200V
C518 1-104-665-11 ELECT 100MF 20% 10V
C519 1-102-212-00 CERAMIC 820PF 10% 500V
C622 1-102-074-00 CERAMIC 0.001MF 10% 50V
C623 1-104-665-11 ELECT 100MF 20% 25V
C624 1-164-143-11 CERAMIC 0.001MF 10% 1KV
C627 1-102-002-00 CERAMIC 680PF 10% 500V
C628 1-126-943-11 ELECT 2200MF 20% 25V
C629 1-126-964-11 ELECT 10MF 20% 50V
C630 1-123-024-21 ELECT 33MF 160V
C633 1-104-999-11 MYLAR 0.1MF 10% 200V
C634 1-126-933-11 ELECT 100MF 20% 16V
C635 1-104-665-11 ELECT 100MF 20% 10V
C636 1-104-760-11 CERAMIC CHIP 0.047MF 10% 50V
C639 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C640 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C642 1-126-767-11 ELECT 1000MF 20% 16V
C643 1-104-665-11 ELECT 100MF 20% 10V
C644 1-104-331-11 CERAMIC 0.0022MF 10% 1KV
C645 1-137-605-11 FILM 0.01MF 10% 250V
C646 1-107-679-91 ELECT 10MF 20% 450V
C647 1-163-275-11 CERAMIC CHIP 0.001MF 5% 50V
C649 1-126-940-11 ELECT 330MF 20% 25V
C650 1-163-275-11 CERAMIC CHIP 0.001MF 5% 50V
C651 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C652 1-126-965-11 ELECT 22MF 20% 50V
C657 1-101-821-00 CERAMIC 0.0022MF 500V
C658 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C901 1-136-153-00 FILM 0.01MF 5% 50V
C905 1-126-963-11 ELECT 4.7MF 20% 50V
C906 1-164-346-11 CERAMIC CHIP 1MF 16V
C907 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C910 1-126-967-11 ELECT 47MF 20% 50V
C911 1-126-967-11 ELECT 47MF 20% 50V
C912 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C913 1-104-665-11 ELECT 100MF 20% 10V
C914 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
<CONNECTOR>
CN104 1-695-915-11 TAB (CONTACT)
CN202 * 1-785-608-11 PIN, CONNECTOR 4P
CN203 * 1-564-506-11 PLUG, CONNECTOR 3P
CN204 * 1-564-506-11 PLUG, CONNECTOR 3P
CN305 * 1-564-509-11 PLUG, CONNECTOR 6P
CN505 * 1-508-766-00 PIN, CONNECTOR (5MM PITCH) 4P
CN601 * 1-580-843-11 PIN, CONNECTOR (POWER)
CN602 * 1-508-786-00 PIN, CONNECTOR (5MM PITCH) 2P
CN604 * 1-573-963-11 PIN, CONNECTOR (PC BOARD) 3P
CN901 * 1-564-506-11 PLUG, CONNECTOR 3P
<DIODE>
D001 8-719-988-61 DIODE 1SS355TE-17
D005 8-719-988-61 DIODE 1SS355TE-17
D006 8-719-988-61 DIODE 1SS355TE-17
D203 8-719-914-42 DIODE DA204K
D300 1-216-295-91 SHORT 0
D301 8-719-988-61 DIODE 1SS355TE-17
D306 8-719-988-61 DIODE 1SS355TE-17
D307 8-719-988-61 DIODE 1SS355TE-17
D308 8-719-988-61 DIODE 1SS355TE-17
D309 8-719-159-10 DIODE RD5.1SB-T2
To Next Page
Loading...
