Sony Trinitron KV-PF14DK7 - Scheamtic Diagram of a(2;2) Board

http://cxema.ru
– 71 –
REF. NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF. NO. PART NO. DESCRIPTION REMARK
KV-PF14DK7/PF14L70/PF14M40/PF14M70
KV-PF14P10/PF14P70/PF14Q70
RM-952
A
R302 1-216-295-91 SHORT 0
R303 1-216-049-91 RES,CHIP 1K 5% 1/10W
R304 1-216-073-00 RES,CHIP 10K 5% 1/10W
R305 1-216-051-00 RES,CHIP 1.2K 5% 1/10W
R306 1-216-077-91 RES,CHIP 15K 5% 1/10W
R308 1-216-025-91 RES,CHIP 100 5% 1/10W
R309 1-216-025-91 RES,CHIP 100 5% 1/10W
R310 1-216-025-91 RES,CHIP 100 5% 1/10W
R311 1-216-017-91 RES,CHIP 47 5% 1/10W
R312 1-216-041-00 RES,CHIP 470 5% 1/10W
R313 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R314 1-216-045-00 RES,CHIP 680 5% 1/10W
R316 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R317 1-216-077-91 RES,CHIP 15K 5% 1/10W
R318 1-216-051-00 RES,CHIP 1.2K 5% 1/10W
R319 1-216-025-91 RES,CHIP 100 5% 1/10W
R320 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R321 1-216-073-00 RES,CHIP 10K 5% 1/10W
R322 1-216-033-00 RES,CHIP 220 5% 1/10W
R331 1-216-295-91 SHORT 0
R332 1-216-033-00 RES,CHIP 220 5% 1/10W
R333 1-216-073-00 RES,CHIP 10K 5% 1/10W
R334 1-216-129-00 RES,CHIP 2.2M 5% 1/10W
R335 1-216-045-00 RES,CHIP 680 5% 1/10W
R338 1-216-041-00 RES,CHIP 470 5% 1/10W
R340 1-216-025-91 RES,CHIP 100 5% 1/10W
R345 1-216-081-00 RES,CHIP 22K 5% 1/10W
R348 1-208-806-11 RES,CHIP 10K 0.50% 1/10W
R349 1-216-073-00 RES,CHIP 10K 5% 1/10W
R350 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R351 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R354 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R355 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R356 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R357 1-216-079-00 RES,CHIP 18K 5% 1/10W
R358 1-216-049-91 RES,CHIP 1K 5% 1/10W
R359 1-216-033-00 RES,CHIP 220 5% 1/10W
R360 1-216-033-00 RES,CHIP 220 5% 1/10W
R361 1-216-073-00 RES,CHIP 10K 5% 1/10W
R362 1-216-075-00 RES,CHIP 12K 5% 1/10W
R363 1-216-079-00 RES,CHIP 18K 5% 1/10W
R364 1-216-295-91 SHORT 0
R365 1-216-033-00 RES,CHIP 220 5% 1/10W
R366 1-216-073-00 RES,CHIP 10K 5% 1/10W
R367 1-216-073-00 RES,CHIP 10K 5% 1/10W
R370 1-216-033-00 RES,CHIP 220 5% 1/10W
R376 1-216-081-00 RES,CHIP 22K 5% 1/10W
R377 1-216-121-91 RES,CHIP 1M 5% 1/10W
R378 1-216-031-00 RES,CHIP 180 5% 1/10W
R404 1-216-073-00 RES,CHIP 10K 5% 1/10W
R405 1-216-049-91 RES,CHIP 1K 5% 1/10W
R406 1-216-073-00 RES,CHIP 10K 5% 1/10W
R408 1-216-049-91 RES,CHIP 1K 5% 1/10W
R411 1-216-113-00 RES,CHIP 470K 5% 1/10W
R412 1-216-041-00 RES,CHIP 470 5% 1/10W
R413 1-216-021-00 RES,CHIP 68 5% 1/10W
R414 1-216-113-00 RES,CHIP 470K 5% 1/10W
R417 1-216-077-91 RES,CHIP 15K 5% 1/10W
R418 1-216-113-00 RES,CHIP 470K 5% 1/10W
R419 1-216-022-00 RES,CHIP 75 5% 1/10W
R426 1-216-033-00 RES,CHIP 220 5% 1/10W
R505 1-216-107-00 RES,CHIP 270K 5% 1/10W
R506 1-216-083-00 RES,CHIP 27K 5% 1/10W
R507 1-249-389-11 CARBON 4.7 5% 1/4W F
R508 1-215-885-00 METAL OXIDE 68 5% 2W F
R509 1-215-887-00 METAL OXIDE 150 5% 2W F
R510 1-215-886-11 METAL OXIDE 100 5% 2W F
R511 1-215-911-11 METAL OXIDE 100 5% 3W F
R516 1-216-081-00 RES,CHIP 22K 5% 1/10W
R518 1-247-807-31 CARBON 100 5% 1/4W
R520 1-215-445-00 METAL 10K 1% 1/4W
R522 1-208-806-11 RES,CHIP 10K 0.50% 1/10W
R523 1-249-411-11 CARBON 330 5% 1/4W
R526 1-208-798-11 RES,CHIP 4.7K 0.50% 1/10W
R527 1-216-001-00 RES,CHIP 10 5% 1/10W
R528 1-208-814-91 RES,CHIP 22K 0.50% 1/10W
R529 1-208-766-11 RES,CHIP 220 0.50% 1/10W
R531 1-247-843-11 CARBON 3.3K 5% 1/4W
R533 1-249-417-11 CARBON 1K 5% 1/4W
R534 1-216-361-00 METAL OXIDE 0.22 5% 2W F
R535 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R536 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R540 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R541 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R542 1-216-295-91 SHORT 0
R543 1-249-426-11 CARBON 5.6K 5% 1/4W F
R544 1-215-922-11 METAL OXIDE 6.8K 5% 3W F
R545 1-216-077-91 RES,CHIP 15K 5% 1/10W
R546 1-216-077-91 RES,CHIP 15K 5% 1/10W
R547 1-216-085-00 RES,CHIP 33K 5% 1/10W
R549 1-215-459-00 METAL 39K 1% 1/4W
R550 1-216-097-91 RES,CHIP 100K 5% 1/10W
R551 1-249-421-11 CARBON 2.2K 5% 1/4W
R552 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R553 1-215-459-00 METAL 39K 1% 1/4W
R554 1-215-461-00 METAL 47K 1% 1/4W
R556 1-215-437-00 METAL 4.7K 1% 1/4W
R557 1-216-345-11 METAL OXIDE 0.47 5% 1W F
R558 1-249-421-11 CARBON 2.2K 5% 1/4W
R559 1-249-429-11 CARBON 10K 5% 1/4W
R560 1-216-073-00 RES,CHIP 10K 5% 1/10W
R562 1-249-401-11 CARBON 47 5% 1/4W
R565 1-216-085-00 RES,CHIP 33K 5% 1/10W
R567 1-216-085-00 RES,CHIP 33K 5% 1/10W
R568 1-249-383-11 CARBON 1.5 5% 1/4W F
R570 1-216-079-00 RES,CHIP 18K 5% 1/10W
R571 1-215-437-00 METAL 4.7K 1% 1/4W
R573 1-216-073-00 RES,CHIP 10K 5% 1/10W
R577 1-215-913-11 METAL OXIDE 220 5% 3W F
R578 1-216-369-00 METAL OXIDE 1 5% 2W F
R579 1-216-097-91 RES,CHIP 100K 5% 1/10W
R580 1-216-675-91 METAL CHIP 10K 0.50% 1/10W
R581 1-208-800-11 RES,CHIP 5.6K 0.50% 1/10W
R583 1-216-105-91 RES,CHIP 220K 5% 1/10W
